21000-16-10-35-098-03-02

/ 4.9
1001 reviews | Need a Specific Revision?
The 21000-16-10-35-098-03-02 is a 21000 Series Proximity Probe Housing Assembly designed for use with 3300 XL 8 mm probes. This model features a 1.0 m (39 in) probe cable length, 3.5 in standoff adapter, and 9.8 in probe penetration.
Get a quick price for 21000-16-10-35-098-03-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 21000-16-10-35-098-03-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    21000-16-10-35-098-03-02
  • Product Family:
    21000, 24701, and 164818 Proximity Probe Housing A
  • Product Type:
    21000 Series Proximity Probe Housing Assembly
  • Compatible Probe:
    3300 XL 8 mm probe with connector
  • Probe Cable Length:
    1.0 m (39 in)
  • Standoff Adapter:
    3.5 in
  • Probe Penetration:
    9.8 in
  • Mounting Thread:
    3/4-14 NPT
  • Fittings Included:
    One 3/4-14 NPT plug, One 3/4-14 to 1/2-14 NPT reducer
  • Cable Seal Grip:
    Includes grommets for: 1/8-3/16 in, 1/4-5/16 in, 5/16-3/8 in
  • Housing Material:
    Aluminum
  • Enclosure Rating:
    CSA Type 4
  • Application:
    Intrinsically safe, hazardous areas
  • Key Benefit:
    Solves the pain point of probe installation in explosive environments through CSA explosion-proof certification and CSA Type 4 enclosure rating.
  • Weight:
    1.44 kg
  • Estimated shipping dimensions:
    60x8.5x8.5cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Communication Humidity and Protection

Features:

  • The 21000-16-10-35-098-03-02 features a rugged aluminum housing with CSA explosion-proof certification for hazardous areas.
  • This model includes a comprehensive cable seal grip with three grommet sizes accommodating 1/8 to 3/8 inch cables.
  • The 21000-16-10-35-098-03-02 is fully compliant with API 670 Standard for externally mounted proximity probe housings.
The 21000-16-10-35-098-03-02 includes essential sealing components that directly affect the proper operation of the monitoring system in harsh environments. It comes with one 3/4-14 NPT plug, one 3/4-14 to 1/2-14 NPT reducer, and a cable seal grip with grommets for multiple cable sizes: 1/8 to 3/16 inches, 1/4 to 5/16 inches, and 5/16 to 3/8 inches. The 21000-16-10-35-098-03-02 is certified as a CSA Type 4 enclosure, ensuring protection against water and dust ingress.

For hazardous area compliance, the 21000-16-10-35-098-03-02 is rated explosion-proof and suitable for intrinsically safe applications. This housing assembly is fully compliant with the American Petroleum Institute's API 670 Standard for externally mounted proximity probe housings. The 21000-16-10-35-098-03-02 features a 3/4-14 NPT mounting thread for secure attachment to machinery casings.

The 21000-16-10-35-098-03-02 represents a complete solution for externally mounted probe installations requiring hazardous area approvals. This assembly addresses the pain point of probe protection in explosive environments through its CSA certification. The 21000-16-10-35-098-03-02 ensures reliable vibration and position monitoring while meeting stringent API 670 requirements for petroleum industry applications.

The 21000-16-10-35-098-03-02 Bently Nevada 21000 Series Proximity Probe Housing Assembly may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 21000-16-10-35-098-03-02 21000 Series Proximity Probe Housing Assembly Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 21000-16-10-35-098-03-02 Proximity Probe Housing Assemblies Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 21000-16-10-35-098-03-02
  • Condition New Original ready stock
  • Product Family 21000-30-10-35-098-03-02,21000-32-10-35-098-03-02,21000-16-10-30-098-03-02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Axial/Thrust Position Monitoring: Monitors changes in the axial position of the rotor to prevent rotor collisions; a key data source for mechanical protection systems.
  • Rod Drop/Position Monitoring in Reciprocating Compressors: Used to monitor piston ring wear.
  • Keyphasor & Speed ​​Measurement: Serves as a phase reference sensor, providing speed signals and assisting in mechanical fault diagnosis.
  • Signal Transmission and Communication: Analog Signal Output: The analog voltage signal output from the preamplifier is typically connected to a Bently Nevada 3500 system or a 990/991 series transmitter.
  • Digital Integration: Through the monitoring system's communication gateway module (such as Modbus or Ethernet/IP), measurement data can be transmitted in real time to System 1 software or a DCS system for data analysis and alarm management.
  • Configuration Considerations: Gap Voltage: During installation, the gap between the probe and the measured surface must be adjusted. The output voltage is typically positioned at the midpoint of linearity (approximately -9V to -11V DC) to ensure optimal measurement results.
  • Humidity Tolerance: This housing is designed for extreme industrial environments and has passed the humidity and heat test specified in IEC 68-2-3.
  • Sealing and Protection Rating: It has a CSA Type 4 (equivalent to IP66) protection rating, completely preventing dust ingress and resisting strong water spray.
  • It employs a triple O-ring sealing system to effectively prevent moisture, oil mist, and contaminants from penetrating the internal probe space.
Description
The 21000-16-10-35-098-03-02 features a rugged aluminum housing designed for use with 3300 XL 8 mm probes in hazardous area applications. This model includes a 1.0 m (39 in) probe cable length, 3.5 in standoff adapter, and 9.8 in probe penetration for precise positioning in critical machinery.

The 21000-16-10-35-098-03-02 includes a comprehensive cable seal grip with grommets accommodating multiple cable sizes: 1/8 to 3/16 inches, 1/4 to 5/16 inches, and 5/16 to 3/8 inches. This 21000 series assembly is CSA approved as explosion-proof for hazardous areas and certified as a CSA Type 4 enclosure, ensuring reliable operation in demanding environments.

The 21000-16-10-35-098-03-02 is available for intrinsically safe applications requiring aluminum construction. This housing assembly provides robust protection for 3300 XL 8 mm probes while maintaining accessibility for installation and maintenance.

The 21000-16-10-35-098-03-02 represents a complete solution for externally mounted proximity probe installations in hazardous areas. This assembly addresses the pain point of probe protection in explosive environments through its CSA explosion-proof rating.
Alternative Names
21000-30-10-35-098-03-02 21000-32-10-35-098-03-02 21000-16-30-35-098-03-02 21000-16-36-35-098-03-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the difference between the 21000-16-10-35-098-03-02 aluminum housing and the 24701 stainless steel version?
The 21000-16-10-35-098-03-02 uses lightweight aluminum construction, while 24701 offers stainless steel for enhanced corrosion resistance in aggressive environments. Both are CSA Type 4 and API 670 compliant.
How can I identify a quality supplier for the 21000-16-10-35-098-03-02?
Verify the supplier provides genuine CSA explosion-proof certification documentation, authentic API 670 compliance verification, and complete grommet sets for all specified cable sizes with the 21000-16-10-35-098-03-02.
Does the 21000-16-10-35-098-03-02 require additional certifications for export to the United States?
The CSA explosion-proof certification satisfies US hazardous location requirements. No additional certifications are needed for standard industrial installations.
Why do probe housings like the 21000-16-10-35-098-03-02 experience seal failure?
Without proper grommet selection, cable entry points leak. The 21000-16-10-35-098-03-02 prevents this with three precision grommet sizes covering 1/8 to 3/8 inch cables.
