Features:
- Interface Between Rotating Machinery Casing and Condition Monitoring Systems
- Combines Capability of Vibration Velocity Measurement with Secure Mechanical Mounting Support
- Operates in Conjunction with Condition Monitoring and Protection Systems
The 190501-12-00-02 operates as the Velomitor CT Velocity Transducer in rotating machinery applications, providing reliable velocity signals for casing vibration monitoring systems. It continuously detects mechanical vibration from equipment surfaces and transmits accurate velocity data through its MIL-C-5015 connection interface to support steady state operation of condition monitoring and protection systems. Seamless signal transmission is standard with the 190501-12-00-02, however using its plate stud mounting hardware (3/8-24 to M8x1) will ensure optimal vibration coupling from the machinery casing to the sensor in demanding industrial environments. The 190501-12-00-02 has made improvements in several areas over previous velocity transducer designs in addition to incorporating rugged connection capability within harsh industrial conditions.
The 190501-12-00-02 provides essential vibration monitoring functions common to critical rotating equipment, and is a critical component of the protection path, directly affecting the proper, normal operation of the overall machinery system. One or multiple 190501-12-00-02 velocity transducers are required per machine depending on the desired monitoring coverage. The 190501-12-00-02 features compact plate stud mounting hardware for secure installation and is always positioned to ensure optimal vibration transmission from the equipment casing.
For Heavy-Duty Rotating Equipment applications, the 190501-12-00-02 Velomitor CT Velocity Transducer requires proper installation using its specified mounting hardware. In addition to standard single transducer operation, the secure mounting configuration also ensures accurate measurement repeatability. The 190501-12-00-02 vibration monitoring configuration executes reliable detection using the internal sensing element specified in the transducer specifications. Using this method, the velocity monitoring system continually tracks machinery vibration levels. If the system detects that the vibration amplitude is exceeding acceptable thresholds (outside configured tolerance levels), it will automatically alert operators and enable corrective actions to prevent equipment failure.
The 190501-12-00-02 Velomitor CT Velocity Transducer with MIL-C-5015 connection interface may still be available for purchase and support from authorized distributors beyond standard product lifecycle transitions by the manufacturer (OEM).
Bently Nevada 190501-12-00-02 Velomitor CT Velocity Transducer Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 190501-12-00-02 Velomitor CT Velocity Transducer
General
- Manufacturer GE / Bently Nevada
- Model 190501-12-00-02
- Condition New Original ready stock
- Product Family 190501-12-00-00,190501-12-00-01,190501-12-00-04
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Cooling Tower Fans: Its primary design intent is measuring casing vibration on cooling tower fan assemblies.
- Air-Cooled Heat Exchangers: Specifically suited for fan assemblies in these units.
- Low-Speed Machinery: Ideal for machines operating at or above 90 RPM (typically 100 to 300 RPM), including large pumps and fans.
- Malfunction Detection: Used to identify common rotor-related issues like unbalance and misalignment.
- Hazardous Area Protection: Designed for use in potentially dangerous settings with various agency approvals (e.g., ATEX, IECEx).
- Frequency Range: Adjusted downward to 1.5 Hz to 1.0 kHz (±3.0 dB) to capture low-frequency vibration signatures.
- Internal Diagnostics: Operating outside specified limits results in a "Not OK" status or loss of monitoring to prevent false readings.
- Robust Construction: Features a 316L stainless steel case, is hermetically sealed, and can withstand shocks up to 5,000 g pk.
- Bently Nevada Monitors: Directly compatible with Bently Nevada monitoring systems; requires selecting the "Velomitor CT" transducer type in software configurations.
- Standard Interface: Uses a common 2-pin MIL-C-5015 top connection.
- Interoperability: Can be used with non-standard monitors by setting appropriate "OK" limits and using "Prox/Accel" configuration jumpers on I/O modules.
- Cabling: Supports cable lengths up to 305 meters (1,000 ft) without signal degradation.
