330101-00-47-05-02-05

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330101-00-47-05-02-05 is a non-armored 3300 XL 8 mm probe with a 4.7-inch case, 0.5-metre system length, and ClickLoc connector.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330101-00-47-05-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-47-05-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-47-05-02-05
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe
  • Stock:
    1
  • Probe family:
    3300 XL 8 mm
  • Mounting thread:
    3/8-24 UNF, without armor
  • Unthreaded length:
    0.0 in
  • Overall case length:
    4.7 in
  • Total length:
    0.5 m
  • Connector:
    Miniature coaxial ClickLoc
  • Cable option:
    Standard cable
  • Agency approvals:
    CSA, ATEX, IECEx
  • Tariff Code:
    Please confirm the destination before shipping
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Probe Geometry Cable and Connector System Matching Product Applications

Features:

  • Defined mounting geometry: a 0.0-inch unthreaded section and 4.7-inch case control installed reach
  • Half-metre system length: the cable code specifies a 0.5 m total length
  • Standard ClickLoc termination: the connector code identifies a miniature coaxial interface without a FluidLoc claim
Bently Nevada 330101-00-47-05-02-05 is a complete order identity within the 3300 XL 8 mm proximity probe family.

Its dimensional and cable suffixes distinguish the installed probe from visually similar configurations that use other case lengths, total lengths, or cable constructions.

Selection must preserve the complete code, matching transducer components, machine target, mounting record, hazardous-area approval context, and baseline gap evidence.

Apter Power supports document review, quotation, and procurement for the Bently Nevada 330101-00-47-05-02-05 3300 XL 8 mm Proximity Probe while current OEM ordering remains available.
Bently Nevada 330101-00-47-05-02-05 3300 XL 8 mm Proximity Probe Manuals,Datasheets,Link
Important Notice: No qualified exact-model English PDF is attached. Use the complete product model in every document request.
  • Thread form: the body uses the documented 3/8-24 UNF mounting interface.
  • Flush start: the 0.0-inch unthreaded code places the thread boundary at the probe-end geometry.
  • Case reach: the 4.7-inch case must clear the bracket, machine surface, and connector access zone.
  • Drawing check: the approved insertion and target gap remain site-specific installation records.
  • Total length: the order code establishes a 0.5-metre probe and cable assembly.
  • ClickLoc interface: the miniature coaxial connector belongs in the receiving check.
  • Standard cable: code 02 does not establish the optional FluidLoc construction.
  • Routing control: cable bend, restraint, and connector cleanliness affect a repeatable measurement path.
  • Component family: use the probe with a documented 3300 XL 8 mm system chain.
  • Extension path: verify the cable identity and total system-length requirement before connection.
  • Sensor pairing: the Proximitor sensor and scale must agree with the approved installation.
  • Baseline proof: retain gap voltage, runout, and monitor-channel records after replacement.
  • Shaft vibration monitoring: observe documented relative motion on compatible rotating equipment.
  • Radial position measurement: preserve the original probe location and target geometry.
  • Machine protection systems: feed a qualified transducer chain used by the installed monitoring architecture.
  • Hazardous-area service: maintain the approval and installation evidence required for the site classification.
Description
Built around a 3/8-24 UNF non-armored body, 330101-00-47-05-02-05 uses a 0.0-inch unthreaded section and a 4.7-inch overall case. That geometry defines how far the connector end stands from the mounting surface and must be checked against the machine drawing.

The cable selection within 330101-00-47-05-02-05 establishes a 0.5-metre total system length and a miniature coaxial ClickLoc termination with standard cable. A receiving inspection should keep that connector and length together instead of treating the family number as the complete identity.

CSA, ATEX, and IECEx approval coding completes 330101-00-47-05-02-05. Installation still depends on a compatible 3300 XL 8 mm transducer chain, the approved gap setup, hazardous-area documentation, routing, and the exact probe position recorded for the monitored machine.
Alternative Names
Bently Nevada 330101-00-47-05-02-05 Baker Hughes 330101-00-47-05-02-05 330101 00 47 05 02 05 3301010047050205 330101-0047-05-02-05 330101 0047 05 02 05 330101-00-47-05-02-05 probe 3300 XL probe 330101 00 47 05 02 05 BN 3301010047050205
Technical notes
For 330101-00-47-05-02-05 service, verify the 3/8-24 UNF mounting thread, 0.0-inch unthreaded length, 4.7-inch case, 0.5-metre total length, standard-cable ClickLoc connector, approval suffix, extension cable, Proximitor sensor, target material, and original gap record before installation. Do not infer FluidLoc construction from the connector code, and prove stable channel operation afterward.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Should installation proceed if 330101-00-47-05-02-05 is supplied with a different case length?
No. A different case-length code changes the mechanical configuration; hold the item until the 4.7-inch requirement is reconciled with the approved machine drawing.
Does code 02 prove that 330101-00-47-05-02-05 has a FluidLoc cable?
No. In the official ordering structure, code 02 identifies the miniature coaxial ClickLoc connector with standard cable, so FluidLoc must not be inferred.
What should be checked before connecting 330101-00-47-05-02-05 to an existing extension cable?
Confirm the 3300 XL 8 mm component family, total system length, connector condition, extension-cable identity, Proximitor sensor, and channel scale before making the connection.
How should receiving verify 330101-00-47-05-02-05 when the family label looks correct?
Use the complete six-segment order code, then verify thread, unthreaded length, case length, total length, ClickLoc termination, and approval suffix against the purchase record.
What should stop hazardous-area use of 330101-00-47-05-02-05?
Stop if the approval marking, installation method, associated apparatus, barriers, drawings, or site classification cannot be matched to the approved loop documentation.
Which records should follow a replacement of 330101-00-47-05-02-05?
Retain the full order code, machine and probe location, target material, mechanical gap, gap voltage, cable path, channel scale, runout result, and final acceptance signature.
