    Apter Power provides original Bently Nevada sensors, securing continuous condition monitoring across high-speed plant machinery.

330101-00-40-10-01-00

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330101-00-40-10-01-00 is a 3300 XL 8 mm probe with 3/8-24 UNF thread, 4.0" case, 1.0m cable, ClickLoc with connector protector, and no approvals.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330101-00-40-10-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-40-10-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-40-10-01-00
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    Proximity Probe
  • Stock:
    2
  • Thread Type:
    3/8-24 UNF
  • Armor:
    Without armor
  • Unthreaded Length:
    00 = 0.0 inches
  • Overall Case Length:
    40 = 4.0 inches
  • Total Cable Length:
    10 = 1.0 meter (3.3 feet)
  • Connector Option:
    01 = ClickLoc with connector protector, standard cable
  • Agency Approval:
    00 = Not required
  • Linear Range:
    2 mm (80 mils)
  • Recommended Gap:
    1.27 mm (50 mils)
  • Scale Factor (1m System):
    7.87 V/mm (200 mV/mil) ±5%
  • DSL (1m System):
    ±0.025 mm (±1 mil) @ 0-45°C
  • Pull Strength:
    330 N (75 lbf)
  • Operating Temperature:
    -52°C to +177°C
  • API Compliance:
    API 670 Standard
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    1.5x1.3x119cm
  • Tariff Code:
    8411999000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Operational Environment Monitoring & Control

Features:

  • 4.0-inch case with 1.0m cable for standard mounting applications.
  • ClickLoc connector with protector for moisture/contaminant protection.
  • Patented TiLoc and CableLoc technologies for robust mechanical durability.
The 330101-00-40-10-01-00 is an 8 mm proximity probe engineered for reliable vibration and position measurement on fluid-film bearing machines such as turbines, compressors, and generators. With a 4.0-inch overall case length, 0.0-inch unthreaded length, and 1.0-meter (3.3-foot) integral cable, it provides a versatile solution for standard mounting applications. The 3/8-24 UNF threads without armor offer a lightweight yet durable design. The 330101-00-40-10-01-00 is fully interchangeable with both XL and non-XL 3300 series components.

The 330101-00-40-10-01-00 includes a connector protector (option 01) that provides enhanced environmental sealing against moisture, dust, and contaminants. This protection is critical for maintaining reliable signal transmission in harsh industrial environments. The gold-plated ClickLoc connector requires only finger-tight torque and features a locking mechanism to prevent loosening. The 330101-00-40-10-01-00 operates from -52°C to +177°C and is factory calibrated to AISI 4140 steel, with other target material calibrations available upon request.

The 330101-00-40-10-01-00 incorporates patented TiLoc molding for a robust bond between the probe tip and the probe body, ensuring long-term reliability under vibration and mechanical stress. The CableLoc design provides 330 N (75 lbf) pull strength, securely attaching the probe cable to the probe tip. The 330101-00-40-10-01-00 delivers an Incremental Scale Factor of 7.87 V/mm (200 mV/mil) ±5% for 1-meter systems with a linear range of 2mm (80 mils). The 330101-00-40-10-01-00 complies with API 670 Standard for mechanical configuration and accuracy.

