24701-28-05-00-038-04-02

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 24701-28-05-00-038-04-02 is a stainless-steel proximity probe housing assembly configured with a 3300 XL 8 mm probe and a 0.5 m cable.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 24701-28-05-00-038-04-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 24701-28-05-00-038-04-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    24701-28-05-00-038-04-02
  • Product Family:
    21000, 24701, and 164818 Proximity Probe Housing A
  • Product Type:
    Proximity Probe Housing Assembly
  • Stock:
    1
  • Probe with Connector:
    3300 XL 8 mm, with approval option
  • Probe Cable Length:
    20 in (0.5 m)
  • Standoff Adapter:
    None
  • Probe Penetration:
    3.8 in (approximately 97 mm)
  • Fittings Option:
    One 3/4-14 NPT plug only
  • Mounting Thread:
    3/4-14 NPT
  • Housing Material:
    303 stainless-steel body with a 304 stainless-steel sleeve
  • Weight:
    1.8 kg
  • Estimated shipping dimensions:
    26 × 7.8 × 7.8 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Monitoring Performance Application Scenarios

Features:

  • 303 stainless-steel body with a 304 stainless-steel sleeve
  • Includes a 3300 XL 8 mm probe with a 0.5 m cable
  • CSA Type 4 and API 670 compliant; hazardous-area approval depends on the exact configuration
Bently Nevada 24701-28-05-00-038-04-02 provides a practical mounting solution for proximity probes that need to be installed externally on industrial machinery. The stainless steel housing helps organize the mechanical interface between the machine case, probe, sleeve, and associated connection hardware. A 3300 XL 8 mm probe is incorporated into the specified configuration, allowing the assembly to support proximity-based machine measurements. External mounting can also simplify access to probe hardware during inspection and service activities.

For machinery environments requiring sturdy metallic components, Bently Nevada 24701-28-05-00-038-04-02 combines a 303 stainless steel body with a 304 stainless steel sleeve. The 3.8-inch penetration dimension defines how far the probe assembly extends into the mounting location, while the 3/4-14 NPT thread provides the mechanical connection to the machine. No standoff adapter is included, producing a direct installation arrangement for applications matching the specified geometry. One 3/4-14 NPT plug completes the listed fitting configuration.

Bently Nevada 24701-28-05-00-038-04-02 also fits machinery monitoring projects where recognized hazardous-area and enclosure standards are important. The 24701 housing design is available for use with hazardous-area-approved probes in intrinsically safe applications. Bently Nevada identifies the 21000 and 24701 housings as CSA Type 4 enclosures and compliant with API 670 requirements for externally mounted proximity probe housings. CSA explosion-proof certification applies to the corresponding CA24701 configuration and approved ordering combination.

Availability of 24701-28-05-00-038-04-02 should be confirmed with Apter Power. The available official documentation does not state an OEM lifecycle classification for this complete ordering configuration.
Bently Nevada 24701-28-05-00-038-04-02 Proximity Probe Housing Assembly Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 24701-28-05-00-038-04-02 Proximity Probe Housing Assembly Specs

