440R-N23114 MSR126.1T

/ 4.9
1001 reviews | Need a Specific Revision?
The Allen-Bradley 440R-N23114 MSR126.1T is a dedicated, single-function monitoring safety relay engineered to provide fundamental fault detection within high-risk control circuits.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 440R-N23114 MSR126.1T
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 440R-N23114 MSR126.1T

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    440R-N23114 MSR126.1T
  • Product Family:
    GuardPLC
  • Product Type:
    Monitoring Safety Relay
  • Stock:
    1
  • Safety Contact Outputs:
    2 N/O, Undelayed
  • Supply Voltage:
    24V AC/DC 20.4-26.4V
  • Power Consumption:
    4 W
  • Input Wiring:
    1 or 2-Channel
  • Terminal Type:
    Fixed Screw, 0.2-2.5 mm²
  • External Fusing:
    6 A SB or 10 A QB
  • Thermal Current (Ith):
    6 A/Path
  • Output Contact Rating:
    6 A @ 24V DC, 6 A @ 250V AC
  • Minimum Switching Current:
    10 mA @ 10V
  • Electrical Durability:
    100k-2M ops (load dependent)
  • Start Input:
    Integrated Start/Restart
  • Feedback Loop:
    External Contact Monitoring
  • Rated Impulse Voltage:
    2500V
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    2.2x11x17.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Monitoring & Control Operating Environment

Features:

  • Safety Circuit Monitoring with Single or Dual-Channel Input Configurations
  • Start/Restart Integration and External Contact Monitoring Feedback Loop
  • High-Capacity Contact Outputs and 2500V Impulse Voltage Protection
The 440R-N23114 MSR126.1T operates as a Monitoring Safety Relay in industrial safety control systems, providing reliable switching logic for safety circuit applications. It continuously processes safety input signals received through either single or dual-channel wiring configurations and converts these into decisive output switching actions via two normally open (N/O) undelayed contacts.

The 440R-N23114 provides essential safety monitoring functions common to the entire protection circuit, and is a critical component of the safety control path, directly affecting the proper, normal operation of the overall safeguarding system. One 440R-N23114 relay is typically required per safety zone depending on the desired input channel configuration. The 440R-N23114 utilizes fixed screw terminals accommodating input wiring from 0.2 to 2.5 mm² and is mounted in a standard control panel position, ensuring secure physical connections.

For Dual-Channel safety applications, the 440R-N23114 supports a dual input channel configuration wired to safety devices such as interlock switches or emergency stop buttons. In addition to standard single-channel operation, the dual-channel configuration also performs automatic cross-monitoring of input states. The 440R-N23114 dual-channel safety circuit executes monitoring using the internal safety logic specified in the relay design.

The 440R-N23114 MSR126.1T Allen-Bradley Monitoring Safety Relay may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 440R-N23114 MSR126.1T Monitoring Safety Relay Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Allen-Bradley 440R-N23114 MSR126.1T Monitoring Safety Relay Specs

General

  • Manufacturer Allen-Bradley
  • Model 440R-N23114 MSR126.1T
  • Condition New Original ready stock
  • Product Family 440R-N23112 MSR126.1T,440R-N23117 MSR126T
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Emergency Stop Buttons: Connects directly to dual-channel E-stop push buttons for instant power isolation.
  • Safety Gates & Interlocks: Monitors electromechanical safety switches, tongue switches, and hinge switches on protective guards.
  • Safety Light Curtains: Interfaces with optoelectronic presence sensing devices that incorporate cross-fault monitoring capabilities.
  • Dual-Channel Input Logic: Configured to monitor 2 Normally Closed (N.C.) inputs to ensure redundancy.
  • Cross-Fault Monitoring: Active detection loops prevent machine restarts if a short circuit occurs across the input channels.
  • Automatic/Manual Reset: Features an unmonitored reset function (indicated by the "T" suffix), meaning the unit activates immediately once the safety loop and reset loop are closed simultaneously.
  • Safety Integrity Ratings: Complies with Performance Level e (PLe) per ISO 13849-1, Safety Integrity Level 3 (SIL CL3) per IEC 62061, and Category 4 per EN 954-1.
  • Operating Temperature: Suitable for ambient operating environments ranging from -5°C to +55°C (+23°F to +131°F).
  • Relative Humidity: Designed to withstand up to 90% non-condensing relative humidity.
  • Ingress Protection (IP): The primary polycarbonate housing is rated IP40, while the fixed screw terminals are rated IP20.
  • Mounting Type: Standard snap-on installation compatible with 35mm DIN rails inside sealed control panels.
  • Mechanical Life: Engineered for a durable service life of up to 2,000,000 mechanical operations.
Description
The Allen-Bradley 440R-N23114 MSR126.1T Monitoring Safety Relay is specifically designed to handle critical safety interlocking and monitoring tasks in industrial automation environments. The 440R-N23114 MSR126.1T addresses the challenge of maintaining safe machine operations by providing reliable monitoring of safety circuits, ensuring that hazardous conditions trigger immediate and dependable shutdown responses. This relay is engineered to solve the problem of inconsistent safety responses in multi-channel safety systems, offering a robust solution for applications requiring precise safety logic execution.

The 440R-N23114 MSR126.1T is widely applied across manufacturing, material handling, packaging, and automotive production lines. In these sectors, the 440R-N23114 MSR126.1T serves as a core component in safety systems guarding press machinery, robotic work cells, conveyor systems, and automated assembly equipment. The 440R-N23114 MSR126.1T is also commonly utilized in process industries where safety gate monitoring, light curtain integration, and emergency stop circuit management are essential operational requirements.

Regarding upgrade recommendations, facilities currently utilizing legacy safety relay modules should consider transitioning to the 440R-N23114 MSR126.1T to benefit from its 2500V rated impulse voltage protection and enhanced transient surge resistance. The 440R-N23114 MSR126.1T offers improved electrical durability ranging from 100,000 to 2 million operations, representing a significant lifecycle advantage over older safety relay technologies.
Alternative Names
440R-N23114 MSR126.1T MSR126.1R/T MSR126R/T 440R-N23113 MSR126.1T 440R-N23112 MSR126.1T 440R-N23117 MSR126T 440R-N23116 MSR126T 440R-N23115 MSR126T
Technical notes
The 440R-N23114 MSR126.1T features dual-channel input wiring configurations and is specifically equipped with built-in cross-fault detection across its inputs. It delivers immediate safety control through its two normally open (N/O) undelayed safety outputs, which are built with independent and redundant internal contacts to guarantee the execution of critical safety commands even if a single component fails.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the 440R-N23114 MSR126.1T safety relay?
The 440R-N23114 MSR126.1T is a safety relay designed to monitor dual-channel safety devices and provide reliable machine shutdown when unsafe conditions or circuit faults are detected.
What is the primary function of the 440R-N23114 MSR126.1T?
The relay monitors safety inputs such as emergency stop buttons, safety gates, and interlock switches, ensuring that hazardous machinery can operate only when all safety conditions are satisfied.
What safety problems does the 440R-N23114 MSR126.1T solve?
The relay detects wiring faults, cross-channel short circuits, and other electrical failures that conventional relays may overlook, helping prevent unexpected machine operation and improving personnel safety.
Does the 440R-N23114 MSR126.1T support manual and automatic reset?
Yes. The relay supports both automatic and manual reset modes through a dedicated feedback circuit, allowing safe system recovery only after connected actuators have returned to their normal state.
