917-0050

/ 4.9
1001 reviews | Need a Specific Revision?
ABB / MEDAR 917-0050 is a resistance-welding processor module used within a documented Medar control system.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 917-0050
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 917-0050

  • Manufacturer:
    ABB
  • Part Number:
    917-0050
  • Product Family:
    ABB Electrical
  • Product Type:
    Resistance-Welding Processor Module
  • Stock:
    1
  • Required System Elements:
    Processor module, firing card, current-monitoring coil, interface cable, and software
  • Interface Cable:
    205-1212Vx family documented
  • Programming Software:
    T93300 base software with documented processor modules
  • Standard Maximum Weld Time:
    5 seconds
  • Standard Maximum Duty Cycle:
    33%
  • Tariff Code:
    8537109090
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals System Match Software Weld Control Application
  • Resistance-welding processor for a multi-component Medar control arrangement
  • Works with documented firing-card and current-monitoring hardware
  • Uses documented programming software and 205-1212Vx interface cabling

917-0050 is an ABB / MEDAR Resistance-Welding Processor Module designed for a Medar resistance-welding control system.

The processor coordinates weld schedules, firing commands, and current feedback within a multi-component resistance-welding control system.

Before installation or replacement, identify every companion part, preserve the weld database, and verify load-resistor and duty-cycle requirements before returning the welder to service.

Availability, condition, price, and shipping time for 917-0050 are confirmed during quotation.

MEDAR 917-0050 MedWeld 3005 Resistance-Welding Processor Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Verify the documented installed rack arrangement
  • Match the processor to the specified firing card
  • Match the current-monitoring coil and interface cable to the installed system
  • Use the documented T93300 base software environment
  • Confirm the processor-specific software module
  • Back up weld schedules and calibration values before service
  • Observe the documented standard maximum weld time
  • Review duty cycle and load-resistor requirements
  • Validate firing output and current feedback under controlled conditions
  • Resistance spot-welding systems
  • Automotive weld-cell controls
  • Industrial SLC 500-based weld sequencing and current control
Description
917-0050 is an ABB / MEDAR Resistance-Welding Processor Module for a Medar resistance-welding control system.

The documented system combines the processor with a firing card, current-monitoring coil, interface cable, and T93300-series programming software for weld sequencing and current control.

Before installation or replacement, confirm the installed rack, firing-card and current-coil part numbers, interface cable, selected programming software, load resistor, and stored weld schedules.
Alternative Names
917-0050 ABB 917-0050 ABB MEDAR 917-0050 MEDAR 917-0050 Welding Technology Corporation 917-0050 Medar 9170050
Technical notes
ABB / MEDAR 917-0050 requires its firing card, current coil, interface cable, software, rack arrangement, and saved weld schedules to be verified before replacement; partial system matching is the principal compatibility risk.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can ABB / MEDAR 917-0050 be replaced without checking the rest of the weld-control cabinet?
No. Identify the installed firing card, current-monitoring coil, interface cable, rack arrangement, and stored weld data before selecting a replacement. The processor is only one part of the documented control system.
What should be backed up before changing ABB / MEDAR 917-0050?
Save the weld schedules, calibration values, I/O assignments, firing settings, current-feedback configuration, interlocks, and the associated software records so the machine can be restored and verified safely.
Does ABB / MEDAR 917-0050 need the original firing card and current coil?
It must be matched to the system components documented for the installation. Do not assume an unrelated firing card or coil is interchangeable.
What limits should be reviewed when applying ABB / MEDAR 917-0050?
Review the documented weld-time and duty-cycle limits together with the selected load resistor and the full machine duty. The processor must be verified in the actual control arrangement, not in isolation.
Why does ABB / MEDAR 917-0050 need a rack and power check before replacement?
The processor works within an installed rack and companion-module arrangement, so verify slot, backplane, supply, wiring, and saved control-program context before applying power.
What proves ABB / MEDAR 917-0050 is ready to return to service?
Controlled tests should verify schedule selection, firing output, current feedback, interlocks, fault reporting, and actual weld-current behavior before production release.
When should ABB / MEDAR 917-0050 be rejected as a replacement candidate?
Do not install it when the cabinet identification, companion hardware, software, or saved weld data cannot be matched. Resolve those differences before energizing the weld-control system.
