DSQC 541 3HAC14363-1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DSQC 541 3HAC14363-1 is a slim controller backplane identified by ABB for legacy robot-control assemblies and cross-referenced to old product ID 3HAC3617-1.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for DSQC 541 3HAC14363-1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSQC 541 3HAC14363-1

  • Manufacturer:
    ABB
  • Part Number:
    DSQC 541 3HAC14363-1
  • Product Family:
    ABB Robots
  • Product Type:
    Robot Controller Backplane
  • Stock:
    1
  • Replaced old product ID:
    3HAC3617-1
  • Gross volume:
    0.945 dm³
  • Dimensions:
    20.7 × 1.8 × 25.35 cm
  • Controller platform:
    ABB S4Cplus M2000A
  • Main computer pairing:
    DSQC 540
  • Configuration note:
    DSQC 541 is the backplane used with the DSQC 540 main computer
  • Minimum software:
    BaseWare OS 4.0.92 or later for the DSQC 540 configuration
  • Weight:
    0.36 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Slot Preservation Connector Condition Part Matching Application
  • ABB controller backplane identified by complete part number 3HAC14363-1
  • Low-profile format for its designated robot-controller hardware assembly
  • Officially cross-referenced to the older product identifier 3HAC3617-1

DSQC 541 3HAC14363-1 forms the backplane connection structure for its designated ABB robot-controller assembly.

Because installed cards and harnesses depend on the backplane connector topology, the complete 3HAC number and original slot map are more important than visual similarity.

Before fitting the backplane, preserve the module sequence, examine mating contacts and verify the chassis reference associated with the existing hardware.

Availability, condition, price, and shipping time for DSQC 541 3HAC14363-1 are confirmed during quotation.

ABB DSQC 541 3HAC14363-1 Robot Controller Backplane Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Label every installed card position before the original backplane is removed.
  • Return plug-in units to the same documented connector locations.
  • Verify full seating without forcing a module into a mismatched connector.
  • Inspect the long mating surfaces for bent, recessed or contaminated contacts.
  • Check retained harnesses for strain before tightening the backplane fixings.
  • Resolve connector damage before applying controller power.
  • Match both DSQC 541 and 3HAC14363-1 to the installed label.
  • Use 3HAC3617-1 only as the documented older-product cross-reference.
  • Reject a candidate whose card layout or mounting pattern differs from the chassis.
  • Backplane interconnection in ABB legacy robot-controller assemblies
  • Mechanical support and electrical mating for designated controller plug-in units
  • Signal and supply distribution across the associated ABB controller chassis
Description
DSQC 541 3HAC14363-1 is an ABB robot-controller backplane whose complete identity combines the DSQC designation with the 3HAC ordering number.

The backplane provides the mechanical and electrical interconnection surface for its designated controller hardware, so connector layout and installed module positions are essential compatibility checks.

ABB records 3HAC3617-1 as an older product identifier; confirm the existing cabinet, mating hardware and full replacement number before disturbing any plug-in units.
Alternative Names
DSQC 541 3HAC14363-1 DSQC541 3HAC14363-1 3HAC14363-1 DSQC 541 3HAC143631 DSQC541 ABB DSQC 541 3HAC14363-1 ABB 3HAC14363-1 DSQC 541
Technical notes
DSQC 541 3HAC14363-1 requires confirmation of the controller chassis, original module positions, mating connectors and complete 3HAC identity before installation to prevent backplane or slot incompatibility.
