SDCS-IOE-2C

/ 4.9
1001 reviews | Need a Specific Revision?
ABB SDCS-IOE-2C is a UC measurement board from the SDCS-IOE-2 family documented for use in a Thyristor Supply Unit.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for SDCS-IOE-2C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SDCS-IOE-2C

  • Manufacturer:
    ABB
  • Part Number:
    SDCS-IOE-2C
  • Product Family:
    ABB Drives
  • Product Type:
    UC Measurement Board
  • Stock:
    1
  • Official Base Designation:
    SDCS-IOE-2
  • Board Function:
    UC Measurement Board
  • System Application:
    TSU (Thyristor Supply Unit)
  • Measurement Channels:
    Two analogue measurement channels
  • Measured Quantities:
    Measured Quantities
  • Measurement Method:
    U/f conversion and counters
  • Reference Adjustment:
    R2 adjusts the +10 V reference at MP1 and MP2; factory set
  • Signal Isolation:
    +UC and -UC actual-voltage signals are not galvanically isolated
  • UC Measurement Path:
    Via SDCS-UCM-1 resistor board
  • Supply Voltage Measurement Path:
    Via SDCS-PIN-51 and SDCS-CON-1
  • Tariff Code:
    9030900090
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Identity TSU Matching Application
  • Complete supplied identity is SDCS-IOE-2C
  • ABB defines the SDCS-IOE-2 base family as a UC measurement board
  • The documented base-board role is within a Thyristor Supply Unit
ABB SDCS-IOE-2C belongs to an SDCS measurement-board family referenced in official ABB drive documentation.

The official base designation establishes the UC measurement function and TSU context, but it does not establish interchangeability for every suffix.

Match the complete 2C label, host unit, board position, connectors, and system drawing before selecting a replacement.

Availability, condition, price, and shipping time for SDCS-IOE-2C are confirmed during quotation.

ABB SDCS-IOE-2C UC Measurement Board Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use the full SDCS-IOE-2C label as the ordering identity
  • Keep the 2C suffix when comparing installed and replacement boards
  • Do not substitute another SDCS board designation as an alternative name
  • ABB identifies the SDCS-IOE-2 base family as a UC measurement board
  • The base board is documented for use in a Thyristor Supply Unit
  • The exact host-unit hardware documentation controls replacement selection
  • Record the board position and every connector before removal
  • Match the host TSU or converter type to the applicable system drawing
  • Verify board identification and cable markings before energizing the system
  • UC measurement-board service in a documented ABB Thyristor Supply Unit
  • Replacement where the installed board carries the complete SDCS-IOE-2C identity
  • Converter maintenance performed with the matching ABB system drawing
Description
ABB SDCS-IOE-2C is identified from the SDCS-IOE-2 UC measurement-board family referenced in ABB drive documentation.

ABB defines the SDCS-IOE-2 base designation as a UC measurement board used in a Thyristor Supply Unit, while the verified material does not separately define the 2C suffix.

Before replacement, match the complete board label and confirm the TSU hardware, board location, connector arrangement, wiring, and system drawing for the installed converter.
Alternative Names
SDCS-IOE-2C SDCSIOE2C SDCS IOE 2C ABB SDCS-IOE-2C ABB Drives SDCS-IOE-2C SDCS-IOE-2C UC Measurement Board ABB SDCS IOE 2C SDCS-IOE-2C TSU Measurement Board
Technical notes
SDCS-IOE-2C must be matched by the complete suffix. Verify the TSU type, installed board label, connector arrangement, wiring, board location, and applicable ABB system drawing.
