330730-040-01-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 24701-33-05-00-029-04-02 is an industrial vibration monitoring and signal interface component designed for use within Bently Nevada machinery condition monitoring systems.
Get a quick price for 330730-040-01-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330730-040-01-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330730-040-01-05
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Series:
    3300 XL 11 mm Extension Cable
  • Cable Length:
    4.0 meters (13.1 feet)
  • Connector and Cable Type:
    Armored cable
  • Agency Approvals:
    Multiple Approvals
  • Operating and Storage Temperature:
    –52°C to +177°C (–62°F to +351°F)
  • Cable Type:
    75 Ω triaxial shielded, FEP-insulated
  • Cable Sheath:
    Flexible AISI 302 stainless steel with FEP outer layer
  • Cable Capacitance:
    69.9 pF/m (21.3 pF/ft) typical
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    20.5x22.4x3.3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Diagnostics & Protection Installation & Integration Operating Environment


Features:

  • Maintains Stable Signal Transmission Between the Proximity Probe and Monitoring System
  • Combines Durable Cable Construction with Effective Electromagnetic Interference Protection
  • Designed for Reliable Integration with Bently Nevada 3300 XL Proximity Probe Systems
The Bently Nevada 330730-040-01-05 functions as a proximity probe extension cable within the Bently Nevada 3300 XL vibration monitoring system, providing a stable electrical link between the proximity probe and the Proximitor sensor. It ensures accurate transmission of displacement and vibration signals from the probe to the monitoring module, supporting precise measurement of shaft position and machinery vibration. The cable is engineered to maintain consistent signal quality across the monitoring chain used in rotating equipment protection systems.

The Bently Nevada 330730-040-01-05 provides essential signal transmission functions for the 3300 XL monitoring system and is a critical component of the monitoring path, directly affecting accurate measurement of shaft vibration and displacement. One or more 330730-040-01-05 cables may be installed per machine depending on the number of measurement points and system configuration. The cable occupies a single connection location between the proximity probe and the Proximitor sensor, and is always routed to maintain proper alignment and signal integrity within the monitoring system.

For dual‑probe or multi‑cable monitoring applications, the 3300 XL system may require an additional 330730-040-01-05 extension cable installed to accommodate multiple measurement points or redundant signal paths. In addition to standard single‑probe operation, the redundant or multi‑cable configuration supports uninterrupted signal transmission. The system continually monitors the integrity of each cable and its connected probe. If a cable or probe connection is detected to be faulty or producing signals outside the expected range, the system automatically relies on the secondary or redundant cable to maintain accurate vibration and displacement measurement, while generating an alert or event in the monitoring system log.

The 330730-040-01-05 Bently Nevada high-performance cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330730-040-01-05 Proximity Probe Extension Cable Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
 Bently Nevada 330730-040-01-05 3300 XL Proximity Probe Extension Cable Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330730-040-01-05
  • Condition New Original ready stock
  • Product Family 330730-040-01-00,330730-040-00-05,330730-040-00-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Displacement and vibration measurement: The system outputs a voltage signal proportional to the distance from the probe end face to the measured metal surface (standard sensitivity is 3.94 V/mm or 100 mV/mil), used to monitor axial displacement (thrust) and radial vibration.
  • Mechanical Protection Applications:
  • Thrust Position Measurement: Prevents rotor-stator collision.
  • Differential Expansion Monitoring: Monitors the expansion difference between the rotor and the casing during turbine startup and shutdown.
  • Overspeed Protection: Can be used as a tachometer or keyphasor signal source, working in conjunction with the monitoring module to achieve overspeed protection.
  • System Stability and Interference Immunity:
  • RFI/EMI Immunity: Improved electromagnetic interference immunity design prevents false alarms or diagnostic errors caused by high-frequency radio signals in industrial environments.
  • Physical Protection: Equipped with FluidLoc sealing technology (to prevent liquid leakage) and electrostatic discharge (ESD) protection to ensure signal integrity in harsh environments.
  • Connector Installation: This cable uses ClickLoc gold connectors, which can be tightened simply by hand. A "click" indicates that it is locked in place; no wrench is needed, as excessive torque may damage the connector.
  • Connector Protector: The -01 option in the model number indicates that a connector protector is included. In humid, oily, or contaminated environments, ensure that the protector completely covers the connector to prevent signal attenuation or galvanic corrosion.
  • Complete Replacement Policy: All components of the 3300 XL 11mm system (probe, extension cable, preamplifier) ​​must be replaced with the purple-coded components of this series. It is strictly forbidden to mix them with older models or other series (such as the 8mm system).
  • Temperature Range: Operating and Storage Temperature: Standard range is -51°C to +177°C (-60°F to +350°F).
  • Accuracy Limits: To ensure optimal measurement accuracy (ISF within ±25%), it is recommended that the cable ambient temperature be maintained between -35°C and +65°C.
  • Humidity Tolerance: When the connector is protected by the protector (option -01 in the model number), it can withstand 100% condensation humidity, but it must not be immersed in liquid.
  • Chemical and Liquid Protection: Corrosion Resistance: The external stainless steel armor (AISI 302) provides excellent abrasion resistance, chemical resistance, and moisture protection. Leakage Prevention Design: Optional FluidLoctechnology (usually with different suffixes) prevents oil or other liquids from leaking into the machine through the cable interior.
Description
It plays an important role in transmitting and conditioning signals between vibration sensors and monitoring equipment, enabling accurate detection of mechanical conditions such as shaft vibration, displacement, and other dynamic parameters in rotating machinery. This capability allows operators to continuously monitor equipment health and respond quickly to abnormal operating conditions.

Constructed with a stainless steel housing body and engineered for long‑term durability in demanding industrial environments, the 24701‑33‑05‑00‑024‑04‑02 assembly includes a probe with connector protector and is configured with a 0.5 m probe cable length option.

The probe penetration length of approximately 2.4 in (60 mm) ensures appropriate reach into the measurement area, while the housing provides threaded ports for conduit connections and optional standoff adapters for flexible installation.

The housing assembly is fully compatible with Bently Nevada’s 3300 series proximity transducers and condition monitoring systems, enabling seamless system integration. Its modular build and accessory features support reliable data collection for real‑time condition assessment and predictive maintenance strategies, enhancing equipment reliability and helping prevent unplanned downtime.
Alternative Names
330730-040-01-00 330730-040-00-05 330730-040-00-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the primary purpose of the 330730-040-01-05 extension cable?
It extends the reach of 3300 XL proximity probes while maintaining accurate and stable signal transmission.
What type of cable and shielding does this model use?
It uses a 75 Ω triaxial shielded cable with FEP insulation and a flexible AISI 302 stainless steel sheath with FEP outer layer.
What is the cable length?
This cable has a total length of 4.0 meters (13.1 feet).
