146054-058-20-02-05 MOD:173931-011-058

/ 4.9
1001 reviews | Need a Specific Revision?
The 146054-058-20-02-05 (MOD: 173931-011-058) is a Bently Nevada 3300 Series proximity probe featuring an alumina ceramic tip, specifically designed for highly corrosive chemical gases and high-pressure operating conditions.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 146054-058-20-02-05 MOD:173931-011-058
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 146054-058-20-02-05 MOD:173931-011-058

  • Manufacturer:
    Bently Nevada
  • Part Number:
    146054-058-20-02-05 MOD:173931-011-058
  • Product Family:
    3300 System
  • Product Type:
    3300 Ceramic Capped Probe
  • Stock:
    1
  • Thread & Mount Style:
    3/8-24 UNF thread, Forward Mount
  • Overall Case Length:
    5.8 in
  • Total Length:
    2.0 meters (6.6 feet)
  • Connector & Cable Option:
    Miniature coaxial ClickLoc connector, standard cable
  • Agency Approval Option:
    CSA, ATEX, IECEx (Multiple Approvals)
  • Probe Tip Material:
    Alumina ceramic (Al2O3)
  • Probe Case Material:
    AISI 304 Stainless Steel
  • Cable Type:
    75 ohm coaxial, fluoroethylene propylene (FEP) insulated
  • Connector Material:
    Gold-plated brass / gold-plated beryllium copper
  • Linear Range:
    1.52 mm (60 mils), starting approximately 0.25 mm (10 mils) from target
  • Recommended Gap Setting:
    1.0 mm (40 mils)
  • Incremental Scale Factor (ISF):
    7.87 V/mm (200 mV/mil) ± 6.5%
  • Pressure Rating:
    Rated to seal 34 Bar (500 psi) nitrogen at the front end
  • Operating Temperature Range:
    -51°C to +177°C (-60°F to +351°F)
  • Minimum Cable Bend Radius:
    25.4 mm (1.0 in)
  • Target Material:
    AISI 4140 Steel (Standard Calibration)
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Installation & Integration Safety & Compliance Compatibility

Features:

  • 3/8-24 UNF threaded stainless steel case with an overall length of 5.8 inches.
  • Alumina ceramic tip (Al2O3) designed for high-pressure and extreme pH conditions.
  • Integrated 2.0-meter coaxial cable with gold-plated ClickLoc connector.
The 146054-058-20-02-05 MOD:173931-011-058 represents a factory-modified 3300 ceramic capped proximity probe, featuring an extended 5.8-inch AISI 304 stainless steel case and a 2.0-meter FEP-insulated coaxial cable.

Designed for machinery protection in harsh process environments, this probe unit transmits non-contact vibration and position signals through its helium-leak-tested ceramic-to-metal interface to a compatible Proximitor Sensor.

Installation requires precise electrical gapping to avoid mechanical contact with the target surface, and the unsealed rear portion of the assembly must be isolated from corrosive liquids or gases.

Availability,The 146054-058-20-02-05 MOD:173931-011-058 is fully surplus / newly original, verified and guaranteed by the manufacturer (OEM).
Bently Nevada 146054-058-20-02-05 MOD:173931-011-058 Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Monitors shaft vibration and axial position on rotating machinery in anhydrous ammonia environments.
  • Protects critical turbomachinery operating in high-pressure gas or fluid atmospheres.
  • Provides continuous proximity sensing for industrial equipment exposed to aggressive chemical process media.
  • Mounts forward into machinery casings using standard 3/8-24 UNF 2A external threads with a maximum engagement depth of 0.563 inches.
  • Connects to extension cables using a miniature gold-plated ClickLoc coaxial connector that locks with finger-tight torque.
  • Requires a minimum cable bend radius of 25.4 mm (1.0 inch) during routing through conduit or enclosure paths.
  • Approved for Class I, Zone 0/Zone 2 intrinsically safe and non-incendive hazardous area installations under CSA, ATEX, and IECEx standards.
  • Complies with European Community Directive RoHS 2011/65/EU and China RoHS SJ/T 11364-2024 regulations.
  • Meets American Bureau of Shipping (ABS) Maritime classification rules for offshore units and marine structures.
  • Operates in conjunction with 3300 Proximitor Sensors and standard 75-ohm FEP-insulated extension cables.
  • Calibrated for optimal interchangeability and linear range performance when targeting AISI 4140 steel surfaces.
  • Interfaces with 3300 series machinery monitoring systems configured to accommodate shifted linear curve characteristics.
Description
The Bently Nevada 146054-058-20-02-05 MOD:173931-011-058 is an advanced proximity probe designed to withstand severe process conditions that destroy standard sensors. Featuring an alumina ceramic cap and a 304 stainless steel case, the 146054-058-20-02-05 MOD:173931-011-058 provides robust resistance against aggressive chemical media such as anhydrous ammonia and high-pressure fluids. Its helium-leak-tested ceramic-to-metal interface ensures a reliable front-end seal for critical rotating equipment monitoring.

