1756-DMA31

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-DMA31 is a ControlLogix drive module that links one controller slot with one SA3100 Power Module Interface chassis for coordinated velocity, position, or torque control.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1756-DMA31
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-DMA31

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-DMA31
  • Product Family:
    ControlLogix
  • Product Type:
    ControlLogix Drive Module for SA3100 Drives
  • Stock:
    1
  • Controlled drive platform:
    SA3100
  • Drive interface capacity:
    One PMI chassis per module
  • Supported control functions:
    Velocity, position, and torque control
  • SynchLink network rate:
    5 Mbps
  • Firmware release:
    Major 1, minor 11
  • RSLogix 5000 requirement:
    Version 8.02.00
  • RSLinx requirement:
    Version 2.30
  • RSNetWorx for ControlNet requirement:
    Version 3.00
  • DriveExecutive requirement:
    Version 1.01
  • Volts-per-hertz controller format:
    Custom User Defined
  • Supported input classes:
    230 V AC, 310 V DC, 460 V AC, 575 V AC, 620 V DC, and 775 V DC
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Drive Interface Software Match Commissioning Application
  • Connects a ControlLogix controller to one SA3100 PMI chassis
  • Supports velocity, position, and torque control rather than general-purpose I/O
  • Uses a documented software and firmware set for drive commissioning

1756-DMA31 occupies the control boundary between a Logix project and an SA3100 drive installation. Its role is defined by the paired PMI chassis and the selected control mode.

The official release notes focus on firmware/software compatibility and two commissioning hazards: an incorrect controller communication format for volts-per-hertz operation and transient PMI faults during power cycling.

Before installation or replacement, verify the SA3100 power-unit class, PMI chassis allocation, SynchLink arrangement, controller format, firmware, and archived DriveExecutive project.

Availability, condition, price, and shipping time for 1756-DMA31 are confirmed during quotation.

Allen-Bradley 1756-DMA31 ControlLogix Drive Module for SA3100 Drives Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Interfaces one ControlLogix module with one SA3100 PMI chassis
  • Supports velocity, position, and torque-control functions
  • Requires the power-unit class and drive project to match the installed SA3100 system
  • Use firmware major 1, minor 11 with the documented software environment
  • Retain the RSLogix 5000 and DriveExecutive project records before replacement
  • Confirm the controller communication format before restoring the application
  • Use Custom User Defined communication format for volts-per-hertz operation
  • Allow PMI communication to reinitialize after a power cycle
  • Clear or reset persistent PMI communication faults using the documented procedure
  • Single-axis SA3100 velocity-control applications
  • SA3100 position-control installations coordinated through ControlLogix
  • SA3100 torque-control systems using the documented PMI and SynchLink architecture
Description
1756-DMA31 provides the ControlLogix interface for a single SA3100 drive and its associated Power Module Interface chassis.

The module supports controller-directed velocity, position, and torque functions, while its documented SynchLink connection carries deterministic drive-system timing at 5 Mbps.

Commissioning depends on the matching SA3100 power-unit type, controller communication format, firmware revision, and saved drive project; the release notes require a custom user-defined format for volts-per-hertz operation.
Revisions

Revision Part #

Also known as

1756-DMA31 Ser A
1756-DMA31/A, Series A, Rev A
Alternative Names
1756-DMA31 1756-DMA31/A Allen-Bradley 1756-DMA31 Allen Bradley 1756-DMA31 Rockwell Automation 1756-DMA31 ControlLogix Drive Module 1756-DMA31
Technical notes
1756-DMA31 replacement requires the matching SA3100 PMI chassis, power-unit class, firmware, SynchLink arrangement, and saved controller format; an incorrect drive or format prevents commissioned operation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is 1756-DMA31 intended for any Allen-Bradley drive?
No. Rockwell Automation identifies 1756-DMA31 for the SA3100 drive platform and one associated PMI chassis. Confirm the complete drive family and power-unit arrangement before ordering.
Can a replacement 1756-DMA31 retain the installed SA3100 PMI chassis?
Only when the PMI chassis, power-unit class, SynchLink arrangement, firmware, and controller communication format match the documented SA3100 design. Confirm the complete drive architecture before commissioning.
Can 1756-DMA31 run a volts-per-hertz application with a standard controller format?
No. The official release notes require the Custom User Defined controller communication format for volts-per-hertz operation; selecting another format can prevent the module from connecting to the controller.
Why can 1756-DMA31 report PMI communication faults after a power cycle?
The release notes describe transient PMI communication faults while the drive module re-establishes synchronized communication. Clear faults after initialization and follow the documented reset procedure if the condition remains.
Does one 1756-DMA31 control more than one PMI chassis?
No. Rockwell Automation documents one 1756-DMA31 module interfacing with one PMI chassis, so multi-axis or multi-drive arrangements require the engineered module allocation.
Which software versions matter when servicing 1756-DMA31?
The release notes associate firmware 1.11 with RSLogix 5000 8.02.00, RSLinx 2.30, RSNetWorx for ControlNet 3.00, and DriveExecutive 1.01; verify the existing project before changes.
Can 1756-DMA31 be selected only by matching the ControlLogix slot?
No. Slot fit does not establish compatibility. The SA3100 drive, PMI chassis, input-voltage class, communication format, firmware, and saved controller/drive configuration must all match.
