2707-L40P2

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 2707-L40P2 is a DTAM Plus operator interface with a four-line LCD, 40K application memory, real-time clock, RS-232C printer port, and P2 wide-range power supply.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 2707-L40P2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2707-L40P2

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2707-L40P2
  • Product Family:
    Allen Bradley Panelviews
  • Product Type:
    DTAM Plus 4-Line LCD Operator Interface Terminal
  • Stock:
    1
  • Display Type:
    LCD
  • Display Format:
    4 lines × 20 characters
  • Application Memory:
    40K
  • Real-Time Clock:
    Included
  • Communication Port:
    Configurable RS-232C or RS-485
  • Printer Port:
    RS-232C
  • Input Voltage:
    85 to 265 V AC, 47 to 440 Hz, or 110 to 300 V DC
  • Maximum Input Current:
    300 mA
  • Input Fuse:
    0.5 A
  • Enclosure Rating:
    NEMA Type 12, 13, and 4X indoor when properly mounted
  • Operating Temperature:
    0 to 45 °C
  • Storage Temperature:
    -20 to 85 °C
  • Relative Humidity:
    5% to 95%, noncondensing
  • Dimensions:
    Body 19.3 × 13.97 × 4.57 cm; front panel 21.59 × 16.51 cm
  • Weight:
    0.95 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Communication Setup Printer and Clock Installation Checks Application
  • DTAM Plus LCD terminal with four lines × 20 characters and 40K application memory
  • Configurable RS-232C or RS-485 controller communication
  • Real-time clock, RS-232C printer port, and P2 wide-range power input

2707-L40P2 presents controller messages, operator prompts, data-entry screens, recipes, and alarms through the DTAM Plus interface.

The 40K configuration supports up to 244 screens, time-stamped reports, and ASCII input such as decoded bar-code data through the printer port.

Replacement planning must preserve the DTAM Plus application, communication selection, printer setup, controller addressing, P2 supply, panel cutout, and enclosure seal.

Availability, condition, price, and shipping time for 2707-L40P2 are confirmed during quotation.

Allen-Bradley 2707-L40P2 Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Select RS-232C or RS-485 to match the controller connection
  • Restore baud rate, addressing, parity, and application communication settings
  • Verify cable pinout and RS-485 polarity before applying machine control
  • The printer port uses a dedicated RS-232C connection
  • Report triggers and formatting are defined by the terminal application
  • Confirm real-time-clock values after application restoration
  • Confirm the P2 power range before connecting the cabinet supply
  • Retain the documented panel cutout, gasket, and mounting clearances
  • Test every key, message, serial path, and print function before release
  • Recipe screens that download values to as many as 10 non-sequential controller addresses per screen
  • ASCII input such as decoded bar-code data through the RS-232C printer port on the 40K terminal
  • Time-stamped critical reports and displayed data using the built-in real-time clock
Description
2707-L40P2 is an Allen-Bradley DTAM Plus operator interface with a four-line by 20-character LCD and 40K application memory.

The catalog configuration includes configurable RS-232C or RS-485 controller communication, a dedicated RS-232C printer port, a real-time clock, and the P2 wide-range power supply.

Before replacement, preserve the DTAM Plus application and verify the communication mode, printer settings, controller addresses, P2 supply, panel cutout, and enclosure seal.
Alternative Names
2707-L40P2 2707 L40P2 2707L40P2 Allen-Bradley 2707-L40P2 Allen Bradley 2707-L40P2 DTAM Plus 2707-L40P2 DTAM Plus L40P2
Technical notes
2707-L40P2 requires the correct P2 wide-range supply, restored DTAM Plus application, matched RS-232C or RS-485 settings, printer wiring, and installation cutout; an incorrect supply or communication selection can prevent operation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What must be backed up before replacing Allen-Bradley 2707-L40P2?
Save the original DTAM Plus application and record the controller addresses, RS-232C or RS-485 selection, printer parameters, real-time-clock settings, and programmed key behavior before removing the terminal.
Can Allen-Bradley 2707-L40P2 replace another DTAM Plus terminal without configuration changes?
Only after the LCD format, 40K memory option, P2 power supply, controller communication mode, printer requirement, mounting cutout, and downloaded DTAM Plus application are confirmed against the installed unit.
What power check is most important before installing Allen-Bradley 2707-L40P2?
Confirm that the cabinet supply falls within the documented P2 AC or DC range and that protective wiring and the specified input fuse are correctly applied.
Why might Allen-Bradley 2707-L40P2 fail to communicate after replacement?
Common causes are an incorrect RS-232C or RS-485 selection, mismatched serial parameters, wrong controller address, reversed RS-485 wiring, or an application that does not match the machine.
How should the printer connection be checked on Allen-Bradley 2707-L40P2?
Verify the RS-232C printer cable, port parameters, print-trigger logic, and the report format stored in the application before relying on production records.
What should be verified when mounting Allen-Bradley 2707-L40P2?
Match the existing panel cutout, gasket, clearance, retainer arrangement, enclosure sealing, and cable bend space so the documented environmental rating is maintained.
Can Allen-Bradley 2707-L40P2 accept decoded bar-code data through its printer port?
Yes. Rockwell Automation documents ASCII input capability for 40K DTAM Plus versions through the RS-232 printer port; the application and serial parameters must be configured for the connected input device.
