DSTY101 57120001-KY

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DSTY101 57120001-KY is the S100 I/O Analog Isolation Amplifier for S100 I/O Hardware. It isolates and conditions selectable voltage or current signals in S100 I/O installations.
In Stock
Ships by Saturday, October 31
Get a quick price for DSTY101 57120001-KY
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSTY101 57120001-KY

  • Manufacturer:
    ABB
  • Part Number:
    DSTY101 57120001-KY
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Analog Isolation Amplifier
  • Stock:
    1
  • Input Signal Ranges:
    0...10 V; 0...5 V; 0...2 V; 0...20 mA
  • Input Selection:
    Jumper group S1
  • Output Selection:
    Jumper groups S2 and S3
  • Rise Time:
    100 ms with S3 pins 3-4 installed; 40 s without
  • Mounting:
    DSRA 110 mounting bar
  • Supply:
    24 VDC system supply
  • Hardware Family:
    S100 I/O
  • Manual:
    3BSE002413R0201
  • Tariff Code:
    8543709990
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Configuration Mounting & Power S100 Service Details

Features:

  • The input signal ranges are 0...10 V; 0...5 V; 0...2 V; 0...20 mA.
  • Input selection is set to Jumper group S1.
  • The module's output selection is Jumper groups S2 and S3.
DSTY101 57120001-KY combines input signal ranges of 0...10 V; 0...5 V; 0...2 V; 0...20 mA, input selection of Jumper group S1, and output selection of Jumper groups S2 and S3 in the S100 I/O Hardware platform.

It isolates and conditions selectable voltage or current signals in S100 I/O installations. This role connects the S100 I/O Analog Isolation Amplifier to the surrounding S100 I/O Hardware architecture.

Before commissioning, record all S1, S2 and S3 positions before removal; verify the field-signal range and output circuit; and match the DSRA 110 mounting and terminal arrangement.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for ABB DSTY101 57120001-KY: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Provides galvanic signal conditioning in legacy S100 I/O cabinets.
  • Adapts voltage and current input arrangements to the installed analog circuit.
  • Supports service replacement where the original jumper configuration can be preserved.
  • Installing the S3 pins 3-4 jumper selects a 100 ms rise time.
  • Without the S3 pins 3-4 jumper, the rise time changes to 40 seconds.
  • Commissioning teams need to record all S1, S2 and S3 positions before removal.
  • Mechanical mounting uses the DSRA 110 mounting bar.
  • The module draws power from the 24 VDC system supply.
  • Before work begins, personnel must match the DSRA 110 mounting and terminal arrangement.
  • The hardware belongs to the S100 I/O platform.
  • Input-to-supply isolation withstands 3 kV at 50 Hz for one minute.
  • Commissioning teams need to verify the field-signal range and output circuit.
Description
ABB DSTY101 57120001-KY is an S100 I/O Analog Isolation Amplifier for the S100 I/O Hardware platform. It isolates and conditions selectable voltage or current signals in S100 I/O installations. This supports dependable operation within the intended automation architecture.

The rise time is 100 ms with S3 pins 3-4 installed; 40 s without. The module mounts on the DSRA 110 mounting bar. Together, these characteristics support stable integration of the S100 I/O Analog Isolation Amplifier into S100 I/O Hardware systems.

Power is provided by the 24 VDC system supply. The hardware family is S100 I/O. This combination helps engineers preserve the S100 I/O Analog Isolation Amplifier's intended interface and operating role.
Alternative Names
DSTY101-57120001-KY DSTY101 57120001-KY DSTY101 57120001 KY DSTY10157120001KY ABB DSTY101-57120001-KY ABB S100 I/O DSTY101 ABB DSTY101 57120001-KY DSTY101 57120001-KY S100 I/O Analog Isolation Amplifier
Technical notes
Before servicing DSTY101 57120001-KY, record all S1, S2 and S3 positions before removal; verify the field-signal range and output circuit before commissioning.