Engineered for machinery protection in ammonia plants, chemical refineries, and offshore platforms, the 146054-058-20-02-05 MOD:173931-011-058 serves as a front-end transducer in severe pH environments. This probe communicates seamlessly with 3300 Proximitor Sensors and extension cables to transmit precise gap and vibration signals. The 146054-058-20-02-05 MOD:173931-011-058 is specifically applied where corrosive gases or liquids are present at the probe tip while protecting internal components.

Equipped with a 2.0-meter fluoroethylene propylene insulated cable and gold-plated ClickLoc connectors, the 146054-058-20-02-05 MOD:173931-011-058 prevents connector loosening without requiring special installation tools. Certified under multiple hazardous area standards including ATEX and IECEx, this model meets strict industrial safety compliance requirements. Incorporating the 146054-058-20-02-05 MOD:173931-011-058 into your machinery monitoring infrastructure optimizes asset uptime and extends transducer service life.
Alternative Names
146054-058-20-02-05 173931-011-058 146054058200205 MOD173931011058 146054-058-20-02-05 MOD:173931-011-058 146054-058-20-02-05 173931-011-058 Bently Nevada 146054-058-20-02-05 MOD:173931-011-058 3300 Ceramic Capped Probe 146054-058-20-02-0
Technical notes
The 146054-058-20-02-05 MOD:173931-011-058 requires precise electrical gapping without target contact due to its alumina ceramic tip. Avoid exposing its unsealed rear assembly to corrosive fluids like NH3 or H2S.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the pressure rating of the 146054-058-20-02-05 MOD:173931-011-058 front tip?
The front-end ceramic-to-metal seal of the 146054-058-20-02-05 MOD:173931-011-058 is helium leak-tested and rated to seal pressure up to 34 Bar (500 psi) nitrogen.
Is the rear connection of the 146054-058-20-02-05 MOD:173931-011-058 sealed against fluids?
No, the 146054 series probes do not have a sealed rear fitting or stainless steel armor tube, so the rear of the 146054-058-20-02-05 MOD:173931-011-058 must not be exposed to corrosive gases or liquids.
What is the tightening requirement for the ClickLoc connector on 146054-058-20-02-05 MOD:173931-011-058?
The gold-plated ClickLoc connector on the 146054-058-20-02-05 MOD:173931-011-058 requires only finger-tight torque until it clicks, preventing accidental loosening without requiring special tools.
Which Proximitor Sensors and extension cables are compatible with 146054-058-20-02-05 MOD:173931-011-058?
The 146054-058-20-02-05 MOD:173931-011-058 is fully compatible with Bently Nevada 3300 Proximitor Sensors and matching 75 ohm extension cables configured for a 5-meter or 9-meter overall system length.
What should be considered when setting the gap for 146054-058-20-02-05 MOD:173931-011-058?
Set the gap electrically to the recommended 1.0 mm (40 mils) setting without making direct mechanical contact with the shaft, as the ceramic tip cannot withstand direct physical impact.
How can I request a quotation or check availability for 146054-058-20-02-05 MOD:173931-011-058?
You can submit an inquiry directly through our sales contact form with the full part number 146054-058-20-02-05 MOD:173931-011-058 to receive real-time pricing, stock status, and lead time details.
