          Apter Power supports 129716-XXX-040-15 MOD 166797-0133 identification, documentation review and quotation.

        129716-XXX-040-15 MOD 166797-0133

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 129716-XXX-040-15 MOD 166797-0133 is a special-configuration probe from the 3300 XL 8 mm proximity transducer family. The XXX code and MOD drawing must be checked against the installed probe before ordering.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 129716-XXX-040-15 MOD 166797-0133
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 129716-XXX-040-15 MOD 166797-0133

        • Manufacturer:
          Bently Nevada
        • Part Number:
          129716-XXX-040-15 MOD 166797-0133
        • Product Family:
          3300 XL 8mm Proximity Transducer System
        • Product Type:
          Special-Configuration 3300 XL 8 mm Probe
        • Stock:
          1
        • Probe family:
          129716 special configuration
        • Transducer system:
          3300 XL 8 mm Proximity Transducer System
        • Measurement principle:
          Non-contacting eddy current
        • Published nominal scale factor:
          7.87 V/mm / 200 mV/mil
        • Published linear range:
          2 mm / 80 mil, approximately 0.25 to 2.3 mm
        • Reference target material:
          AISI 4140 steel
        • System components:
          Probe, extension cable and Proximitor sensor
        • Interchangeability:
          Components interchangeable within a correctly matched system
        • Configuration field:
          XXX; controlled option
        • Suffix:
          040-15; verify against tag and drawing
        • MOD drawing reference:
          166797-0133
        • System output:
          Voltage proportional to distance from the conductive target
        • Measurement modes:
          Static position and dynamic vibration
        • Recommended radial-vibration gap:
          Approximately 1.27 mm / 50 mil at -9 V DC
        • Frequency response:
          0 to 10 kHz, +0/-3 dB
        • Minimum flat target diameter:
          15.2 mm / 0.6 in
        • Minimum shaft diameter:
          50.8 mm / 2 in
        • Recommended shaft diameter:
          76.2 mm / 3 in
        • Probe-tip material:
          Polyphenylene sulfide
        • Probe-case material:
          AISI 303 or 304 stainless steel
        • Standard probe cable:
          75 Ω triaxial FEP-insulated cable
        • Minimum cable bend radius:
          25.4 mm / 1 in
        • Connector material:
          Gold-plated brass or gold-plated beryllium copper
        • Probe-to-lead tensile strength:
          330 N / 75 lbf maximum rated
        • Probe temperature range:
          -52 to +177 °C for a standard probe
        • Probe humidity effect:
          Less than 3% average-scale-factor change at 93% RH for up to 56 days
        • Electromagnetic standards:
          EN 61000-6-2 immunity and EN 61000-6-4 emissions
        • Functional-safety capability:
          SIL 2 with HFT 0; SIL 3 with HFT 1
        • Tariff Code:
          Please confirm the destination before shipping.
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Environmental Ratings Configuration Compatibility & Interoperability

        Features:

        • Operates as the non-contacting sensing element in a matched 3300 XL 8 mm chain.
        • Supports both static gap and dynamic shaft-vibration measurements.
        • Preserves the XXX option and MOD 166797-0133 identity for exact configuration control.
        The listed probe is a special 129716 execution rather than a fully decoded standard catalog string.

        Its eddy-current tip observes a conductive shaft while the Proximitor sensor converts the gap-dependent response.

        Confirm every unresolved suffix and the complete electrical length before connecting the probe to an existing channel.

        Apter Power can review sourcing, documentation and system matching for 129716-XXX-040-15 MOD 166797-0133.
        Verified resources for Bently Nevada 129716-XXX-040-15 MOD 166797-0133: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Fluid-film bearing machines use the probe for radial shaft-vibration observation.
        • Axial position or thrust channels can use the same measurement principle with suitable mechanical orientation.
        • Keyphasor and speed-reference arrangements may use compatible 3300 XL 8 mm probes where the engineered target permits.
        • Probe temperature, cable routing and area classification depend on the exact 129716 configuration selected by the controlled suffix.
        • The probe tip and case must remain compatible with the process atmosphere and machine-case sealing arrangement.
        • Approval markings should be verified from the installed tag rather than inferred from the family datasheet.
        • The monitor channel scale and alarm logic are configured for the matched 3300 XL 8 mm system output.
        • Mechanical gap is established within the published linear range after the exact probe chain is installed.
        • The XXX and 040-15 fields require the tag or MOD drawing before a configuration record can be finalized.
        • Use only a compatible 3300 XL 8 mm extension cable and Proximitor sensor with the selected total electrical length.
        • Published accuracy assumes the specified probe chain and reference target material.
        • A visually similar probe is not interchangeable until case, connector, lead and approval options are matched.
        Description
        129716-XXX-040-15 MOD 166797-0133 retains the published 129716 family identity while preserving a customer-controlled XXX option and MOD drawing reference. It is treated as one probe component of a matched 3300 XL 8 mm system.

        The sensing tip uses eddy-current coupling to a conductive target, allowing the complete probe, extension cable and Proximitor chain to measure static shaft position and dynamic vibration without physical contact.

        The 040-15 suffix cannot be expanded safely without the exact drawing or tag record. Match total system length, connector, approvals, mechanical case and drawing 166797-0133 before replacing the installed probe.
        Alternative Names
        129716-XXX-040-15 MOD 166797-0133 Bently Nevada 129716-XXX-040-15 MOD 166797-0133 129716 XXX 040 15 MOD 166797 0133 129716-XXX-040-15-MOD-166797-0133 129716XXX04015MOD1667970133 Bently Nevada Special-Configuration 3300 XL 8 mm Probe Bently Nevada 3300 XL 8 mm Proximity Transducer System Bently Nevada Special-Configuration 3300 XL 8 mm Probe
        Technical notes
        Do not decode the XXX field in 129716-XXX-040-15 MOD 166797-0133 by analogy; verify the probe tag and drawing before matching the extension cable or Proximitor sensor.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why is the XXX field retained in Bently Nevada 129716-XXX-040-15 MOD 166797-0133?
        It represents a controlled option that is not safely recoverable from the public family data.
        Which electrical chain must accompany Bently Nevada 129716-XXX-040-15 MOD 166797-0133?
        Select the extension cable and Proximitor sensor that produce the engineered 3300 XL 8 mm total system length.
        What measurements can Bently Nevada 129716-XXX-040-15 MOD 166797-0133 support?
        A correctly matched system can observe static shaft position and dynamic vibration.
        How is the working gap established for Bently Nevada 129716-XXX-040-15 MOD 166797-0133?
        Install the verified probe chain and set the gap within the published linear operating range while observing the monitor output.
        What prevents blind substitution of Bently Nevada 129716-XXX-040-15 MOD 166797-0133?
        The unresolved suffix, total electrical length, connector, case geometry, approvals and MOD drawing can all affect compatibility.
        Which evidence is required to price Bently Nevada 129716-XXX-040-15 MOD 166797-0133?
        Provide the full tag, drawing 166797-0133, cable and Proximitor part numbers, quantity and delivery location.
