ABB DO630 3BHT300007R1 is a 16-channel isolated 250 V AC digital output module for S600 I/O and Advant control installations.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for DO630 3BHT300007R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DO630 3BHT300007R1

  • Manufacturer:
    ABB
  • Part Number:
    DO630 3BHT300007R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    16-channel isolated digital output module
  • Stock:
    1
  • ABB Type Designation:
    DO630
  • Function:
    Digital output module
  • Output Channels:
    16
  • Channel Grouping:
    16 isolated groups
  • Output Voltage Class:
    250 V AC
  • I/O Family:
    S600 I/O
  • WEEE Category:
    5, small equipment
  • Battery Content:
    0
  • RoHS Status:
    Follows EU Directive 2011/65/EU
  • Dimensions:
    4.0 × 27.3 × 25.2 cm
  • Weight:
    1.32 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compliance Relay Ratings Replacement Checks Application
  • 16 digital output channels in 16 isolated groups
  • 250 V AC output class for supported field loads
  • ABB S600 I/O module for Advant control installations

DO630 3BHT300007R1 is an ABB digital output module for S600 I/O.

The module provides 16 output channels with isolated grouping for field switching duties.

Match the complete product ID, electrical load, protection, wiring, slot, and controller database before replacement.

Availability, condition, price, and shipping time for DO630 3BHT300007R1 are confirmed during quotation.

ABB DO630 3BHT300007R1 Digital Output Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • ABB records the module as compliant with EU RoHS Directive 2011/65/EU.
  • The documented WEEE classification is Category 5, small equipment.
  • ABB records zero batteries in the DO630 3BHT300007R1 module.
  • DO630 3BHT300007R1 provides 16 relay-contact outputs for 24 to 250 V AC/DC circuits.
  • ABB specifies a maximum load current of 2 A; the first relay-data condition also specifies a 20 mA minimum.
  • ABB lists breaking capacities of 500 VA AC and 40 W DC for the first relay-data condition, and 120 W DC for the second.
  • Verify 3BHT300007R1 on the installed module
  • Confirm field voltage, current, protection, and terminal wiring
  • Record controller configuration before removal
  • Isolated digital output expansion in ABB S600 I/O stations
  • Sixteen-channel field-output control in Advant Controller 160 installations
  • Switching 250 V AC field circuits that require individually isolated output groups
Description
DO630 3BHT300007R1 is an ABB S600 digital output module with 16 isolated output channels arranged in 16 groups.

Its documented output class is 250 V AC, making it suitable for switching field loads within supported ABB Advant control architectures.

Confirm the complete product ID, field voltage, load current, wiring, module position, and controller configuration before replacement.
Alternative Names
DO630 DO 630 3BHT300007R1 DO630 3BHT300007R1 ABB DO630 ABB DO630 3BHT300007R1
Technical notes
Before installing ABB DO630 3BHT300007R1, verify output voltage, load current, terminal wiring, rack position, and controller configuration. De-energize the cabinet and follow site lockout procedures.
