    Apter Power can quote the exact board and provide technical documents for its installed pulse-amplifier arrangement.

3BHE013299R0022 LT C743 CE22

/ 4.9
1001 reviews | Need a Specific Revision?
ABB 3BHE013299R0022 LT C743 CE22 is a labeled circuit board assembly whose full ABB material number and board designation should be retained together during sourcing.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 3BHE013299R0022 LT C743 CE22
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3BHE013299R0022 LT C743 CE22

  • Manufacturer:
    ABB
  • Part Number:
    3BHE013299R0022 LT C743 CE22
  • Product Family:
    ABB Drives
  • Product Type:
    Circuit Board Assembly
  • Stock:
    1
  • ABB material number:
    3BHE013299R0022
  • Board designation:
    LT C743 CE22
  • Identification basis:
    Visible ABB label on the documented board
  • Visible board references:
    MASTER/SLAVE selectors and ERROR/OK legends
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Switzerland
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Photo Identity Board Markings Receiving Match Product Applications

Features:

  • Complete board identity: the ABB material line and board designation are retained as one product title.
  • Visible operating references: selector and indicator legends provide configuration-specific photo-matching points.
  • Physical receiving match: connector positions, mounting holes and component placement support a like-for-like visual comparison.
The complete label line separates the orderable board identity from barcode and other trace markings.

Visible selector and indicator legends give receiving teams more evidence than the product title alone when comparing a supplied board with the removed unit.

Board outline, connector placement and mounting points provide additional mechanical evidence, while installation approval still depends on the host-equipment record.

Apter Power supports ABB 3BHE013299R0022 LT C743 CE22 Circuit Board Assembly identity review, quotation and sourcing coordination.
ABB 3BHE013299R0022 LT C743 CE22 Circuit Board Assembly Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Exact label line: 3BHE013299R0022 LT C743 CE22 appears as the complete ABB product identity.
  • Trace separation: the barcode string is retained as receiving evidence rather than added to the product title.
  • Brand reference: the ABB mark and material label must remain visible on the supplied board.
  • Image match: component placement and the labeled board edge provide a second identity check.
  • Selector legends: visible MASTER and SLAVE positions help distinguish the photographed board layout.
  • Status legends: ERROR and OK markings provide recognizable front-side references.
  • Test references: marked test points should remain consistent with the approved receiving image.
  • Connector pattern: connector locations and neighboring large components support configuration comparison.
  • Identity match: release the board only when the full product label matches the purchase record.
  • Outline match: compare the board shape and edge profile with the removed unit.
  • Mounting match: reconcile mounting holes, connector locations and component clearance before installation.
  • Condition review: quarantine boards with damaged connectors, displaced components or unreadable labels.
  • Exact installed-board replacement: use only where the equipment record calls for 3BHE013299R0022 LT C743 CE22.
  • Maintenance outage planning: compare the spare with the removed board before the scheduled intervention.
  • Traceable procurement: keep the complete product identity on quotations, purchase orders and receiving records.
  • Engineering approval boundary: a visual match alone does not establish compatibility with another host position.
Description
At the firing stage of an ABB medium-current converter, the LT C743 pulse amplifier takes an optical ignition signal and drives two pulse transformers for power thyristors. 3BHE013299R0022 LT C743 CE22 is the CE22-designated board for this function.

In the LT C743 CE arrangement, one master can drive up to twelve slave boards, with the slaves supplied through plug X2. The position of 3BHE013299R0022 LT C743 CE22 in that chain matters when selecting a board for an installed converter.

The LT C743 BE/CE family uses a 48 V DC supply; at 24 V DC, performance is limited. For 3BHE013299R0022 LT C743 CE22, this difference matters if the installed converter uses the lower supply voltage.
Alternative Names
3BHE013299R0022 LTC743 CE22 3BHE013299R0022 LTC743CE22 ABB 3BHE013299R0022
Technical notes
Treat 3BHE013299R0022 LT C743 CE22 as one complete board identity. Record the ABB material number, LT C743 CE22 designation, barcode label, connector positions, selector markings, indicator legends, mounting points and board outline before service. Do not add other nearby codes unless approved ABB documentation identifies them as part of this same assembly.
