CI610-3BHT300003R1

/ 4.9
1001 reviews | Need a Specific Revision?
The CI610-3BHT300003R1 is an I/O bus extender designed for ABB Advant Master basic units. It belongs to the CI610 series of bus interfaces. This module is used in I/O stations such as RF615K01 (single CI610) and RF615K02 (redundant CI610).
Get a quick price for CI610-3BHT300003R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI610-3BHT300003R1

  • Manufacturer:
    ABB
  • Part Number:
    CI610-3BHT300003R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • ABB Type Designation:
    CI610
  • Catalog Description:
    IOB_A Bus Extender for Basic Unit
  • Product Type:
    Communication Module
  • WEEE Category:
    5 – Small Equipment (no external dimension >50 cm)
  • RoHS Status:
    Exempt (2011/65/EU Article 2(4)(c,e,f,j))
  • Pain Point Solved:
    Solves the need for a bus extender to connect basic units to remote I/O in ABB Advant Master systems – enabling physical separation of I/O racks from the controller while maintaining bus communication, with single or redundant CI610 configurations for increased availability.
  • Weight:
    1.16 kg
  • Estimated shipping dimensions:
    3.9x25.1x27.3cm
  • Tariff Code:
    8517795000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Protection Functions Installation and Upgrades

Features:

  • Extends the I/O bus from a basic unit to remote I/O stations; supports single or redundant configurations.
  • Works with Advant Controller 110/160, Advant OCS with Master SW, and S600 I/O.
  • Legal for sale and installation in legacy ABB Advant Master process control systems under EU RoHS exemption.
The CI610-3BHT300003R1 is a dedicated I/O bus extender for ABB Advant Master basic units. It allows the basic unit (controller) to communicate with remote I/O racks located up to physically separated distances. This is essential in large process plants where the controller must be in a safe area while I/O modules are distributed near field devices. The module is used in two kit configurations: RF615K01 for single (non‑redundant) operation and RF615K02 for redundant (dual CI610) operation. Redundancy provides fault tolerance – if one bus extender fails, the second takes over without interrupting process control. For engineers maintaining legacy Advant Master systems (Controller 110/160), the CI610-3BHT300003R1 is a critical spare part.

The CI610-3BHT300003R1 is listed under several ABB product categories: AC 100 – Communication Modules, Advant OCS with Master SW – Controllers (Advant Controller 110 and 160), and S600 I/O – Communication Modules. This wide compatibility means the same bus extender can be used across different generations of ABB control systems. Whether you have an older Advant Controller 110 or a newer Advant Controller 160, the CI610-3BHT300003R1 provides a consistent I/O bus extension solution. It is also used within the S600 I/O family, which is known for its rugged design and high availability.

The CI610-3BHT300003R1 is explicitly exempt from the EU 2011/65/EU RoHS directive under Article 2(4)(c), (e), (f), and (j). This exemption applies to spare parts for legacy process control systems (ABB Advant Master) placed on the market before RoHS restrictions took effect. As a result, the module may contain lead, cadmium, mercury, or other restricted substances that are no longer allowed in new electronic products. However, for operators of existing Advant Master systems, this exemption is critical – it allows the continued sale, installation, and use of CI610-3BHT300003R1 as a spare part to keep legacy plants running.

The CI610-3BHT300003R1 ABB Communication Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

ABB CI610-3BHT300003R1 Communication Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB CI610-3BHT300003R1 Communication Module Specs

General

  • Manufacturer ABB
  • Model CI610-3BHT300003R1
  • Condition New Original ready stock
  • Product Family CI615,CI620,CI630
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Control System Expansion: Dedicated to Advant Master or AC500 control systems, extending the I/O bus by up to 50 meters.
  • Critical Industrial Processes: Widely used in industries with extremely high requirements for real-time data processing and stability, such as petrochemicals, power energy, metallurgy, and papermaking.
  • Redundant System Configuration: Commonly used in RF615K01 (standalone) and RF615K02 (redundant) I/O station kits to ensure continued operation of critical processes in the event of hardware failure.
  • Real-time Diagnostics: Provides real-time analysis of system performance, supporting proactive maintenance.
  • Fault Indication: The panel typically features status LEDs (such as running and fault indicators) for quick identification of internal module faults or communication interruptions.
  • Hot Swap: Supports hot-swap module replacement, allowing maintenance without shutting down the entire system, ensuring production continuity.
  • Physical Installation: The CI610 features a compact design (40mm wide x 273mm high) and requires mounting on a standard rack or rail. It weighs approximately 1.2 kg; ensure good ventilation during installation.
  • Connectivity Requirements: Used to connect controllers and expansion I/O stations.
  • Caching should be kept away from power cables as much as possible to avoid electromagnetic interference.
Description
The CI610-3BHT300003R1 is an I/O bus extender designed for ABB Advant Master basic units. It belongs to the CI610 series of bus interfaces. This module is used in I/O stations such as RF615K01 (single CI610) and RF615K02 (redundant CI610).

When using the CI610-3BHT300003R1, engineers can extend the I/O bus for Advant Controller 110 and 160 systems. It is part of the S600 I/O communication module family.The CI610-3BHT300003R1 is exempt from the 2011/65/EU RoHS directive under Article 2(4)(c), (e), (f), and (j). This exemption applies to specific ABB Advant Master process control system components. The exchange part number is 7650055-439. The declaration of conformity reference is 3BSE088609.

For legacy ABB Advant Master system expansions or repairs, the CI610-3BHT300003R1 provides a direct replacement bus extender. It is listed under multiple ABB categories: AC 100 – Communication Modules, Advant OCS with Master SW, Controllers, and S600 I/O. Always verify compatibility with your specific basic unit and I/O station configuration.
Alternative Names
CI615 CI620 CI630 CI610-3BHT300003R2
Technical notes
The CI610-3BHT300003R1 is exempt from RoHS – it may contain lead, mercury, or other restricted substances. Do not dispose of it in standard electronic waste streams; follow WEEE Category 5 guidelines. The module has an exchange part number 7650055-439
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which ABB systems work with the CI610-3BHT300003R1?
The CI610-3BHT300003R1 is used with Advant Controller 110 and 160, Advant Master process control systems, and S600 I/O. It is a bus extender for basic units.
Is the CI610-3BHT300003R1 RoHS compliant?
No. The CI610-3BHT300003R1 is exempt from the 2011/65/EU RoHS directive under Article 2(4)(c), (e), (f), and (j) for ABB Advant Master process control systems.
Can I use two CI610-3BHT300003R1 modules for redundancy?
Yes. The CI610-3BHT300003R1 is used in RF615K02 I/O station kit with redundant CI610 configuration.
