X20BB80

/ 4.9
1001 reviews | Need a Specific Revision?
B&R X20BB80 is an X20 bus base for a bus controller or hub base module and its associated power-supply module for the X20 System.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for X20BB80
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for X20BB80

  • Manufacturer:
    B&R
  • Part Number:
    X20BB80
  • Product Family:
    B&R X20 System
  • Product Type:
    Bus Controller Bus Base
  • Stock:
    1
  • Primary function:
    Bus base for X20 base module and supply module
  • I/O supply nominal voltage:
    24 VDC
  • Permissible contact load:
    10 A
  • Bus power consumption:
    0.25 W
  • Included accessories:
    Left and right X20 end plates
  • Module pitch:
    37.5 mm +0.2 mm
  • Maximum installation elevation:
    4000 m
  • Elevation derating above 2000 m:
    Reduce ambient temperature by 0.5 °C per 100 m
  • Mounting orientation:
    Horizontal or vertical
  • Degree of protection:
    IP20
  • Operating temperature:
    -25 to 60 °C horizontal; -25 to 50 °C vertical
  • Storage / transport temperature:
    -40 to 85 °C
  • Relative humidity:
    5 to 95%, non-condensing
  • Tariff Code:
    8538900000
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Assembly Power Path Replacement Application
  • Supports an X20 bus controller or hub base module
  • Provides the adjacent position for the supply module
  • Includes the left and right X20 end plates

X20BB80 is a B&R bus controller bus base designed for the X20 System.

The base combines a wide controller position with the adjacent supply-module position so the complete X20 fieldbus head can be assembled on the mounting rail.

Before installation or replacement, verify the complete material number, the exact bus controller or hub, matching supply module, terminal block, 24 VDC potential group, 10 A contact-load limit, included end plates, neighboring X20 slices, and station layout.

Availability, condition, price, and shipping time for X20BB80 are confirmed during quotation.

B&R X20BB80 Bus Controller Bus Base Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The wide base accepts the documented controller or hub assembly
  • The associated supply module occupies the adjacent base position
  • The electronic modules and terminal block must be matched as a complete assembly
  • The I/O supply is nominally 24 VDC
  • The permissible contact load is 10 amperes
  • Potential-group continuity must be verified across neighboring slices
  • Record the controller and supply module material numbers before removal
  • Preserve the left-to-right module order and end-plate arrangement
  • Inspect bus contacts and rail seating before reassembly
  • Building an X20 fieldbus-head assembly
  • Replacing the base beneath a compatible X20 bus controller and supply module
  • Mounting a compatible X20 hub and supply combination
Description
X20BB80 is a B&R bus controller bus base for the X20 System.

It provides the mechanical base and X20 bus contacts for the controller assembly, carries the 24 VDC I/O supply with a 10 A permissible contact load, and includes left and right end plates.

Before installation or replacement, confirm the complete material number, the exact bus controller or hub, matching supply module, terminal block, 24 VDC potential group, 10 A contact-load limit, included end plates, neighboring X20 slices, and station layout.
Alternative Names
X20BB80 X20 BB80 B&R X20BB80 B&R X20 BB80 BR X20BB80 B&R X20 System X20BB80 X20 System X20BB80
Technical notes
X20BB80 is the bus base for an X20 controller or hub assembly and its supply module. Confirm the complete controller-and-supply combination, end plates, 24 VDC potential group, 10 A contact-load limit, rail position, and neighboring module order before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is B&R X20BB80 an electronic bus controller?
No. It is the passive bus base; the compatible controller or hub and supply module are separate components.
What should be recorded before replacing B&R X20BB80?
Record the complete controller, supply module, terminal block, end plates, neighboring slices, potential groups, rail position, and wiring.
Can B&R X20BB80 be substituted with any standard X20 bus module?
No. Its wide mechanical layout is intended for a controller or hub plus supply module, so verify the exact assembly compatibility.
Why can an X20 station remain unpowered after replacing B&R X20BB80?
Check the supply module, terminal block, 24 VDC feed, fuse, potential-group path, bus contacts, rail seating, and module alignment.
Are end plates included with B&R X20BB80?
The official product page states that the left and right X20 end plates are included, but confirm the actual quoted stock contents.
What current limit matters when using B&R X20BB80?
The documented permissible contact load is 10 A; verify the complete downstream load and conductor protection.
When should B&R X20BB81 or X20BB82 be selected instead of X20BB80?
Select X20BB81 when one expansion slot is required, or X20BB82 when two expansion slots are needed for compatible X20 interface or hub add-on modules. X20BB80 is intended for installations that do not require these additional expansion slots.
