  • Lifecycle status

     Discontinued / Obsolete by OEM
    Apter Power specializes in sourcing obsolete ABB Advant Master hardware, providing certified, high-reliability replacement parts to keep your established DCS systems operational.

DSDO120 57160001-AK

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB DSDO120 57160001-AK is designed for seamless installation within standard control system racks and allows for easy expansion of existing I/O configurations.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for DSDO120 57160001-AK
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSDO120 57160001-AK

  • Manufacturer:
    ABB
  • Part Number:
    DSDO120 57160001-AK
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Digital Output Unit
  • Stock:
    1
  • Number of Channels:
    16
  • Output Voltage Range:
    24-48 V DC
  • Output Current per Channel:
    1 A
  • Isolation Type:
    Opto-Isolated
  • Backplane Logic Supply:
    +5 V DC (internal bus)
  • Form Factor:
    Single-slot circuit board format
  • Weight:
    0.44 kg
  • Estimated shipping dimensions:
    2x25.3x24.3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Communication & Connectivity Monitoring & Control

Features:

  • Digital Output Interface Between Control Systems and Industrial Field Devices
  • Provides 16-Channel Opto-Isolated Switching with Wide Voltage Range Support
  • Operates in Conjunction with ABB Distributed Control Systems and PLC Platforms
The ABB DSDO120 57160001-AK Digital Output Unit serves as a reliable digital output interface in industrial automation racks, providing isolated DC switching signals to multiple field devices within the system. It continuously drives output loads across 16 independent channels, each supporting 24-48 V DC at up to 1 A per channel, and distributes these control signals through the rack backplane to support steady state operation of connected actuators and indicators. Reliable signal isolation is standard with the DSDO120 57160001-AK, with its built-in opto-isolation technology ensuring effective electrical separation between control circuits and field equipment to prevent ground loop interference and enhance system safety.

The DSDO120 57160001-AK provides essential digital output functions common to the entire control rack, and is a critical component of the control path, directly affecting the proper, normal operation of the overall automation system. One or more DSDO120 57160001-AK output modules may be installed per rack depending on the required channel count and I/O density. The DSDO120 57160001-AK occupies a standard slot position in the rack and integrates directly with the ABB backplane architecture.

For expanded output applications, the ABB system allows additional DSDO120 57160001-AK modules to be installed in available slots. In addition to standard single module operation, multiple DSDO120 57160001-AK units can be configured within the same rack to scale channel capacity as needed. The ABB rack configuration executes module addressing through the internal backplane circuitry specified in the system options.

The DSDO120 57160001-AK ABB Digital Output Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB DSDO120 57160001-AK Digital Output Unit Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB DSDO120 57160001-AK Digital Output Unit Specs

General

  • Manufacturer ABB
  • Model DSDO120 57160001-AK
  • Condition New Original ready stock
  • Product Family DSTD120A 57160001-UD,DSDO115 57160001-NF
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Industrial Automation: Driving assembly lines, conveyor belts, and robotic packaging systems.
  • Process Industries: Actuating solenoid valves, chemical dosing pumps, and process dampers in oil, gas, and chemical plants.
  • Power Distribution: Controlling switchgears, circuit breakers, and protective relays in utility substations.
  • Facility Management: Managing heavy-duty HVAC dampers, motorized security gates, and large-scale industrial lighting grids.
  • Bus Architecture: Plugs directly into the ABB S100 I/O bus backplane for native rack communication.
  • System Compatibility: Interfaces seamlessly with Advant Controller 410/450, MasterPiece 200, and Symphony Plus / 800xA DCS platforms.
  • Signal Isolation: Features onboard optical isolation to shield internal logic circuits from field-side electrical noise and surges.
  • Field Wiring: Connects to field devices via standard termination units using binary on/off signaling.
  • Channel Capacity: Manages up to 16 independent binary output channels simultaneously.
  • Electrical Ratings: Supports 24V to 48V DC nominal operating voltages with up to 1A output current per channel.
  • Circuit Protection: Includes built-in overcurrent and short-circuit protection to prevent hardware damage from field faults.
  • Diagnostics Support: Reports channel status and fault detection back to the central controller for real-time system monitoring.
Description
The ABB DSDO120 57160001-AK Digital Output Unit is a high-performance industrial control module designed for reliable switching operations in automation systems. The DSDO120 57160001-AK features 16 digital output channels, each supporting a voltage range of 24-48 V DC with a maximum current rating of 1 A. Equipped with opto-isolation technology, the DSDO120 57160001-AK ensures effective electrical separation between control circuits and field devices, enhancing system safety and signal integrity in demanding industrial environments.

The DSDO120 57160001-AK is specifically designed to handle multi-channel digital output control requirements in industrial automation, addressing the challenge of driving multiple external loads simultaneously while maintaining electrical isolation. By integrating 16 opto-isolated output channels into a single compact unit, the DSDO120 57160001-AK solves the problem of signal interference and ground loop issues that commonly occur when control systems interface with high-power field equipment. This makes the DSDO120 57160001-AK an ideal solution for applications requiring safe, isolated switching of solenoids, relays, contactors, and indicator devices across varied voltage levels.

The DSDO120 57160001-AK is widely applied across multiple industrial sectors, including process control, manufacturing automation, power generation, and material handling systems. In these environments, the DSDO120 57160001-AK serves as a critical interface component for driving actuators, motor starters, and pneumatic valves. The robust opto-isolated design of the DSDO120 57160001-AK makes it particularly suitable for deployment in heavy industries such as oil and gas, chemical processing, water treatment, and factory automation lines where reliable digital signal output and electrical noise immunity are essential.
Alternative Names
DSDO120 57160001-AK DSD0120 57160001-AK DSDOI20 57I6000I-AK DSDI110A 57160001-AA DSDI120A 57160001-ACA DSTD120A 57160001-UD DSDO115 57160001-NF
Technical notes
The ABB DSDO120 57160001-AK is designed with strong electrical isolation in mind, employing advanced opto-isolation technology to protect sensitive control-side electronic components from severe external magnetic field interference, ground loops, and high-voltage spikes.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What problem does the ABB DSDO120 57160001-AK solve?
The ABB DSDO120 57160001-AK is designed to execute high-current digital output commands in demanding industrial environments. It helps protect the control system from short circuits, voltage surges, and electrical interference that could otherwise damage controllers or interrupt production.
Why is the ABB DSDO120 57160001-AK suitable for harsh industrial environments?
The module provides reliable output control even in locations with strong electromagnetic interference and continuous operation. Its robust design ensures stable switching performance while minimizing electrical noise between field devices and the control system.
What types of field devices can the ABB DSDO120 57160001-AK control?
It is commonly used to operate heavy-duty relays, solenoid valves, motorized actuators, warning lamps, alarm indicators, and other discrete industrial loads that require dependable digital switching.
What industrial processes benefit from the ABB DSDO120 57160001-AK?
It supports safety interlock systems, automatic process sequencing, equipment start/stop control, valve operation, and fluid routing applications that require accurate and continuous binary output signals.
