SPAM150C SPAM150C-AA

/ 4.9
1001 reviews | Need a Specific Revision?
ABB SPAM150C SPAM150C-AA is the 50 Hz, 80 to 265 V AC/DC auxiliary-supply version of the SPAM 150 C multifunction motor protection relay with a make-type trip contact.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for SPAM150C SPAM150C-AA
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SPAM150C SPAM150C-AA

  • Manufacturer:
    ABB
  • Part Number:
    SPAM150C SPAM150C-AA
  • Product Family:
    ABB Electrical
  • Product Type:
    Motor Protection Relay, 50 Hz, 80–265 V AC/DC Auxiliary Supply
  • Stock:
    1
  • Official type:
    SPAM 150 C
  • Trip contact:
    Make / normally open
  • Rated frequency:
    50 Hz
  • Auxiliary supply:
    80 to 265 V AC/DC
  • Communication:
    SPA serial bus
  • Front protection:
    IP54 when correctly panel mounted
  • Dimensions:
    14.2 × 16.2 × 25.0 cm
  • Panel cut-out:
    12.9 × 13.9 cm
  • Tariff Code:
    8536490090
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Protection Scope Ordering Identity Replacement Work Application
  • AA suffix: 50 Hz with 80 to 265 V AC/DC auxiliary supply
  • RS 641 014-AA with a make-type normally open trip contact
  • SPA serial communication and IP54 front protection when correctly panel mounted

The SPAM150C SPAM150C-AA suffix identifies the circuit-breaker-drive version of the SPAM 150 C motor protection relay.

Its protection functions include thermal overload, high-set overcurrent, phase unbalance, phase sequence, earth fault, undercurrent and start supervision.

Before replacement, preserve relay settings, current-transformer ratios, trip logic, SPA communication parameters and the exact AA auxiliary-supply configuration.

Availability, condition, price, and shipping time for SPAM150C SPAM150C-AA are confirmed during quotation.

ABB SPAM150C SPAM150C-AA Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Coordinate thermal, start, phase and earth-fault protection with the motor
  • Use the current-transformer and earth-fault connection documented for the scheme
  • Confirm that trip, alarm and restart logic match the plant protection philosophy
  • Match suffix AA with 50 Hz and 80 to 265 V AC/DC auxiliary supply
  • Confirm order number RS 641 014-AA and the make-type trip contact
  • Do not substitute break-contact suffixes without reviewing the trip circuit
  • Export settings, event records and SPA communication parameters before removal
  • Verify panel cut-out, terminal map and auxiliary voltage before energizing
  • Test trip, alarm, self-supervision and communication paths before service
  • Circuit-breaker-controlled medium and large three-phase AC motor drives
  • ExE motor drives requiring start-up supervision through the external control input
  • Single-, two- or three-phase feeder or transformer protection requiring overcurrent, overload and non-directional earth-fault functions
Description
ABB SPAM150C SPAM150C-AA is the 50 Hz, 80 to 265 V AC/DC auxiliary-supply version of the SPAM 150 C multifunction motor protection relay with a make-type trip contact.

Selection and replacement must follow the exact SPAM150C SPAM150C-AA official data, wiring and accessory requirements.

Before commissioning, verify identity, installation, configuration, protection behavior and the connected field circuit.
Alternative Names
SPAM150C SPAM150C-AA SPAM150C AA RS641014-AA RS 641 014-AA ABB SPAM150C-AA ABB SPAM 150 C-AA ABB RS 641 014-AA SPACOM SPAM150C ABB SPACOM SPAM150C ABB SPACOM SPAM 150 C
Technical notes
Official drawings support the listed relay-case dimensions. No exact complete-product net weight was found; Weight remains blank.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What makes ABB SPAM150C SPAM150C-AA different from the other SPAM 150 C suffixes?
Suffix AA identifies the 50 Hz, 80 to 265 V AC/DC auxiliary-supply version with a make-type normally open trip contact.
Can ABB SPAM150C SPAM150C-AA replace an AB, CA, DA or FA suffix without review?
No. Frequency, auxiliary-supply range and trip-contact form are encoded by the suffix and must match the existing protection and trip circuit.
What must be saved before replacing ABB SPAM150C SPAM150C-AA?
Record every protection setting, CT and earth-fault arrangement, motor start data, trip and alarm outputs, SPA address and communication settings, events and active bypasses.
Why can ABB SPAM150C SPAM150C-AA trip during a normal motor start?
Check the start-time supervision, thermal history, high-set threshold, CT ratio, measured phase balance and whether the motor acceleration time has changed.
Why can earth-fault indication appear on ABB SPAM150C SPAM150C-AA after rewiring?
Verify the residual or core-balance CT connection, polarity, grounding, cable routing and earth-fault setting; incorrect CT summation can create false residual current.
Can ABB SPAM150C SPAM150C-AA be replaced by a newer relay using settings alone?
No. A retrofit must also reproduce CT inputs, auxiliary supply, trip-contact behavior, panel mechanics, output logic, communication and the complete protection study.
How should ABB SPAM150C SPAM150C-AA be accepted after installation?
Perform secondary-injection tests for each enabled function, verify make-contact tripping and alarm outputs, prove self-supervision and SPA communication, and document reset and restart behavior.
