330101-00-60-05-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
The 330101-00-60-05-02-00 is a 6.0-inch 8 mm probe with 3/8-24 UNF thread, 0.5 m cable, no approvals, for non-hazardous installations requiring rugged 8 mm durability.
Get a quick price for 330101-00-60-05-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-60-05-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-60-05-02-00
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe
  • Thread Type:
    3/8-24 UNF (without armor)
  • Total Length:
    0.5 meter (1.6 feet)
  • Agency Approval:
    Not required
  • Unthreaded Length:
    0.0 inches
  • Overall Case Length:
    6.0 inches
  • Key Benefit:
    Solves upgrading 5 mm systems in non-hazardous areas—6.0-inch case provides extra reach, 0.5 m cable reduces panel clutter, no approvals lower cost.
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    20x20x2cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Protection Features Installation

Features:

  • 6.0-inch case length provides extra reach for deeper insertion into machine casings without standoffs.
  • 0.5-meter integral cable eliminates excess slack in compact control cabinets.
  • No agency approvals reduce cost and lead time for non-hazardous applications.
The 330101-00-60-05-02-00’s 6.0-inch case reaches through thicker casings. No spacers, no adapters. Thread it in and the tip lands where it needs to be—even on machines with deeper mounting ports.

At 0.5 meters, the cable won't clutter your cabinet. No coiling, no tie-wraps fighting excess length. The 330101-00-60-05-02-00 connects directly to nearby terminal blocks or junction boxes.

CSA, ATEX, IECEx not required. The 330101-00-60-05-02-00 skips the certifications you don't need, saving money and delivery time. For general-purpose machinery, it's the practical choice.

The 330101-00-60-05-02-00 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330101-00-60-05-02-00 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330101-00-60-05-02-00 3300 XL 8 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330101-00-60-05-02-00
  • Condition New Original ready stock
  • Product Family 330101-00-60-05-01-00,330101-00-60-05-11-00,330101-00-60-05-02-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Rotating Machinery Monitoring: Widely used in machines equipped with hydrodynamic bearings, such as steam turbines, compressors, pumps, motors, and generators.
  • Radial Vibration and Displacement: Measures the dynamic vibration of the shaft and its static position relative to the bearing.
  • Axial (Thrust) Position: Monitors the axial movement of the rotor to prevent mechanical collisions between the rotor and the stator.
  • High-Accuracy Data: The output voltage is proportional to the distance from the probe tip to the conductive surface, with a sensitivity of 7.87 V/mm (200 mV/mil), providing a highly stable diagnostic signal.
  • API 670 Compliance: Fully compliant with American Petroleum Institute (API) 670 standards, meeting the highest industry requirements for mechanical configuration, linear range, accuracy, and temperature stability.
  • Environmentally Friendly Design: The probe tip is molded from polyphenylene sulfide (PPS), and the housing is made of 304 stainless steel, offering excellent corrosion resistance, oil resistance, and contamination resistance, making it suitable for harsh environments.
  • Threadless Length (0.0 in) and Overall Housing Length (6.0 in): Ensure the mounting bracket thickness and axis pitch conform to the design of this 6-inch all-threaded housing.
  • Gapping Setting: A setting of approximately -9 Vdc (about 1.27 mm) is generally recommended to ensure the probe is centered within the linear measurement range.
  • ClickLoc connector: The ClickLoc connector is gold-plated and can be installed simply by tightening it with your fingers (you will hear a "click"), without the need for special tools.
Description
The 330101-00-60-05-02-00 offers a 6.0-inch case for deeper insertion into machine casings without standoffs. Its 3/8-24 UNF thread matches standard English ports, while the 0.5-meter cable keeps wiring tidy in compact panels.

Built on the 8 mm platform, the 330101-00-60-05-02-00 provides thicker PPS encapsulation than 5 mm probes, absorbing impacts that would crack smaller tips. The larger body diameter resists bending under vibration, maintaining consistent gap readings.

This probe drops into existing 3300 series systems without recalibration. Replace 5 mm probes directly where the mounting hole accepts the larger 8 mm body. The 330101-00-60-05-02-00’s longer case reaches through thicker casings while the short cable eliminates excess slack in crowded cabinets.

This probe solves the pain point of upgrading 5 mm installations in non-hazardous areas. The 330101-00-60-05-02-00’s 6.0-inch case provides extra reach, its 0.5 m cable reduces panel clutter, and no approvals mean faster delivery and lower cost for general-purpose machinery.
Alternative Names
330101-00-60-05-12-00 330101-00-60-05-01-00 330101-00-60-05-11-00 330101-00-60-05-02-05
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the case length of the 330101-00-60-05-02-00?
6.0 inches—longer than standard probes, for deeper insertion into machine casings.
Does this probe require hazardous area approvals?
No. It has no agency approvals, making it suitable for general-purpose industrial environments only.
How long is the cable?
0.5 meters (1.6 feet)—short enough to avoid slack in crowded control cabinets.
Can I replace a 5 mm probe with this 8 mm model?
Yes, it is backward compatible with non-XL 3300 series 5 mm probes, provided the mounting hole accepts the larger 8 mm body.
