    Apter Power provides premium, genuine ABB replacement hardware for critical machinery control protection.

NXPP-03C 64008544

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB NXPP-03C 64008544 is a control distribution board for ACS600/ACC600 drives, managing power and signal distribution with 24V DC and RS-485 communication.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for NXPP-03C 64008544
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for NXPP-03C 64008544

  • Manufacturer:
    ABB
  • Part Number:
    NXPP-03C 64008544
  • Product Family:
    ABB Drives
  • Product Type:
    Control Distribution Board
  • Stock:
    1
  • Input Voltage:
    24V DC nominal
  • On-Board Rails:
    +5V DC at 6A
  • Isolation:
    500V DC rail-to-earth
  • Operating Temperature:
    0°C to +60°C
  • Storage Temperature:
    -40°C to +85°C
  • Humidity:
    5-95% RH non-condensing
  • Communication Interface:
    RS-485
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    36.5x14.2x1.5cm
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Communication Safety & Compliance

Features:

  • Manages power and signal distribution for MultiDrive systems in larger frame sizes
  • 24V DC input with +5V at 6A rails and 500V DC isolation
  • Enables data exchange between drives and higher-level automation networks
The NXPP-03C 64008544 is a control distribution board specifically designed for ABB's ACS600 and ACC600 MultiDrive modules, particularly in larger frame sizes like R10i and up . It functions as a central hub for power and signal management within control panels, helping organize inputs/outputs and distribute control logic to industrial devices such as PLCs, relays, and actuators . The NXPP-03C 64008544 is a standard component that simplifies connectivity and improves real-time control across distributed industrial environments.

The NXPP-03C 64008544 operates on a nominal 24V DC input with on-board rails providing +5V DC at 6A, and features 500V DC rail-to-earth isolation for robust noise immunity . The board operates from 0°C to +60°C and can be stored from -40°C to +85°C with 5-95% non-condensing humidity . Weighing approximately 0.2 kg with dimensions of 36.5 x 14.2 x 1.5 cm, the NXPP-03C 64008544 is designed for installation inside drive cabinets with limited available space.

The NXPP-03C 64008544 facilitates communication between field devices and control systems through an RS-485 interface . This enables efficient data exchange between drives and higher-level automation networks, supporting reliable integration with ABB drive platforms and ensuring consistent system performance in demanding applications . The NXPP-03C 64008544 enhances diagnostic visibility, allowing operators to monitor system status and quickly identify communication issues, and supports stable operation even in electrically noisy environments commonly found in industrial facilities.

The NXPP-03C 64008544 ABB Control Distribution Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

ABB NXPP-03C 64008544 Control Distribution Board Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB NXPP-03C 64008544 Control Distribution Board Specs

General

  • Manufacturer ABB
  • Model NXPP-03C 64008544
  • Condition New Original ready stock
  • Product Family NXPP-02C,NXPP-01,NXPP-01C
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Heavy-Duty AC Drives: It is a standard internal component for the legacy ABB ACS600 Drive Series, specifically within large ACS600 Multidrive topologies where multiple inverters share a common DC bus.
  • Liquid-Cooled Marine & Industrial Drives: It is widely deployed in ABB ACW600 liquid-cooled drive enclosures (e.g., ACW6345, ACW6441), managing complex multi-phase power modules in tight spaces.
  • Heavy Industry Motor Control: It orchestrates dynamic speed and torque control for mega-watt class motors operating in metals rolling mills, mining winders, paper machine sections, and maritime propulsion thrusters.
  • Fiber-Optic Communication Links: It incorporates onboard fiber-optic terminal ports (using proprietary ABB PPCS/DDCS protocols) to guarantee immunity against massive electromagnetic interference (EMI) generated by switching power semiconductors.
  • Gate Driver Integration: It distributes firing pulse patterns directly to the downstream ABB NGDR-03C Gate Driver Boards, which handle the physical gating of high-power IGBT (Insulated Gate Bipolar Transistor) modules.
  • Internal Bus Architecture: It acts as a bridge connecting the drive's primary control interface—such as the NINT Main Interconnection Board or SMIO Main I/O Board—to distribute critical timing data, voltage readings, and thermal status alerts synchronously across all converter phases.
  • Environmental Resilience (Coating): The "C" suffix in NXPP-03C indicates that the printed circuit board (PCB) features a rugged Conformal Coating. This meets compliance standards for harsh industrial environments, shielding internal tracks against conductive dust, moisture condensation, and corrosive chemical vapors.
  • Galvanic & Optical Isolation: The design enforces absolute galvanic isolation via optical channels. This separates the low-voltage micro-control circuits from the lethal, high-power DC bus voltage (often exceeding 690V to 1000V+), preventing feedback faults from frying the entire automation rack.
  • CE & Industrial Directives: As part of the ACS600 system ecosystem, the assembly aligns with European Low Voltage Directive (LVD) and EMC Directive requirements, provided the cabinet is grounded and shielded according to ABB's official installation guidelines.
Description
The ABB NXPP-03C 64008544 is a control distribution board designed for ABB industrial drive systems, particularly the ACS 600 and ACC 600 MultiDrive modules . This board serves as a central hub for power and signal management within control panels, helping organize inputs/outputs and distribute control logic to industrial devices such as PLCs, relays, and actuators . The NXPP-03C 64008544 ensures reliable operation in demanding industrial environments.

The ABB NXPP-03C 64008544 operates on a nominal 24V DC input with on-board rails providing +5V DC at 6A, and features 500V DC rail-to-earth isolation for robust noise immunity. The NXPP-03C 64008544 operates from 0°C to +60°C and can be stored from -40°C to +85°C with 5-95% non-condensing humidity.


The ABB NXPP-03C 64008544 facilitates communication between field devices and control systems through an RS-485 interface, enabling efficient data exchange between drives and higher-level automation networks . The NXPP-03C 64008544 enhances diagnostic visibility, allowing operators to monitor system status and quickly identify communication issues . The NXPP-03C 64008544 supports stable operation even in electrically noisy environments commonly found in industrial facilities.

The ABB NXPP-03C 64008544 is classified under tariff code 8537101190 . The NXPP-03C 64008544 is available as a brand new, original, unused, and factory-sealed product The NXPP-03C 64008544 is an essential component for maintaining and upgrading ABB ACS600 and ACC600 drive systems in power generation, manufacturing, and process industries.
Alternative Names
NXPP-O3C 64OO8544 NXPP-03C 64008544 NXPP-02C NXPP-01C NGDR-03C NINT-71C SMIO-01C
Technical notes
The ABB NXPP-03C 64008544 is a control distribution board for ACS600/ACC600 drives. It features 24V DC input, +5V at 6A rails, 500V isolation. Operates 0°C to +60°C. Essential for power/signal distribution in larger MultiDrive frames.
