    For ABB CP651-WEB 1SAP551200R0001, Apter Power offers quotations, manuals, and model matching.

CP651-WEB 1SAP551200R0001

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB CP651-WEB 1SAP551200R0001 is a 10.4-inch CP600 control panel that displays an AC500 V2.3 web server through its embedded micro-browser.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for CP651-WEB 1SAP551200R0001
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CP651-WEB 1SAP551200R0001

  • Manufacturer:
    ABB
  • Part Number:
    CP651-WEB 1SAP551200R0001
  • Product Family:
    ABB Operator Panel
  • Product Type:
    10.4-Inch CP600 Web Control Panel
  • Stock:
    1
  • Display:
    10.4-inch TFT LCD
  • Resolution:
    800x600 pixels
  • Colors:
    65,536
  • Brightness:
    300 cd/m²
  • Backlight:
    LED; 40,000 h at 25 °C
  • Touchscreen:
    4-wire resistive single-touch
  • Processor:
    ARM Cortex-A8, 1 GHz
  • Operating System:
    Windows Embedded CE 6.0 Core
  • RAM:
    256 MB
  • Flash Memory:
    256 MB
  • HMI Project Memory:
    Up to 60 MB
  • Removable Storage:
    SD card
  • Ethernet 0:
    10/100 Mbit/s with integrated switch
  • Ethernet 1:
    10/100 Mbit/s
  • Serial Port:
    COM1 configurable as RS-232/RS-485/RS-422
  • USB Interfaces:
    USB 2.0 host and USB 2.0/1.1 device
  • Supply Voltage:
    18–32 V DC
  • Current Consumption:
    1.0 A
  • Front Protection:
    IP66
  • Rear Protection:
    IP20
  • Operating Temperature:
    0 to +50 °C
  • Storage Temperature:
    -20 to +70 °C
  • Operating Humidity:
    5–85%, non-condensing
  • Maximum Altitude:
    2000 m
  • Panel Cutout:
    276x221 mm
  • Weight:
    4.63 lbs (2.1 kg)
  • Estimated shipping dimensions:
    28.7x23.2x6cm
  • Tariff Code:
    8537109090
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Web Display Port Roles Memory Paths Panel Envelope

Features:

  • ABB CP651-WEB 1SAP551200R0001 presents AC500 V2.3 web visualization on a 10.4-inch touch display.
  • Dual Ethernet, configurable serial communication and two USB roles provide separate connection paths.
  • The IP66 front and IP20 rear divide operator-side protection from the cabinet interior.
The resistive touch layer accepts operator input for pages rendered by the embedded micro-browser rather than acting as a passive display.

Processor, RAM, flash and SD storage keep the browser environment, runtime data and removable files on distinct memory resources.

Portrait or landscape mounting uses the same cutout while the rear electronics remain inside the specified temperature and humidity envelope.

The ABB CP651-WEB 1SAP551200R0001 10.4-Inch CP600 Web Control Panel may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB CP651-WEB 1SAP551200R0001 10.4-Inch CP600 Web Control Panel Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

How browser pages reach the operator

  • Web source: The panel is defined for visualization served by an AC500 V2.3 controller.
  • Rendering path: The embedded micro-browser converts the controller pages into the local display image.
  • Operator input: The four-wire resistive layer returns single-touch actions to the displayed interface.
  • Visible area: An 800x600 color TFT provides the documented 10.4-inch workspace.

Separating network, serial and service connections

  • Ethernet 0: The first 10/100 port connects through an integrated switch.
  • Ethernet 1: The second 10/100 port provides a separate network interface.
  • COM1: Software selection assigns RS-232, RS-485 or RS-422 electrical operation to the D-sub port.
  • USB roles: Host and device ports separate peripheral attachment from the documented device connection.

Where runtime and project resources are held

  • Working memory: The ARM processor uses 256 MB of RAM while running the panel environment.
  • Internal storage: The 256 MB flash area holds the operating environment and local data.
  • Project allocation: Up to 60 MB of flash is available for HMI project content.
  • Removable storage: The SD-card interface provides a separate medium from internal flash.

Coordinating cutout, orientation and enclosure protection

  • Cabinet opening: The mounting surface requires the documented 276x221 mm cutout.
  • Orientation: The panel can be mounted in landscape or portrait position.
  • Front seal: Correct installation places the IP66 face toward the operator environment.
  • Rear housing: The IP20 electronics remain inside the cabinet with clearance for the 56 mm housing depth.
Description
Web visualization for an AC500 V2.3 controller is the defined role of ABB CP651-WEB 1SAP551200R0001, a CP600 classic control panel with a 10.4-inch 800x600 color TFT. Its four-wire resistive touch surface provides the operator input path for the pages rendered by the embedded micro-browser.

An ARM Cortex-A8 processor running at 1 GHz executes the Windows Embedded CE 6.0 Core environment in CP651-WEB 1SAP551200R0001. The panel combines 256 MB of RAM with 256 MB of flash memory, supports SD storage, and assigns up to 60 MB of the flash area to HMI projects.

Two 10/100 Ethernet ports give CP651-WEB 1SAP551200R0001 separate network connections, with Ethernet 0 operating through an integrated switch. COM1 can be configured as RS-232, RS-485 or RS-422, while the USB host and USB device interfaces support the documented peripheral and service connections.

A nominal 24 V DC supply powers CP651-WEB 1SAP551200R0001 through the specified 18–32 V DC range and reverse-polarity protection. The aluminum panel mounts in portrait or landscape orientation, places its IP66-rated face toward the operator, and leaves the IP20 rear housing inside the enclosure.

Operation of CP651-WEB 1SAP551200R0001 is limited to 0–50 °C, 5–85% non-condensing humidity and installations up to 2000 m. The cutout, mounting orientation and rear clearance must therefore be coordinated with both the cabinet opening and the documented environmental limits.
Alternative Names
CP651WEB 1SAP551200R0001 CP651 WEB 1SAP551200R0001 ABB CP651-WEB ABB 1SAP551200R0001 1SAP551200R0001 CP651 WEB CP65I-WEB 1SAP551200R0001 CP651-WEB CP600 Panel ABB CP651 WEB HMI
Technical notes
ABB CP651-WEB 1SAP551200R0001 combines a CP600 10.4-inch touch panel with dual Ethernet, configurable serial communication, and an AC500 V2.3 web micro-browser.
