The ABB HESG447307R1 70EA01B-ES is an analog signal input module designed for the ABB Procontrol P13 distributed control system. It is used for accurate acquisition of process signals in power plants and large-scale industrial automation systems, supporting multiple analog input types with high precision and HART communication capability.
Get a quick price for HESG447307R1 70EA01B-ES
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for HESG447307R1 70EA01B-ES

  • Manufacturer:
    ABB
  • Part Number:
    HESG447307R1 70EA01B-ES
  • Product Family:
    ABB Procontrol
  • Current Inputs:
    0–20 mA / 4–20 mA
  • Voltage Inputs:
    ±10 V DC, 1–5 V DC
  • Voltage Inputs:
    Supports HART communication
  • Accuracy:
    ±0.1% of span
  • Sampling Frequency:
    >300 scans/sec
  • Input Impedance:
    250 Ω for current
  • Group isolation:
    200 V RMS
  • Inter-track isolation:
    250 V RMS continuous
  • Temp Range:
    -25°C - +70°C
  • Relative Humidity:
    ≤95% (non-cond)
  • Weight:
    0.42 kg
  • Estimated shipping dimensions:
    3.3x20x14.6cm
  • Tariff Code:
    5911400000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Flexibility Monitoring

Features:

  • Supports multiple analog inputs: 0–20 mA, 4–20 mA, ±10 V DC, and 1–5 V DC
  • High accuracy measurement with ±0.1% of span and HART communication support
  • Strong electrical isolation design with high-speed sampling capability
The ABB HESG447307R1 70EA01B-ES is an analog input module designed for the ABB Procontrol P13 distributed control system. It is widely used in power generation plants and large-scale industrial automation environments. The ABB HESG447307R1 70EA01B-ES enables accurate acquisition of analog signals from field devices, ensuring stable and reliable process monitoring. Its support for both current and voltage inputs makes it compatible with a wide range of industrial sensors and transmitters. Overall, it plays a key role in maintaining precise data flow within control systems.

The ABB HESG447307R1 70EA01B-ES offers high precision signal processing with ±0.1% accuracy, making it suitable for critical measurement applications. It also supports HART communication, allowing smart field devices to exchange diagnostic and configuration data with the control system. This enhances system transparency and improves maintenance efficiency. The module’s high sampling rate ensures rapid response to process changes. As a result, the ABB HESG447307R1 70EA01B-ES is well-suited for demanding industrial automation environments.

The ABB HESG447307R1 70EA01B-ES is designed for stable operation in harsh industrial conditions, with a temperature range of -25°C to +70°C and high humidity tolerance. It incorporates strong electrical isolation to reduce interference and improve system reliability. Compared with earlier Procontrol P13 analog input modules, the ABB HESG447307R1 70EA01B-ES provides enhanced sampling performance and improved signal integrity. Its robust design ensures long-term stability in continuous operation systems. This makes it a reliable choice for power plants and process industries.

The HESG447307R1 70EA01B-ES ABB Analog Signal Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB HESG447307R1 70EA01B-ES Analog Signal Input Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB HESG447307R1 70EA01B-ES Analog Signal Input Module Specs

General

  • Manufacturer ABB
  • Model HESG447307R1 70EA01B-ES
  • Condition New Original ready stock
  • Product Family 70BK03-ES HESG440640R2,70BV01-ES HESG441614R1,70BT01C HESG447024R1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Power Plant Control: As a core component of the ABB Procontrol P13 system, it is used in the distributed control system (DCS) of power plants.
  • Signal Acquisition: Responsible for acquiring standard analog signals from field sensors (such as pressure and temperature transmitters) and converting them into data that the system can process.
  • Motor Protection: In automated production lines, its high-precision current/voltage monitoring function provides overload and phase loss protection for large motors.
  • Process Industries: Widely used in industrial environments such as chemical and oil and gas industries that require precise closed-loop control of process parameters.
  • Software Configuration: No need for manual jumper switching; all parameter settings can be completed through the dedicated P13 Configurator tool.
  • Address Assignment: Supports non-contiguous addressing of input channels, facilitating system logic optimization without changing existing physical wiring.
  • Forced Output: Allows forced input value setting at the board level, greatly simplifying logic verification after system upgrades or overhauls.
  • Plug and Replace: Designed with backward compatibility in mind, it can be used as a direct replacement for older models for expansion or maintenance.
  • Status Transmission: Transmits data to the station-level bus in real time via the bus interface, ensuring the host computer can obtain the latest field dynamics.
  • Fault Self-Check: Possesses comprehensive unit self-monitoring functions; any abnormality within the module or channel will immediately trigger a disturbance alarm.
  • Remote Management: Can be connected to PROFIBUS or Modbus networks with the communication module, enabling centralized monitoring of remote equipment from the control room.
  • Real-Time Response: Employs a high-speed processing architecture, ensuring that changes in key process parameters are fed back to the controller with millisecond-level latency.
Description
The ABB HESG447307R1 70EA01B-ES analog input module is part of the ABB Procontrol P13 DCS platform, widely applied in power generation and heavy industrial process control. It is designed to collect and process analog signals from field instruments, converting them into stable control data for distributed automation systems. The ABB HESG447307R1 70EA01B-ES supports multiple input types, including 0–20 mA and 4–20 mA current signals as well as ±10 V DC and 1–5 V DC voltage signals, enabling flexible integration with different field devices.

The ABB HESG447307R1 70EA01B-ES provides high measurement accuracy of ±0.1% of span, ensuring reliable signal acquisition for critical industrial processes. It also supports HART communication, allowing digital communication with smart field instruments for enhanced diagnostics and configuration. With an input impedance of 250 Ω for current signals, the module ensures stable signal conversion and minimal distortion during operation.

In terms of performance, the ABB HESG447307R1 70EA01B-ES supports a sampling frequency greater than 300 scans per second, enabling fast and responsive data acquisition. It also features strong electrical isolation, including 200 V RMS group isolation and 250 V RMS inter-track continuous isolation, improving system stability and protection against electrical interference. Compared with earlier Procontrol P13 analog input modules such as 70EA01A versions, the ABB HESG447307R1 70EA01B-ES offers improved signal processing speed and enhanced isolation design, making it more suitable for modernized retrofit DCS systems.

The ABB HESG447307R1 70EA01B-ES operates reliably within a temperature range of -25°C to +70°C and supports relative humidity up to 95% non-condensing. These environmental tolerances make it suitable for harsh industrial environments such as power plants, refineries, and large process industries. Its robust design ensures stable long-term operation in continuous control systems where accuracy and reliability are essential.