General

  • Manufacturer Bently Nevada
  • Model 24701-28-05-00-038-04-02
  • Condition New and unused — subject to inspection and stock confirmation by Apter Power
  • Product Family 24701 Proximity Probe Housing Assembly
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • External Probe Access: The housing provides external access to the proximity probe and its extension cable.
  • Probe Gap Adjustment: The external housing arrangement permits probe gap adjustment without machine disassembly.
  • Probe Replacement: The proximity probe can be replaced through the housing without disassembling the machine.
  • Configured Probe: Ordering option -28 specifies a 3300 XL 8 mm probe with an approval option.
  • Housing Material: 303 stainless-steel body with a 304 stainless-steel sleeve.
  • Typical Mass: 1.8 kg (4.1 lb), without fittings.
  • Probe Penetration: 3.8 in (approximately 97 mm).
  • Mounting Connection: 3/4-14 NPT mounting thread.
  • Fitting Configuration: One 3/4-14 NPT plug only.
  • Standoff Configuration: No standoff adapter.
  • External Probe Mounting: For externally mounting a proximity probe on machinery.
  • Service Access: Suitable where access is required for probe gap adjustment or probe replacement without machine disassembly.
  • Direct Mounting Arrangement: Configured without a standoff adapter for installations matching the specified 3.8 in penetration and 3/4-14 NPT mounting thread.
  • Intrinsically Safe Installations: The standard 24701 housing can be ordered with hazardous-area-approved probes for intrinsically safe applications, subject to the exact probe approval and installation documentation.
  • Long-Sleeve Installations: Other 24701 configurations with sleeve lengths greater than 304 mm (12 in) require additional sleeve support.
Description
Bently Nevada 24701-28-05-00-038-04-02 belongs to the 24701 stainless steel proximity probe housing family used for externally mounted proximity probes. The assembly uses a 303 stainless steel body together with a 304 stainless steel sleeve, providing an all-metal construction for industrial machinery installations. A 3300 XL 8 mm proximity probe with approval option is included in the specified configuration, while the probe cable length is 20 inches or 0.5 meters. The housing arrangement supports reliable probe mounting where external access and mechanical protection are required.

The mechanical configuration of Bently Nevada 24701-28-05-00-038-04-02 provides a 3.8-inch probe penetration dimension and does not include a standoff adapter. A 3/4-14 NPT mounting thread is used for installation, and the fitting configuration consists of one 3/4-14 NPT plug only. The housing family includes a dome cover that screws into the housing body, threaded ports for conduit connections, a probe sleeve, O-rings, a reverse mount proximity probe, a thread seal, and optional conduit fittings. Such construction provides an organized interface between the proximity probe and the machine casing.

Bently Nevada identifies the 21000 and 24701 housing designs as CSA Type 4 enclosures and compliant with API 670 requirements for externally mounted proximity probe housings. The standard 24701 housing can be ordered with hazardous-area-approved probes for intrinsically safe applications. CSA explosion-proof housing certification applies to the corresponding CA24701 configuration and approved ordering combination.

For other 24701 configurations, sleeve length is determined by the actual mounting position, and the probe lead must be longer than the sleeve. Sleeve lengths greater than 304 mm (12 in) require additional support to reduce vibration associated with unsupported long sleeves. Bently Nevada offers probe support and oil seal part number 37948-01 for long sleeves passing through an inner bearing housing.
Alternative Names
247012805000380402 24701 28 05 00 038 04 02 Bently Nevada 24701-28-05-00-038-04-02 24701 Stainless-Steel Proximity Probe Housing Assembly
Technical notes
The 24701-28-05-00-038-04-02 assembly provides external access to the proximity probe and its extension cable, permitting probe gap adjustment or replacement without machine disassembly.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What does Bently Nevada 24701-28-05-00-038-04-02 include for proximity probe installation?
Bently Nevada 24701-28-05-00-038-04-02 includes a 3300 XL 8 mm proximity probe with approval option and a 20-inch or 0.5-meter probe cable. The housing uses a stainless steel construction and provides the required mounting arrangement for externally installed proximity probes.
How does Bently Nevada 24701-28-05-00-038-04-02 mount to machinery?
Bently Nevada 24701-28-05-00-038-04-02 uses a 3/4-14 NPT mounting thread and provides a probe penetration dimension of 3.8 inches. No standoff adapter is included in the specified configuration.
Can Bently Nevada 24701-28-05-00-038-04-02 be used in hazardous-area applications?
Hazardous-area suitability depends on the exact housing version, probe approval and installation documentation. The standard 24701 housing can be ordered with hazardous-area-approved probes for intrinsically safe applications, while CSA explosion-proof housing certification applies to the corresponding CA24701 configuration.
Does Bently Nevada 24701-28-05-00-038-04-02 meet API 670 requirements?
Bently Nevada states that the 21000 and 24701 housing designs comply with API 670 requirements for externally mounted proximity probe housings and are certified as CSA Type 4 enclosures. Hazardous-area approval must be verified separately for the exact ordered configuration.
