Bently Nevada 330703-000-060-50-12-00
Bently Nevada 330703-000-060-50-12-00
Bently Nevada 330703-000-060-50-12-00
Bently Nevada 330703-000-060-50-12-00
Bently Nevada 330703-000-060-50-12-00
Bently Nevada 330703-000-060-50-12-00
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com
  • Lifecycle status

    Active / Available from OEM
    Apter Power provides quotations, technical documents, sourcing support, and system matching guidance for this product.

330703-000-060-50-12-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330703-000-060-50-12-00 is a 3300 XL 11 mm proximity probe with M14 x 1.5 thread, without armor, 0 mm unthreaded length, 60 mm case length, 5.0 m (16.4 ft) total length, fluidloc cable, connector protector not included, and no agency approval.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330703-000-060-50-12-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330703-000-060-50-12-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330703-000-060-50-12-00
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Stock:
    1
  • Probe Thread:
    M14 x 1.5
  • Armor:
    Without armor
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    60 mm
  • Total Length:
    5.0 m (16.4 ft)
  • Connector and Cable:
    Miniature coaxial ClickLoc, fluidloc cable, protector not included
  • Agency Approval:
    No agency approval
  • Linear Range:
    4.0 mm (160 mils)
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    2.5x2x124cm
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Ordering Code System Matching Installation

Product overview:

  • •Measurement: Non-contact eddy-current sensing for radial vibration and shaft-position applications
  • •Mechanical configuration: M14 x 1.5 thread, without armor, 0 mm unthreaded length, 60 mm case length
  • •Cable configuration: 5.0 m (16.4 ft), fluidloc cable, connector protector not included

Bently Nevada 330703-000-060-50-12-00 is a 3300 XL 11 mm proximity probe with M14 x 1.5 thread, without armor, 0 mm unthreaded length, 60 mm case length, 5.0 m (16.4 ft) total length, fluidloc cable, connector protector not included, and no agency approval.

The 5.0 m probe is intended for direct use with a compatible 5 m Proximitor Sensor.

Availability is subject to Apter Power's current inventory and sourcing confirmation.

Bently Nevada 330703-000-060-50-12-00 Specs

General

ManufacturerBently Nevada
Model330703-000-060-50-12-00
ConditionNew and factory sealed
Product Family3300 XL 11mm Proximity Transducer System

Ordering code breakdown

  • •Base model: 330703 3300 XL 11 mm proximity probe
  • •Probe thread: M14 x 1.5
  • •Unthreaded length: 0 mm
  • •Overall case length: 60 mm
  • •Total length: 5.0 m (16.4 ft)
  • •Connector code 12: Miniature coaxial ClickLoc, fluidloc cable, protector not included
  • •Approval code 00: No agency approval

System matching guidance

  • •5 m system: Connect the 5.0 m probe directly to a compatible 5 m Proximitor Sensor
  • •Extension cable: Do not add an extension cable to this 5.0 m probe configuration
  • •Electrical length: Keep the probe and Proximitor Sensor matched to the 5 m system
  • •Scale factor: 3.94 V/mm (100 mV/mil)
  • •Reference target: Official performance data is based on AISI 4140 steel

Installation checks

  • •Recommended gap: 2.5 mm (100 mils)
  • •Target guidance: 30.5 mm (1.2 in) recommended minimum flat target
  • •Shaft guidance: 152 mm (6.0 in) recommended minimum
  • •Connector: Install the ClickLoc connector finger tight; no special tool is required
  • •Cable routing: Protect the connector and avoid sharp bends, crushing, or unsupported cable loads
  • •Commissioning: Verify bracket stiffness, target material, viewing clearance, and system matching
Description

The Bently Nevada 330703-000-060-50-12-00 is a 3300 XL 11 mm proximity probe with M14 x 1.5 thread, without armor, 0 mm unthreaded length, 60 mm case length, 5.0 m (16.4 ft) total length, fluidloc cable, connector protector not included, and no agency approval.

The 3300 XL 11mm Proximity Transducer System provides non-contact measurement for radial vibration and shaft position. Official system data specifies a 4.0 mm (160 mils) linear range, a nominal scale factor of 3.94 V/mm (100 mV/mil), and an AISI 4140 steel reference target.

The 5.0 m probe is intended for direct use with a compatible 5 m Proximitor Sensor. Set the probe near the recommended 2.5 mm (100 mils) gap and confirm target material, mechanical mounting, cable routing, and applicable approvals before installation.

Alternative Names
330703-000-060-50-12-00 Bently Nevada 330703-000-060-50-12-00 Baker Hughes Bently Nevada 330703-000-060-50-12-00 330703-000-060-50-12-00 proximity probe 330703-000-060-50-12-00 eddy current probe 330703-000-060-50-12-00 3300 XL 11 mm proximity probe 330703-000-060-50-12-00 datasheet 330703000060501200
Technical notes
330703-000-060-50-12-00 uses a M14 x 1.5 case with 5.0 m (16.4 ft) total length. The 5.0 m probe is intended for direct use with a compatible 5 m Proximitor Sensor.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the Bently Nevada 330703-000-060-50-12-00?
It is a 3300 XL 11 mm proximity probe for non-contact vibration and shaft-position measurement.
What thread and armor configuration does 330703-000-060-50-12-00 use?
It uses a M14 x 1.5 thread and is supplied without armor.
What are the case dimensions for 330703-000-060-50-12-00?
The unthreaded length is 0 mm, and the overall case length is 60 mm.
What is the total length of 330703-000-060-50-12-00?
The specified total length is 5.0 m (16.4 ft).
Which connector and cable option does 330703-000-060-50-12-00 use?
It uses a Miniature coaxial ClickLoc with fluidloc cable; the protector is not included.
What approval option is specified for 330703-000-060-50-12-00?
Ordering code 00 indicates no agency approval.
How should 330703-000-060-50-12-00 be matched to the system?
The 5.0 m probe is intended for direct use with a compatible 5 m Proximitor Sensor.
Is 330703-000-060-50-12-00 currently available?
Current official documentation lists the product family; Apter Power can confirm stock, sourcing, and lead time.
