        ASTRO RB-614C
        ASTRO RB-614C
        ASTRO RB-614C
        ASTRO RB-614C
        ASTRO RB-614C
        ASTRO RB-614C
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail sales1@apterpower.com

        • Lifecycle status

          Discontinued

        RB-614C

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ASTRO RB-614C is a wired remote control box for compatible VG-series video signal generators, providing program selection, pattern switching and signal-output control through the generator's 25-pin remote connector.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for RB-614C
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for RB-614C

        • Manufacturer:
          ASTRO
        • Part Number:
          RB-614C
        • Product Family:
          ASTRO
        • Product Type:
          VG-Series Wired Remote Control Box
        • Stock:
          1
        • Documented Host Models:
          VG-827 and VG-880
        • Generator Connection:
          Front-panel remote connector
        • Connector Type:
          25-pin female connector on VG-880
        • Program Selection:
          Numeric entry plus INC and DEC keys
        • Pattern Control:
          Character, crosshatch, dots, circle, color, gray, burst, window and optional patterns
        • Signal Control:
          RGB, inversion and sync-output switching
        • Group Data Operation:
          H-T key
        • Cursor Limitation:
          Cannot select a cursor pattern; can operate an already-output cursor
        • Output-Level Limitation:
          Video output levels cannot be changed with RB-614C
        • Tariff Code:
          8537109090
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Program Control Pattern Operation Compatibility Limits Application
        • Wired remote operation for documented ASTRO VG-827 and VG-880 generators
        • Numeric program entry plus dedicated pattern and output-control keys
        • Model-specific limitations for cursor selection and video-level adjustment

        ASTRO RB-614C moves frequently used VG-series program, pattern and signal-output controls to a dedicated wired operator box.

        Its key matrix supports direct program navigation and test-pattern operation through the generator's remote connector without duplicating every function available on later remote models.

        Selection should therefore confirm the target VG model, required key functions and cable condition, especially where cursor selection or output-level adjustment is part of the operating procedure.

        Availability, condition, price, and shipping time for ASTRO RB-614C are confirmed during quotation.

        ASTRO RB-614C VG-Series Remote Control Box Manuals, Datasheet, Links

        Important Notice: Other accessories, manuals, cables, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • Number keys enter the target program or group value
        • INC and DEC keys step through available program numbers
        • SET and FUNC complete the documented remote-key sequences
        • Dedicated keys switch character, crosshatch, dot and circle patterns
        • Color, gray, burst, window and optional outputs use separate controls
        • Cursor operation is available only after another method selects the cursor
        • VG-827 and VG-880 are the generator models listed in the official comparison
        • The RB-614C key matrix is identified at the 25-pin remote interface
        • Video output levels cannot be changed from this remote box
        • Calling stored VG-series test programs by number at the operator position
        • Switching character, dot, crosshatch and other video test patterns
        • Controlling RGB and synchronization-signal outputs during display testing
        Description
        ASTRO RB-614C is a VG-series wired remote control box used to call stored programs and operate pattern and output functions from the generator's front-panel remote interface.

        Its key set provides program increment and decrement, numeric entry, pattern selection, RGB and sync-output switching, inversion, function execution and H-T group-data operation.

        Before replacement, confirm RB-614C support on the target VG generator, the 25-pin cable and connector, saved program data, required key behavior, and the functions that this model does not provide.
        Alternative Names
        RB-614C RB 614C ASTRO RB-614C ASTRODESIGN RB-614C RB-614C Remote Control Box VG-Series RB-614C Remote Box VG-827 RB-614C Remote Control Box VG-880 RB-614C Remote Control Box
        Technical notes
        ASTRO RB-614C connects to the VG-series 25-pin remote interface; it supports program, pattern and signal-output control but does not select cursor patterns or change video output levels, so these limitations must be checked before replacement.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Which ASTRO generators officially support ASTRO RB-614C?
        ASTRO's VG-880 manual lists RB-614C as a supported remote control box for both VG-827 and VG-880. Confirm the target generator model, firmware behavior and physical remote connector before ordering.
        How is ASTRO RB-614C connected to a VG-880 generator?
        Connect the RB-614C cable to the 25-pin female remote connector on the VG-880 front panel. Power down or follow the generator's approved connection procedure, inspect pins, and secure the connector before operation.
        Can ASTRO RB-614C call stored programs without using the generator front panel?
        Yes. ASTRO documents numeric program entry together with INC and DEC controls, allowing the operator to call or step through stored program numbers from the remote box.
        Can ASTRO RB-614C select and switch video test patterns?
        Yes. Its pattern keys support the documented character, crosshatch, dot, circle, color, gray, burst, window and optional-pattern functions, subject to the data stored in the connected VG generator.
        Can ASTRO RB-614C change the VG-880 video output level?
        No. The VG-880 manual states that video output levels cannot be changed with RB-614C. Use the supported generator or remote-control method for level adjustment instead of assuming the H-T key performs that function.
        Can ASTRO RB-614C select a cursor pattern?
        RB-614C cannot select the cursor pattern. ASTRO states that it can operate a cursor only after the cursor is already output, so workflows needing direct cursor selection require another supported control method.
        What should be checked if ASTRO RB-614C keys do not operate the VG generator?
        Verify generator compatibility, cable continuity, connector seating and bent pins, the VG remote input, stored program data, and the key-matrix path. Also confirm that the requested function is actually supported by RB-614C.
