SDCS-CON-3A

/ 4.9
1001 reviews | Need a Specific Revision?
The SDCS-CON-3A is a reliable control board for ABB DCS800 drives, managing logic, I/O, and protective functions with high isolation and broad environmental tolerance.
Get a quick price for SDCS-CON-3A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SDCS-CON-3A

  • Manufacturer:
    ABB
  • Part Number:
    SDCS-CON-3A
  • Product Family:
    ABB Drives
  • Supply Voltage:
    24 V DC (±15%)
  • Power Consumption:
    Typical 20–40 W depending on module type and connected I/O
  • Isolation:
    1500 V AC between control circuits and I/O / power interface
  • Operating Temperature:
    0°C … +50°C (free air circulation)
  • Storage Temperature:
    -40°C … +85°C
  • Humidity:
    5–95% RH, non-condensing
  • Mounting:
    DIN-rail or chassis mounting inside DCS800 cabinet
  • Weight:
    0.35 kg
  • Estimated shipping dimensions:
    24.6x24.2x2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The ABB SDCS-CON-3A is a core control board for the DCS800 series drives, responsible for managing logic operations, monitoring I/O modules, and coordinating protective functions.  It provides stable 24 V DC operation with robust isolation up to 1500 V AC between control circuits and power/I/O interfaces, ensuring safe and reliable performance in industrial environments.

Designed for flexible installation, the board supports DIN-rail or chassis mounting inside the DCS800 cabinet.  It operates efficiently with typical power consumption of 20–40 W, handling diverse module types and connected I/O.  The SDCS-CON-3A functions reliably across a wide environmental range, from 0°C to 50°C operating temperature and 5–95% relative humidity.

Compatible with SDCS-PIN series and I/O expansion modules, the SDCS-CON-3A integrates seamlessly into DCS800 systems, providing precise control and data acquisition for industrial automation applications.
Alternative Names
SDCS-C0N-3A SDCSCON3A SDCSC0N3A
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the supply voltage for the SDCS-CON-3A?
The board operates on 24 V DC with a ±15% tolerance.
How much power does the SDCS-CON-3A consume?
Typical power consumption is 20–40 W, depending on module type and connected I/O.
What is the isolation rating?
The control circuits are isolated from I/O and power interfaces up to 1500 V AC.
What is the operating temperature range?
The board operates between 0°C and +50°C under free air circulation
Which systems is it compatible with?
It is designed for ABB DCS800 series drives and works with SDCS-PIN and I/O expansion boards.
