330102-00-40-10-01-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330102-00-40-10-01-05 is a rugged, armored 8 mm proximity probe from the advanced 3300 XL series, designed for high-precision static and dynamic vibration measurements.
Get a quick price for 330102-00-40-10-01-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330102-00-40-10-01-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330102-00-40-10-01-05
  • Product Type:
    Proximity Probes
  • Unthreaded Length:
    0.0 in
  • Overall Case Length:
    4.0 in.
  • Total Length:
    1.0 meter (3.3 feet)
  • Connector and Cable-Type:
    Miniature coaxial ClickLoc connector with connector protector, standard cable
  • Agency Approval:
    CSA, ATEX, IECEx Approvals
  • Standard Temp Rating:
    -52°C to +177°C (-62°F to +350°F)
  • Minimum Bend Radius:
    25.4 mm (1.0 in)
  • Recommended Mounting Torque:
    11.2 N·m (100 in·lbf)
  • Cable Insulation:
    Fluoroethylene propylene (FEP)
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    1.5x1.3x117cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Monitoring & Control Safety & Compliance Applications

Features:

  • Unmatched Mechanical Robustness
  • Corrosion-Resistant & Vibration-Proof Connectivity
  • Extreme Environmental Protection
The Bently Nevada 330102-00-40-10-01-05 incorporates patented TipLoc and CableLoc molding methods, providing a superior bond between the probe tip, body, and cable. With a pull strength rating of 330 N (75 lbf), this probe withstands significant physical abuse without losing calibration or performance.

Featuring gold-plated ClickLoc connectors, this probe eliminates the need for special tools or over-tightening. The connectors produce an audible "click" when finger-tight, and the specialized locking mechanism prevents loosening due to machine vibration, ensuring consistent signal integrity.

Optional FluidLoc cable technology prevents oil and other machine liquids from leaking out through the cable interior. Combined with the connector protectors and an operating temperature range down to -52°C, the Bently Nevada 330102-00-40-10-01-05 is built for the harshest turbine and compressor environments.

The 330102-00-40-10-01-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330102-00-40-10-01-05 3300 XL 8 mm Proximity Probes Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330102-00-40-10-01-05 3300 XL 8 mm Proximity Probes

General

  • Manufacturer GE / Bently Nevada
  • Model 330102-00-40-10-01-05
  • Condition New Original ready stock
  • Product Family 330102-00-40-10-01-00,330102-00-40-15-01-05,330102-00-40-15-01-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Static Position: Measures axial thrust position and differential expansion.
  • Dynamic Vibration: Detects shaft radial vibration and running speed.
  • API 670 Compliance: Guarantees linear range, accuracy, and temperature stability for standard monitoring systems.
  • Interchangeable Components: Probes, extension cables, and Proximitor sensors are fully interchangeable without bench calibration.
  • ATEX/IECEx Certified: Suitable for hazardous Zone 0/1/2 gas and dust environments (Ex ia IIC T4/T5 Ga).
  • CSA/US (cNRTLus): Approved for Class I, Division 1 & 2, Groups A, B, C, D.
  • SIL 2/3 Capable: Functional safety certified for use in Safety Instrumented Systems (SIL 3 with HFT=1).
  • Environmental Compliance: RoHS and China RoHS compliant (EFUP 15 years).
  • Fluid-film Bearing Machines: Vibration and position measurement on steam and gas turbines.
  • Compressors: Shaft vibration and thrust position monitoring in centrifugal and axial compressors.
  • Keyphasor Reference: Providing precise timing marks for speed and phase measurement.
  • Overspeed Protection: Critical speed detection (requires consultation of specific application notes).
Description
The Bently Nevada 330102-00-40-10-01-05 represents the pinnacle of eddy-current proximity transducer technology, specifically configured as a 3/8-24 UNF threaded probe with flexible stainless steel armor. Built to fully comply with the American Petroleum Institute (API) 670 Standard, this probe provides an output voltage directly proportional to the distance between its tip and a conductive surface, enabling both position and vibration measurements with unmatched accuracy.

The Bently Nevada 330102-00-40-10-01-05 features a total length of 1.0 meter, eliminating the need for an extension cable in short-distance applications. Its armored casing provides superior protection against physical abuse, making it ideal for turbine and compressor installations where mechanical robustness is critical. The gold-plated ClickLoc connector ensures a corrosion-resistant, finger-tight seal that "clicks" when properly secured, eliminating the risk of loosening from vibration.

Furthermore, the Bently Nevada 330102-00-40-10-01-05 is backward compatible with non-XL 3300 series 5 mm and 8 mm components. The probe tip utilizes Polyphenylene sulfide (PPS) material, capable of withstanding temperatures up to 177°C (350°F) in standard configurations, while the optional FluidLoc cable prevents oil and liquid leakage through the cable interior, ensuring machine integrity.
Alternative Names
330102-00-40-10-01-00 330102-00-40-15-01-05 330102-00-40-15-01-00 330102-00-40-15-02-00 330102-00-40-15-02-05 330102-00-40-15-12-00 330102-00-40-15-12-05
Technical notes
The Bently Nevada 330102-00-40-10-01-05 is a 1-meter total length probe, meaning it must be connected directly to a compatible Proximitor sensor without an extension cable; when used as part of a 3300 XL system, performance specifications such as linear range and temperature stability are guaranteed only when all components (probe, extension cable if used, and Proximitor sensor) are from the 3300 XL series.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the primary application for the Bently Nevada 330102-00-40-10-01-05?
The Bently Nevada 330102-00-40-10-01-05 is specifically designed for vibration and position measurements on fluid-film bearing machines, such as steam turbines, gas turbines, and compressors. This model also serves as an excellent solution for Keyphasor reference and speed measurement applications where high reliability and API 670 compliance are required.
Does the Bently Nevada 330102-00-40-10-01-05 require calibration with a specific target material?
Yes, the Bently Nevada 330102-00-40-10-01-05 is factory calibrated to AISI 4140 steel by default. While calibration to other target materials is available upon request, please note that the system accuracy and interchangeability specifications only apply when using the standard AISI 4140 steel target with the Bently Nevada 330102-00-40-10-01-05.
What safety certifications does the Bently Nevada 330102-00-40-10-01-05 hold for hazardous areas?
The Bently Nevada 330102-00-40-10-01-05 with Option 05 includes CSA, ATEX, and IECEx certifications. It is approved for Class I, Zone 0 (AEx/Ex ia IIC T4/T5 Ga) when installed with appropriate intrinsic safety barriers per drawing 141092, making the Bently Nevada 330102-00-40-10-01-05 suitable for the most demanding hazardous area installations.
How do I protect the connection on the Bently Nevada 330102-00-40-10-01-05 from oil leakage?
The Bently Nevada 330102-00-40-10-01-05 comes standard with a gold-plated ClickLoc connector and a connector protector (Option 01). For applications where the connection is exposed to turbine oil, Bently Nevada recommends using the connector protector already installed on the Bently Nevada 330102-00-40-10-01-05, and notes that silicone tape should not be used for turbine oil exposure as an alternative.
What makes the Bently Nevada 330102-00-40-10-01-05 more reliable than previous probe designs?
The Bently Nevada 330102-00-40-10-01-05 incorporates patented TipLoc and CableLoc technologies, providing a 330 N (75 lbf) pull strength between the probe case and lead. This robust construction, combined with the corrosion-resistant gold-plated ClickLoc connectors on the Bently Nevada 330102-00-40-10-01-05, ensures reliable operation even in high-vibration environments.
