    Apter Power offers brand new Bently Nevada 330101-00-77-20-02-CN proximity sensors to maintain accurate turbomachinery vibration feedback and reliable shaft position monitoring.

330101-00-77-20-02-CN

/ 4.9
1001 reviews | Need a Specific Revision?
330101-00-77-20-02-CN is a Bently Nevada 3300 XL 8 mm Proximity Probe designed for high-accuracy vibration and displacement monitoring in rotating machinery.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330101-00-77-20-02-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-77-20-02-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-77-20-02-CN
  • Product Family:
    3300 XL 8 mm Probe
  • Stock:
    1
  • Unthreaded Length:
    0.0 in.
  • Overall Case Length:
    7.7 in.
  • Total Length:
    2.0 meters (6.6 feet)
  • Connector and Cable-Type:
    Miniature coaxial ClickLoc connector, standard cable
  • Agency Approval:
    CSA, ATEX, IECEx Approvals
  • Probe Case Thread:
    3/8-24 UNF thread
  • Armor Protection:
    None
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    1.5x1.3x117cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Monitoring & Control Performance & Efficiency

Features:

  • ClickLoc™ Secure Connectivity
  • Patented Structural Integrity
  • High RFI/EMI Immunity
Designed for high-vibration environments, the ClickLoc™ mechanism provides a positive "click" feedback upon secure engagement. This gold-plated connector system eliminates loosening issues common with threaded connectors, ensuring long-term signal integrity without specialized tools.

Featuring a robust TipLoc and CableLoc design, the Bently Nevada 330101-00-77-20-02-CN withstands a 330N (75 lbf) pull force. This ruggedization protects the probe tip and cable lead from mechanical stress, physical abuse, and severe operational vibrations found in large turbomachinery.

Engineered to exceed international CE mark standards, this transducer system offers superior radio frequency immunity. It can be installed in fiberglass or non-metallic housings without the costly requirement for shielded conduits, simplifying installation and reducing overall project complexity.

The 330101-00-77-20-02-CN Bently Nevada 3300 XL 8mm Proximity Transducer System may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330101-00-77-20-02-CN 3300 XL 8mm Proximity Transducer System Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330101-00-77-20-02-CN 3300 XL 8mm Proximity Transducer System

General

  • Manufacturer GE / Bently Nevada
  • Model 330101-00-77-20-02-CN
  • Condition New Original ready stock
  • Product Family 330101-00-12-10-02-05,330101-00-16-10-02-00,330101-00-50-10-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration: Precisely monitors shaft movement in fluid-film bearings for predictive maintenance.
  • Axial Position: Tracks thrust bearing wear to prevent catastrophic rotor crashes.
  • Speed/Tachometer: Utilizes Keyphasor pulse generation for accurate rotational speed tracking.
  • Reciprocating Compressors: Monitors crosshead and rod drop to assess mechanical health.
  • Condition Monitoring: Integrates into Bently Nevada 3500 series racks for real-time asset protection.
  • Signal Path: Provides raw voltage output proportional to shaft displacement, essential for PLC/DCS analysis.
  • Dynamic Analysis: Supports high-frequency capture for FFT and orbit analysis of complex shaft movements.
  • Interoperability: Facilitates "Smart" monitoring by allowing simple cross-component replacement during outages.
  • Linearity Stability: Maintains consistent voltage-to-distance mapping across the 80-mil range, reducing error in calculated vibration amplitudes.
  • Thermal Resilience: Withstands ambient temperature changes from -52°C to 177°C without compromising the 7.87 V/mm scale factor.
  • Low Maintenance: Minimizes downtime through the durable ClickLoc™ system, ensuring faster system-wide commissioning and repairs.
  • Regulatory Alignment: Simplifies site audits by strictly adhering to API 670 standards, which govern mechanical configuration and accuracy for machinery protection.
Description
330101-00-77-20-02-CN is a Bently Nevada 3300 XL 8 mm Proximity Probe designed for high-accuracy vibration and displacement monitoring in rotating machinery. This model features a 3/8-24 UNF threaded configuration and is supplied without armor, making it suitable for standard industrial installations where reliable signal performance and precise measurement are required within the 3300 XL 8 mm proximity transducer system.

From a dimensional perspective, 330101-00-77-20-02-CN has an unthreaded length of 0.0 inches and an overall probe case length of 7.7 inches, allowing secure installation in applications that require a longer probe body for proper target positioning. The probe is provided with a total cable length of 2.0 meters (6.6 feet), offering flexibility for routing to monitoring or protection systems.

In terms of connection and cabling, 330101-00-77-20-02-CN is equipped with a miniature coaxial ClickLoc connector and uses a standard cable, ensuring stable electrical connections and consistent signal transmission in typical industrial environments.

Regarding compliance and suitability for hazardous areas, 330101-00-77-20-02-CN carries CSA, ATEX, and IECEx approvals, making it suitable for use in a wide range of industrial and potentially hazardous applications, and reflecting the proven reliability and global acceptance of the 3300 XL 8 mm Proximity Probe series.
Alternative Names
330101 00 77 20 02 CN 330101-00-77-20-02-05 330101-00-77-20-02-00 330101-00-77-20-12-CN 330101-00-12-10-02-05 330101-00-16-10-02-00 330101-00-50-10-02-00
Technical notes
The Bently Nevada 330101-00-77-20-02-CN is factory-calibrated for AISI 4140 steel, and any deviation in target material or geometry may require recalibration to maintain linear accuracy. Operators must ensure the minimum cable bend radius and tip-to-tip separation distances are strictly observed during installation to prevent cross-talk and signal interference.
