330709-00-05-10-12-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Model 330709-00-05-10-12-05 is a 3300 XL 11 mm proximity probe featuring M16 x 1.5 metric mounting threads without armor, designed for industrial machinery monitoring applications requiring larger diameter probe construction.
Get a quick price for 330709-00-05-10-12-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330709-00-05-10-12-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330709-00-05-10-12-05
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Probe Type:
    3300 XL 11 mm Proximity Probe
  • Mounting Thread:
    M16 x 1.5
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    50 mm
  • Total Length:
    1.0 meter (3.3 feet)
  • Connector Type:
    Miniature coaxial ClickLoc
  • Cable Type:
    FluidLoc cable
  • Agency Approvals:
    Multiple Approvals
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    20.5x22.4x3.3cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications

Features:

  • 11 mm probe with M16 x 1.5 metric threads and flush-mount design
  • FluidLoc cable with patented TipLoc and CableLoc construction
  • Gold-plated ClickLoc connectors and hazardous area approvals
The 330709-00-05-10-12-05 provides essential sensing functions critical to the entire monitoring path, serving as the primary interface between the rotating machinery and the monitoring system, directly affecting the proper, normal operation of the overall protection system. One 330709-00-05-10-12-05 probe is required per measurement point, installed flush in the machine casing with the M16 x 1.5 metric mounting threads.

For applications requiring fluid containment and hazardous area compliance, the 330709-00-05-10-12-05 incorporates the FluidLoc cable option spanning its 1.0 meter total length. This specialized cable construction prevents oil and process fluids from migrating through the cable interior and leaking from the machine casing.

The 330709-00-05-10-12-05's rugged construction ensures reliable operation in demanding industrial environments. Using patented TipLoc molding method, the probe provides robust tip-to-body bonding, while the patented CableLoc design securely attaches the cable with 330 N pull strength. The gold-plated brass ClickLoc connectors on the 330709-00-05-10-12-05 lock into place, preventing connection loosening from vibration, and enable tool-free installation.

The 330709-00-05-10-12-05 Bently Nevada 11 mm Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330709-00-05-10-12-05 11 mm Probe Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330709-00-05-10-12-05 11 mm Probe Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330709-00-05-10-12-05
  • Condition New Original ready stock
  • Product Family 330709-00-05-10-01-05,330709-00-05-10-1112-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
The Model 330709-00-05-10-12-05 is a precision-engineered 3300 XL 11 mm proximity probe configured with M16 x 1.5 metric mounting threads and zero unthreaded length for flush mounting applications requiring fluid containment. This non-armored version features an overall case length of 50 mm, providing a compact profile suitable for installations with standard clearance requirements.

What distinguishes the 330709-00-05-10-12-05 is its integration of the FluidLoc cable option, which creates a barrier against oil and other process liquids migrating through the cable interior and potentially leaking from the machine casing. This design consideration is essential for maintaining environmental integrity in rotating machinery applications where bearing lubrication or process fluids are present.

Mechanical robustness is a defining characteristic of the 330709-00-05-10-12-05, featuring the patented CableLoc design that securely attaches the probe cable to the probe tip with an impressive 330 N (75 lb) pull strength, ensuring the cable remains securely attached even under significant mechanical stress during installation and operation.

The connector system on the 330709-00-05-10-12-05 features a miniature coaxial ClickLoc connector with gold-plated brass contacts, enabling rapid, tool-free installation while delivering a secure locking mechanism. The FluidLoc cable of the 330709-00-05-10-12-05 provides reliable signal transmission while preventing fluid migration along the cable path.
Alternative Names
330709-00-05-10-01-05 330709-00-05-10-11-05 330709-00-05-10-02-05 330709-00-05-10-12-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What are the key dimensional and mechanical specifications for the 330709-00-05-10-12-05 probe?
The 330709-00-05-10-12-05 features M16 x 1.5 metric mounting threads, a zero unthreaded length (0 mm) for flush mounting applications, and an overall case length of 50 mm. The total length of the probe assembly, including the integral FluidLoc cable, is 1.0 meter (3.3 feet), terminated with a miniature coaxial ClickLoc connector featuring gold-plated brass contacts. The probe incorporates patented TipLoc molding method and CableLoc design providing 330 N (75 lb) pull strength, and includes a standard locknut with pre-drilled safety wire holes.
What is the FluidLoc cable option on the 330709-00-05-10-12-05 and why is it important?
The 330709-00-05-10-12-05 features the FluidLoc cable option, which is specifically designed to prevent oil and other liquids from leaking out of the machine through the cable's interior. This is critical for applications involving rotating machinery with lubricated bearings or process fluids, as it maintains environmental containment and prevents fluid migration that could compromise monitoring system integrity or create safety hazards. The FluidLoc cable works in conjunction with the probe's robust mechanical construction to ensure long-term reliability.
What agency approvals does the 330709-00-05-10-12-05 carry for hazardous area installations?
The 330709-00-05-10-12-05 carries multiple agency approvals for hazardous area installations, making it suitable for use in potentially explosive atmospheres where certified equipment is required. These certifications ensure the probe meets rigorous international safety standards for use in hazardous locations, in addition to its FluidLoc fluid containment capabilities. The combination of hazardous area certifications and fluid containment makes this probe ideal for demanding applications in petrochemical, refining, and other safety-regulated industries.
Is the 330709-00-05-10-12-05 compatible with existing Bently Nevada monitoring systems?
Yes. The 330709-00-05-10-12-05 is fully compatible with the 3300 XL 11 mm transducer system family and features gold-plated brass ClickLoc connectors that lock into place, preventing connection loosening from vibration. The probe is available in various case configurations including multiple thread options such as ½-20, 5⁄8-18, M14 x 1.5, and M16 x 1.5, with reverse mount versions available in 3⁄8-24 or M10 x 1 threads. Optional connector protectors are recommended for all installations to provide increased environmental protection in humid or moist environments.