The 330101-00-40-10-01-00 Bently Nevada Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330101-00-40-10-01-00 Proximity Probe Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330101-00-40-10-01-00 Proximity Probe Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330101-00-40-10-01-00
  • Condition New Original ready stock
  • Product Family 330101-00-40-10-01-05,330101-00-40-10-01-CN,330101-00-40-10-01-RU
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Oil, Gas & Petrochemical Plants: Deployed on major turbomachinery strings, including multi-stage centrifugal compressors, high-pressure process pumps, and turbo-expanders.
  • Power Generation Facilities: Installed on industrial steam turbines, combustion gas turbines, hydro-turbine main shafts, and electrical generators.
  • Heavy Manufacturing & Refining: Utilized on large air blowers, forced draft (FD) fans, and high-load internal gearboxes in steel mills and paper mills.
  • Temperature Hardiness: Operates in extreme thermal zones ranging from -51 °C to +177 °C (-60 °F to +351 °F), easily tolerating radiant bearing friction heat.
  • Chemical & Oil Submersion: The probe tip is made from high-grade Polyphenylene Sulfide (PPS), while the body is AISI 303/304 stainless steel. This construction resists hot industrial lubricants, synthetic oils, chemical vapors, and moisture.
  • Mechanical Integrity: Features patented TipLoc™ molding to secure the tip to the body under heavy fluid pressures, alongside CableLoc™ anchoring, providing up to 330 N (75 lb) of cable pull strength.
  • Radial Vibration: Monitors continuous micro-inch shaft displacement relative to the bearing shell, detecting faults like unbalance, shaft misalignment, mechanical looseness, and oil whirl/whip.
  • Axial Thrust Position: Measures structural rotor float along its centerline. This acts as a critical interlock loop, preventing rotor-to-stator mechanical crashes.
  • Keyphasor & Speed Reference: Detects a machined slot on the shaft to provide once-per-turn reference pulses for exact machine RPM tracking and phase-angle calculations.
Description
The Bently Nevada 330101-00-40-10-01-00 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF thread, without armor, designed for vibration and position measurement on fluid-film bearing machines. It features a 0.0-inch unthreaded length and a 4.0-inch overall case length, with a 1.0-meter integral cable. The 330101-00-40-10-01-00 includes a miniature coaxial ClickLoc connector with connector protector and standard cable (option 01).

The Bently Nevada 330101-00-40-10-01-00 incorporates patented TiLoc molding for a robust bond between the probe tip and body, and CableLoc technology providing 330 N (75 lbf) pull strength. The 330101-00-40-10-01-00's gold-plated ClickLoc connector with connector protector (option 01) requires only finger-tight torque and features a locking mechanism to prevent loosening.

The Bently Nevada 330101-00-40-10-01-00 has a linear range of 2 mm (80 mils) with a recommended gap setting of 1.27 mm (50 mils) for radial vibration measurements. The 330101-00-40-10-01-00 delivers an Incremental Scale Factor of 7.87 V/mm (200 mV/mil) ±5% for 1-meter systems with interchangeability error.

The Bently Nevada 330101-00-40-10-01-00 operates from -52°C to +177°C and is factory calibrated to AISI 4140 steel by default, with other target material calibrations available upon request. The 330101-00-40-10-01-00 is fully interchangeable with both XL and non-XL 3300 series 5 mm and 8 mm components, eliminating the need for bench calibration.
Alternative Names
33O1O1-OO-4O-1O-O1-OO 330I0I-00-40-I0-0I-00 330101 00 40 10 01 00 330101-00-40-10-01-05 330101-00-40-10-01-CN 330101-00-40-10-01-RU 330101-00-40-10-01-BR 330101-00-12-10-02-05
Technical notes
The Bently Nevada 330101-00-40-10-01-00 is an 8mm probe with 3/8-24 UNF thread, 4.0" case, 1.0m cable, and ClickLoc with connector protector. Features 2mm linear range, 7.87 V/mm scale factor (±5%), 330N pull strength, API 670 compliance, and -52°C to +177°C operation. No hazardous area approvals.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the primary application of the 330101-00-40-10-01-00?
It measures radial vibration and axial position on fluid-film bearing machines with 8 mm proximity technology.
What is the cable length and connector type of the 330101-00-40-10-01-00?
It has a 1.0m cable with ClickLoc connector and connector protector (option 01) requiring finger-tight torque.
What is the scale factor of the 330101-00-40-10-01-00?
It delivers 7.87 V/mm (200 mV/mil) ±5% with 2mm linear range and ±0.025mm DSL.
What approvals does the 330101-00-40-10-01-00 carry?
The "00" suffix indicates no agency approvals; a variant with "05" would be required for hazardous areas.
