ABB DCP10 is a high-performance Freelance rack controller that supports single-controller or redundant process-station configurations.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for DCP10
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DCP10

  • Manufacturer:
    ABB
  • Part Number:
    DCP10
  • Product Family:
    ABB H&B Freelance 2000
  • Product Type:
    redundancy-capable rack-based process controller
  • Stock:
    1
  • Processor:
    Intel 80960HD
  • Clock frequency:
    50 MHz
  • Performance:
    100 MIPS
  • Application memory:
    8 MB static RAM
  • Memory architecture:
    32 bit, battery backed, with error detection and correction
  • Communication coprocessors:
    Two Intel 82596CA devices
  • Ethernet media:
    10Base5, 10Base2 and 10BaseFL
  • Serial 1 modes:
    RS485 half duplex, RS422 full duplex or RS232C full duplex
  • Serial bus capacity:
    Up to 32 nodes in RS485 mode
  • Serial speed:
    19,200 baud
  • RS232 cable length:
    15 m maximum
  • RS422 cable length:
    1200 m maximum
  • Redundancy:
    Supports redundant CPU configuration
  • Binary commands:
    Less than 1 ms per 1000 commands
  • Fixed-point commands:
    Less than 1.5 ms per 1000 commands
  • Floating-point commands:
    Less than 1.5 ms per 1000 commands
  • EEPROM:
    16 Kbit; at least 10 million write cycles; at least 10 years retention
  • Watchdog response:
    1.6 s maximum
  • Battery service life:
    More than 1.5 years
  • Hot replacement:
    Permitted
  • Typical power consumption:
    10.4 W
  • Maximum power consumption:
    14 W
  • Dimensions:
    4 × 20.2 × 31 cm
  • Weight:
    2 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Redundant Control Communications Takeover Planning Application
  • Fast rack CPU for engineered Freelance control applications
  • Supports coordinated primary and secondary controller operation
  • Provides system-network and configurable serial communication

DCP10 provides the processing and communication resources for single or redundant classic Freelance rack stations.

In a redundant arrangement, the paired controllers coordinate application state so the standby unit can assume control under the documented takeover strategy.

Confirm the station role, synchronized project, network medium, serial mode and peer-controller status before commissioning a replacement.

Availability, condition, price, and shipping time for DCP10 are confirmed during quotation.

ABB DCP10 redundancy-capable rack-based process controller Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The controller can participate in an engineered primary and secondary CPU arrangement.
  • Both controllers must carry compatible application and hardware configuration data.
  • Takeover acceptance depends on verified synchronization and process continuity.
  • System Ethernet and serial resources are assigned through the station configuration.
  • Serial electrical mode must match the installed topology and connected equipment.
  • Restoration includes checking addressing, media, termination and every required communication partner.
  • The operating controller must remain capable of carrying the process during a controlled exchange.
  • The replacement role is established before it is allowed to synchronize with its peer.
  • A documented transfer test confirms that outputs and communications remain stable.
  • Redundant process-control stations
  • High-speed IEC 61131-3 application execution
  • Classic Freelance rack and network coordination
Description
DCP10 is an ABB Freelance rack CPU designed for fast application execution and for controller redundancy where the engineered station requires it.

Two communication processors, battery-backed application memory and selectable serial standards allow the controller to coordinate rack I/O, system networking and external serial devices.

Replacement planning must preserve the primary or secondary role, peer-controller relationship, project image, network interfaces, serial electrical standard and takeover configuration.
Alternative Names
DCP10 DCP 10 ABB DCP10 ABB DCP 10 Y0338701M DCP10 Y0338701M
Technical notes
DCP10 replacement requires matching firmware, Control Builder F project, redundancy role, Ethernet medium, serial mode and synchronized peer status; an incorrect role or network setup can interrupt process control.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What must match when ABB DCP10 is installed in a redundant controller pair?
The controller type, firmware, project image, rack configuration, network resources and designated primary or secondary role must agree across the engineered pair.
How should takeover be tested after replacing ABB DCP10?
Use the approved station procedure to verify synchronization, process-value continuity, output behavior, communication status and bumpless transfer before redundancy is accepted.
Which communication media can affect ABB DCP10 replacement compatibility?
Confirm the installed 10Base5, 10Base2 or 10BaseFL Ethernet path and the configured serial electrical standard; connectors alone do not prove equivalent communication setup.
Can the serial interface on ABB DCP10 be changed between RS232, RS422 and RS485 without project changes?
No. Electrical mode, topology, termination, address and cable limits must be reconciled with the hardware configuration and every connected device.
What information must be preserved from ABB DCP10 battery-backed memory?
Retain a verified engineering backup and record operating data needed by the application; battery retention is not a substitute for a recoverable project image.
Can ABB DCP10 be hot-replaced in a running redundant station?
The hardware supports replacement, but the active/standby role, synchronization state and plant procedure must be controlled so the remaining controller safely carries the process.
Why should ABB DCP10 performance settings be reviewed after restoration?
Its fast execution and rack cycles serve the engineered task schedule. Confirm program timing, I/O cycles and communication loads before declaring the replacement operational.
