2711P-T4W22D8S

/ 4.9
1001 reviews | Need a Specific Revision?
The Allen-Bradley 2711P-T4W22D8S is a 4.3-inch PanelView Plus 7 Standard HMI that displays Machine Edition screens and returns operator touch input to the control application.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 2711P-T4W22D8S
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-T4W22D8S

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-T4W22D8S
  • Product Family:
    Allen Bradley Panelviews
  • Product Type:
    4.3-Inch Widescreen Dual-Ethernet Touch Terminal
  • Stock:
    1
  • Display size:
    4.3 in. widescreen
  • Display technology:
    Color TFT LCD
  • Viewing area:
    95 x 54 mm
  • Resolution:
    480 x 272 WQVGA, 18-bit color
  • Aspect ratio:
    16:9
  • Typical brightness:
    300 nits
  • Backlight life:
    50,000 h minimum at 40 °C to half brightness
  • Touch technology:
    Analog resistive
  • Touch actuation rating:
    1 million presses
  • Ethernet ports:
    Two 10/100Base-T Auto MDI/MDI-X
  • Supported network topologies:
    Star, linear, and DLR
  • System memory:
    512 MB RAM and 512 MB storage
  • Application storage:
    80 MB nonvolatile
  • Removable storage:
    One SD card slot
  • USB interfaces:
    One USB 2.0 host and one USB 1.0 device port
  • Input voltage:
    24 V DC nominal, 18–30 V DC
  • Maximum power consumption:
    35 W, 1.46 A at 24 V DC
  • Operating system:
    Windows CE
  • Application software:
    FactoryTalk View Studio Machine Edition 8.0 or later
  • Operating limits:
    One controller, up to 100 screens, and up to 500 alarms
  • Operating temperature:
    0 to 55 °C
  • Enclosure ratings:
    NEMA/UL Type 12, 13, 4X indoor; IP54 or IP66
  • Weight:
    0.97 lbs (0.44 kg)
  • Estimated shipping dimensions:
    11x13.5x5.65cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Japan
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Touch Display DLR Network File Paths Runtime Scope

Features:

  • Displays machine information on a 4.3-inch 480 x 272 color resistive touch interface.
  • Provides two Ethernet ports for star, linear, or Device Level Ring network layouts.
  • Stores the HMI runtime locally while supporting SD and USB file-transfer paths.
Allen-Bradley 2711P-T4W22D8S connects a compact operator interface to one controller while organizing as many as 100 screens and 500 alarms.

The embedded two-port switch passes Ethernet traffic between terminal neighbors, so the HMI can participate directly in a linear or DLR segment.

FactoryTalk View Machine Edition Station runs the application, while removable storage and host connectivity keep application files separate from the live touch interface.
Allen-Bradley 2711P-T4W22D8S 4.3-Inch Widescreen Dual-Ethernet Touch Terminal Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Operator Image and Input Chain

  • Display surface: The 4.3-inch TFT panel presents 480 x 272 WQVGA graphics in a 16:9 format.
  • Touch return: The analog resistive layer converts operator pressure into application input.
  • Visual output: The backlight and 300-nit panel provide the local image used by the machine operator.
  • Service boundary: The backlight is not replaceable, while the touch surface is rated for one million presses.

Dual-Port Ethernet Behavior

  • Embedded switch: Two Auto MDI/MDI-X ports share the terminal’s 10/100Base-T connection.
  • Linear path: One cable can enter the HMI and the second can continue toward the next node.
  • Ring path: Both ports allow the terminal to participate in a Device Level Ring topology.
  • Star path: Either port can connect the HMI as a conventional endpoint through an external switch.

Internal, SD, and USB Storage

  • Runtime space: Eighty megabytes of nonvolatile storage are reserved for applications.
  • SD expansion: The card slot stores supported application and project files on removable media.
  • USB host: The Type A host port accepts removable flash storage.
  • USB device: The Type B device port connects a host computer for supported terminal access.

Machine Edition Limits

  • Controller count: The Standard terminal connects to one controller in the documented runtime scope.
  • Screen count: A project can contain up to 100 application screens.
  • Alarm count: The runtime supports up to 500 alarms.
  • Engineering software: FactoryTalk View Studio Machine Edition 8.0 or later creates the terminal application.
Description
Allen-Bradley 2711P-T4W22D8S is a 4.3-inch widescreen PanelView Plus 7 Standard operator terminal for machine-level visualization and touch control. Its 480 x 272 color display presents FactoryTalk View Machine Edition screens while the resistive touch layer returns operator selections to the application.

Two 10/100Base-T ports on Allen-Bradley 2711P-T4W22D8S form an embedded Ethernet switch that supports star, linear, or Device Level Ring topology. This allows the HMI to sit between neighboring EtherNet/IP nodes instead of requiring every connection to return to an external switch.

Application files for Allen-Bradley 2711P-T4W22D8S occupy the terminal’s nonvolatile storage, while the SD slot and USB host port provide removable-file paths. The USB device port links a host computer for supported configuration tasks without consuming either Ethernet connection.

A nonisolated 24 V DC supply powers Allen-Bradley 2711P-T4W22D8S, and the panel cutout supports front-mounted operator access. The sealed front assembly carries the documented indoor enclosure ratings, while rear clearances remain necessary for power, Ethernet, USB, and SD-card access.
Revisions

Revision Part #

Also known as

2711P-T4W22D8S Ser D
2711P-T4W22D8S/D, Series D, Rev D
2711P-T4W22D8S Ser A
2711P-T4W22D8S/A, Series A, Rev A
2711P-T4W22D8S Ser X
2711P-T4W22D8S/X, Series X, Rev X
Alternative Names
2711P T4W22D8S 2711PT4W22D8S Allen-Bradley 2711P-T4W22D8S 2711P-T4W22D8S/D 2711P-T4W22D8S Series D 2711P-T4W22D8S Rev D 2711P-T4W22D8S Touch Terminal 271IP-T4W22D8S
Technical notes
Allen-Bradley 2711P-T4W22D8S combines a 4.3-inch resistive widescreen with dual 10/100Base-T ports for star, linear, or DLR layouts.
