ASTRO RB-649 is a wired VG-series remote control box with program, group, pattern, signal-polarity and video-output-level controls for compatible ASTRO video signal generators.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for RB-649
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for RB-649

  • Manufacturer:
    ASTRO
  • Part Number:
    RB-649
  • Product Family:
    ASTRO
  • Product Type:
    VG-Series Wired Remote Control Box with Group and Output-Level Controls
  • Stock:
    1
  • Device Type:
    Wired remote control box
  • Compatible Generator Family:
    ASTRO VG series
  • Documented Host Models:
    VG-827 and VG-880
  • Generator Connection:
    Front-panel remote connector
  • Connector Type:
    25-pin female connector on VG-880
  • Program Selection:
    Numeric entry plus INC and DEC keys
  • Group Selection:
    Dedicated GROUP key
  • Pattern Control:
    Illuminated pattern-selection keys
  • Signal Polarity Control:
    SHIFT selects NEGA or POSI for HS and VS
  • Output-Level Control:
    H-T key
  • Cursor Limitation:
    Cannot select a cursor pattern; can operate an already-output cursor
  • Dimensions:
    21.7 × 4.0 × 15.5 cm
  • Weight:
    0.82 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Group Selection Signal Adjustment Service Validation Application
  • Dedicated GROUP and H-T controls for VG-series operating workflows
  • Illuminated pattern and signal-output keys provide direct status feedback
  • SHIFT supports documented NEGA and POSI selection for HS and VS

ASTRO RB-649 is a wired operator interface for compatible VG generators where group selection, pattern switching and output adjustment must be available away from the main panel.

Its illuminated keys show selected outputs and patterns, while numeric, GROUP, SHIFT, SET and H-T controls support the documented program and signal workflow.

Replacement verification should exercise group calls, sync polarity, output level, pattern selection and program stepping through the connected generator.

Availability, condition, price, and shipping time for ASTRO RB-649 are confirmed during quotation.

ASTRO RB-649 VG-Series Remote Control Box Manuals, Datasheet, Links

Important Notice: Other accessories, manuals, cables, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The GROUP key enters the registered group-data selection workflow
  • Number keys or INC and DEC choose the requested group number
  • SET executes the selected group and ignores unregistered group data
  • SHIFT changes the documented HS and VS polarity selection
  • H-T opens the video output-level adjustment operation
  • R, G, B, inversion and synchronization outputs use dedicated keys
  • Confirm cable continuity and the 25-pin key-matrix path first
  • Compare remote results with the generator front-panel operation
  • Test program, group, pattern, polarity and level functions independently
  • Remote selection of stored VG-series programs and registered groups
  • Pattern and signal-output control during video-display evaluation
  • Adjustment of supported video levels and synchronization polarity
Description
ASTRO RB-649 is a VG-series wired remote box that combines stored-program selection with group, pattern, signal-polarity and output-level operation.

The front panel provides illuminated output and pattern keys, numeric entry, GROUP, SHIFT, SET, FUNC, H-T, INC and DEC controls through the documented VG remote interface.

Before replacement, match the connected generator, cable and 25-pin interface, then verify that group data, output levels and stored patterns respond correctly after connection.
Alternative Names
RB-649 RB 649 ASTRO RB-649 ASTRODESIGN RB-649 RB-649 Remote Control Box VG-Series RB-649 Remote Box VG-827 RB-649 Remote Control Box VG-880 RB-649 Remote Control Box
Technical notes
ASTRO RB-649 adds dedicated GROUP and output-level control to VG-series remote operation; preserve program, group, polarity and level settings and verify the 25-pin interface before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which ASTRO generators officially support ASTRO RB-649?
ASTRO's VG-880 comparison lists RB-649 for both VG-827 and VG-880. Confirm the exact generator, remote connector and operating procedure before ordering.
What does the GROUP key do on ASTRO RB-649?
The GROUP key opens the documented group-number workflow. The operator enters or steps to a registered group and executes it with SET; unavailable group data is ignored by the generator.
Can ASTRO RB-649 change video output levels?
Yes. ASTRO directs RB-649 users to the H-T key for output-level adjustment. Confirm the generator's analog or digital level range and monitor the resulting output before saving changes.
How does ASTRO RB-649 change HS and VS polarity?
Use SHIFT with the applicable output controls to select NEGA or POSI for HS and VS as documented. Verify the receiving display's sync requirement before changing polarity.
Can ASTRO RB-649 select a cursor pattern?
No. RB-649 cannot select the cursor pattern, although it can operate a cursor that is already output. Direct cursor selection requires another supported method.
What should be checked when ASTRO RB-649 LEDs or keys do not respond?
Inspect the 25-pin cable and connector, generator remote interface, key matrix, stored program or group data, and the specific key sequence. Compare behavior with the generator front panel to isolate the remote box.
What should be recorded before replacing ASTRO RB-649?
Record the host generator model, cable routing, active program and group numbers, signal polarity, output-level settings, and the functions used by the operator so the replacement can be validated systematically.
