The Bently Nevada 330780-50-CN 3300 XL 11 mm Proximitor Sensor delivers precise, non-contact vibration and displacement measurements with a compact design suitable for panel or DIN-rail mounting.
Get a quick price for 330780-50-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330780-50-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330780-50-CN
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Total Length and Mounting Option:
    50= 5.0 meter(16.4 feet) system length, panel mount
  • Proximitor Sensor Material:
    A380 aluminum
  • Operating Temperature:
    -52°C to +100°C (-62°F to +212°F)
  • Storage Temperature:
    52°C to +105°C (-62°F to +221°F)
  • Relative Humidity:
    100% condensing, nonsubmersible when connectors are protected. Tested to IEC 68-2-3 damp heat.
  • Weight:
    0.22 kg
  • Estimated shipping dimensions:
    7.8x6x6.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The Bently Nevada 330780-50-CN 3300 XL 11 mm Proximitor Sensor accepts one non-contacting 3300 XL 11 mm probe and extension cable and operates with a supply voltage of -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption, or -23 Vdc to -26 Vdc with barriers. Operating above -23.5 Vdc may reduce the linear measurement range, while supply sensitivity remains low at less than 2 mV change per volt of input variation.

Constructed from durable A380 aluminum, the sensor operates reliably in temperatures ranging from -52°C to +100°C (-62°F to +212°F) and can be stored between -52°C to +105°C (-62°F to +221°F). It is capable of withstanding 100% condensing relative humidity when connectors are protected and has been tested to IEC 68-2-3 damp heat standards.

This Proximitor Sensor supports a panel-mount configuration and a 5.0 meter (16.4 feet) system length, combining flexibility with robust installation. The thin, compact design allows for high-density installations, while improved RFI/EMI immunity ensures consistent performance even in environments with high-frequency radio signals. SpringLoc terminal strips provide tool-free, fast, and reliable field wiring connections.

With the same advanced features as the 3300 XL 8 mm series, this 11 mm variant is ideal for precision applications requiring non-contact displacement and vibration monitoring in demanding industrial environments. Its combination of durability, linear range, and ease of installation makes it suitable for critical machinery across multiple industries.
Alternative Names
33O78O-5O-CN 3307B0-50-CN 33078050CN 330780 50 CN 33O78O5OCN 3307B050CN
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What material is the Proximitor sensor made of?
Constructed from A380 aluminum.
How fast can the 330780-50-CN be shipped?
In-stock units typically ship within 2–3 business days.
What are the operating and storage temperatures?
Operating: -52°C to +100°C (-62°F to +212°F); Storage: -52°C to +105°C (-62°F to +221°F).
Can the 330780-50-CN sensor operate in high humidity conditions?
Yes, supports 100% condensing relative humidity when connectors are protected and is tested to IEC 68-2-3 damp heat standards.
