330103-00-13-50-12-RU

/ 4.9
1001 reviews | Need a Specific Revision?
The 330103-00-13-50-12-RU is a 3300 XL 8 mm proximity probe featuring an M10 x 1 metric thread without armor, with country-specific approvals for Russia.
Get a quick price for 330103-00-13-50-12-RU
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330103-00-13-50-12-RU

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330103-00-13-50-12-RU
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe, Metric
  • Thread Type:
    M10 x 1 (without armor)
  • Total Length:
    5.0 meters (16.4 feet)
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    130 mm
  • Connector Type:
    Miniature coaxial ClickLoc™
  • Cable Type:
    FluidLoc (fluid-blocking)
  • Key Benefit:
    Solves the challenge of deep mounting with fluid containment in one assembly—130 mm case reaches through thick casings while the FluidLoc cable stops oil migration, all backed by Russian regulatory approvals.
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    2.2x2x122cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Diagnosis & Protection Installation

Features:

  • 130 mm overall case length reaches through thick casings or insulation, eliminating standoffs and adapters in deep-well mounting applications.
  • FluidLoc cable technology with a 5.0-meter integral length combines fluid containment and extended reach in a single assembly.
  • Country-specific approvals for Russia simplify compliance, allowing direct installation in local facilities without extra certification steps.
The 330103-00-13-50-12-RU is built for situations where the probe has to travel a long distance from the mounting surface to the target. Its 130 mm case length lets it pass through thick turbine casings, heavy compressor walls, or multiple insulation layers without adding spacers or custom mounting hardware.

With a 5.0-meter FluidLoc cable, the 330103-00-13-50-12-RU handles two common installation challenges at once: remote Proximitor placement and fluid migration prevention. The extended length lets the sensor live in a control cabinet away from the machine, while the FluidLoc barrier inside the cable blocks oil from wicking through and leaking at the penetration point.

he 330103-00-13-50-12-RU carries country-specific approvals for Russia, so it can be used in local facilities without navigating separate certification processes. Its 8 mm construction adds mechanical toughness: the coil is encased in thicker PPS plastic than 5 mm probes, and the larger body diameter resists bending and vibration.

The 330103-00-13-50-12-RU Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330103-00-13-50-12-RU 3300 XL 8 mm Proximity Probese Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330103-00-13-50-12-RU 3300 XL 8 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330103-00-13-50-12-RU
  • Condition New Original ready stock
  • Product Family 330103-00-13-50-01-RU,330103-00-13-50-02-RU,330103-00-13-50-12-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration Monitoring: Measures the relative dynamic vibration of the shaft in fluid thin-film bearings (sliding bearings) to diagnose imbalance, misalignment, or bearing wear.
  • Axial Displacement Monitoring: Monitors the condition of thrust bearings to prevent axial collisions between the rotor and stator.
  • Speed ​​and Phase Reference (Keyphasor): Detects keyways or protrusions on the shaft, providing accurate speed pulses and phase references.
  • Regional Compliance: The RU marking ensures that this component complies with Russian and related regional technical regulations and explosion-proof safety standards, suitable for local oil, gas, and power industry projects.
  • "Not OK" Self-Diagnosis: When the probe cable is open-circuited or short-circuited, the downstream monitoring system (such as the 3500 series) will detect the signal abnormality and trigger the "Not OK" state, thereby preventing erroneous alarms and tripping.
  • Connection Protection (Option 12): This model has a built-in connector protector that effectively prevents moisture and oil from entering the coaxial connector, reducing signal interference or electrical corrosion caused by poor contact.
  • Chemical and Pressure Protection: The probe tip is encapsulated in PPS (polyphenylene sulfide) plastic with a Viton O-ring seal, resisting corrosion from high-temperature, high-pressure lubricating oil in the bearing housing.
  • During installation, a 3300 XL preamplifier (Proximitor) is required. The DC output voltage should be measured using a multimeter.
  • The gap is typically set at the center of the linear range (approximately -10.0 VDC) to ensure sufficient measurement space for both positive and negative vibrations.
  • ClickLoc Connector: Employs 12-option ClickLoc technology with a self-locking mechanism to prevent loosening of the connector due to prolonged vibration.
Description
The 330103-00-13-50-12-RU combines a 130 mm case with a 5.0-meter FluidLoc cable, making it suitable for deep mounting and remote sensor placement in Russian industrial facilities. Its M10 x 1 metric thread fits standard metric ports, while the extended case length reaches through thick casings or insulation layers without standoffs.

Inside the 330103-00-13-50-12-RU, the FluidLoc cable creates a physical barrier that stops oil from traveling through the cable interior—a practical safeguard in lubricated machinery where fluid leakage is a concern. The gold-plated ClickLoc connector locks with a simple finger turn, staying tight even under vibration.

This 8 mm probe uses thicker PPS plastic encapsulation around the coil, which gives it better resistance to impact and rough handling than 5 mm models. The larger case diameter also adds stiffness, helping it maintain measurement accuracy in high-vibration environments.

With its extended reach, built-in fluid containment, and Russian approvals, the 330103-00-13-50-12-RU is aimed at facilities where both regulatory compliance and physical durability matter.
Alternative Names
330103-00-13-50-01-RU 330103-00-13-50-11-RU 330103-00-13-50-12-00 330103-00-13-50-12-CN
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
When would I choose the 130 mm case length of the 330103-00-13-50-12-RU?
Choose this length when your machine casing is unusually thick, or when insulation layers require the probe to extend farther before reaching the measurement zone—it eliminates the need for mounting adapters.
Does the FluidLoc cable on this model require special handling during installation?
No, the FluidLoc cable installs like standard cable but has an internal barrier that passively blocks fluid migration. No extra steps are needed beyond normal routing.
What is the advantage of the 5.0-meter integral cable?
It lets you place the Proximitor sensor in a control cabinet or remote panel without adding an extension cable, reducing connection points and simplifying parts management.
How do the Russian approvals for this probe affect field use?
They mean the 330103-00-13-50-12-RU can be installed in Russian facilities without pursuing separate local certifications, helping keep project timelines on track.
