ABB ECC 086387-001 is an End Column Color printed wiring assembly for an ABB Accuray quality-control-system installation, with RX, RTS, ERROR and RUN front indicators.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for ECC 086387-001
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ECC 086387-001

  • Manufacturer:
    ABB
  • Part Number:
    ECC 086387-001
  • Product Family:
    ABB MOD 300 and MOD 30ML/MODCELL
  • Product Type:
    End Column Color Printed Wiring Assembly
  • Stock:
    1
  • ABB Product Description:
    PWA, ECC, END COLUMN COLOR
  • Front Indicators:
    RXA, RXB, RTSA, ERROR, RUN, RTSB
  • Module Format:
    Plug-in rack printed wiring assembly
  • Front Panel Format:
    Narrow metal faceplate with status window
  • Rear Interface:
    Multipin rack connector
  • Dimensions:
    2.1 × 13.1 × 26.2 cm
  • Weight:
    0.22 kg
  • Tariff Code:
    7326199000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Board Construction Front Indicators Replacement Application
  • End Column Color printed wiring assembly identified by complete number 086387-001
  • Separate RXA, RXB, RTSA, and RTSB communication-status indications
  • Dedicated ERROR and RUN indicators for operating-state observation

ECC 086387-001 is an ABB End Column Color printed wiring assembly designed for an installed Accuray quality-control-system rack.

The assembly provides front-panel communication and operating-state indications for its documented end-column position within the control system.

Before installation or replacement, verify the complete 086387-001 assembly number, board revision, faceplate arrangement, connector keying, rack position, communication paths, and applicable QCS drawings.

Availability, condition, price, and shipping time for ECC 086387-001 are confirmed during quotation.

ABB ECC 086387-001 End Column Color Printed Wiring Assembly Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Plug-in printed wiring assembly fitted with a narrow metal front faceplate
  • Component-populated circuit board designed for installation in the documented QCS rack position
  • Multipin rear connector providing the electrical interface to the installed rack assembly
  • Separate front-panel indicators labeled RXA and RXB
  • Separate front-panel indicators labeled RTSA and RTSB
  • Dedicated ERROR and RUN indicators for operating-state observation
  • Record the complete RXA, RXB, RTSA, RTSB, ERROR, and RUN indication pattern before removal
  • Match the 086387-001 connector keying, board revision, and documented rack position
  • Follow the installed Accuray wiring and communication documentation during replacement
  • End-column color-system interface within an installed ABB quality-control system
  • Communication-status monitoring for the documented A and B signal paths
  • Operating-state and fault indication for the installed end-column color assembly
Description
ABB ECC 086387-001 is a End Column Color Printed Wiring Assembly. ABB ECC 086387-001 is an End Column Color printed wiring assembly for an ABB Accuray quality-control-system installation, with RX, RTS, ERROR and RUN front indicators.

For replacement work, confirm the complete model identity, installed slot or mounting context, connector and terminal arrangement, power requirements, configuration and site drawings before energization.

Apter supports legacy automation spares, technical cross-reference and replacement planning. Availability and configuration should be confirmed against the installed unit.
Alternative Names
ECC 086387-001 ECC086387-001 ECC 086387 001 ABB ECC 086387-001 086387-001 ECC ABB 086387-001 PWA ECC End Column Color 086387-001
Technical notes
ECC 086387-001 replacement requires the exact assembly number, faceplate indicator map, rack position, connector keying, board revision, and Accuray system drawings.
