330104-02-09-10-01-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330104-02-09-10-01-00 is an armored 3300 XL 8 mm probe with M10×1 thread, 20 mm unthreaded length, 90 mm case, 1.0 m cable, and ClickLoc connector.
In Stock
Ships by Monday, October 26
Fast Shipping Available
Get a quick price for 330104-02-09-10-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330104-02-09-10-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330104-02-09-10-01-00
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe with Armor
  • Stock:
    1
  • Probe Style:
    Standard-mount probe with armor
  • Probe Tip Diameter:
    8 mm
  • Thread:
    M10×1
  • Unthreaded Length:
    20 mm
  • Overall Case Length:
    90 mm
  • Total Length:
    1.0 m
  • Connector Option:
    Miniature coaxial ClickLoc connector with connector protector
  • Cable Type:
    Standard 75 Ω triaxial FEP-insulated cable
  • Agency Approval:
    Not required
  • Temperature Range:
    -52 to +177 °C (-62 to +351 °F)
  • Minimum Cable Bend Radius:
    25.4 mm (1.0 in)
  • Maximum Thread Engagement:
    15 mm (0.59 in)
  • Standard Calibration Target:
    AISI 4140 steel
  • Tariff Code:
    9031900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Configuration Construction Compatibility Application
  • Standard-mount armored 3300 XL 8 mm proximity probe
  • M10×1 thread with 20 mm unthreaded and 90 mm overall case lengths
  • One-meter standard cable with protected miniature coaxial ClickLoc connector

Bently Nevada 330104-02-09-10-01-00 is an armored metric 3300 XL 8 mm proximity probe for non-contact machinery measurements.

The exact configuration uses an M10×1 standard-mount case, 20 mm unthreaded length, 90 mm overall case length, 1.0 m total length, and a protected miniature coaxial ClickLoc connector.

Match the probe to the correct one-meter Proximitor sensor, verify the AISI 4140 calibration basis, maintain cable bend radius, and limit thread engagement to 15 mm.

Availability, condition, price, and shipping time for 330104-02-09-10-01-00 are confirmed during quotation.

Bently Nevada 330104-02-09-10-01-00 3300 XL 8 mm Proximity Probe Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • 02 specifies 20 mm unthreaded length
  • 09 and 10 specify 90 mm overall case length and 1.0 m total length
  • 01 and 00 specify the protected ClickLoc connector and no required agency approval
  • Eight-millimeter probe tip with M10×1 threaded case
  • Armored standard 75 Ω triaxial FEP-insulated cable
  • Miniature coaxial ClickLoc connector with connector protector
  • Use the matching one-meter 3300 XL 8 mm Proximitor sensor configuration
  • No extension cable is used in a one-meter transducer system
  • Mixed XL and non-XL systems are limited to non-XL component performance
  • Radial vibration measurement on fluid-film-bearing machinery
  • Static shaft-position measurement in rotating equipment
  • Keyphasor phase-reference and rotational-speed measurement
Description
Bently Nevada 330104-02-09-10-01-00 is a standard-mount 3300 XL 8 mm proximity probe with armor and an M10×1 thread. Its decoded configuration provides a 20 mm unthreaded length, 90 mm overall case length, and 1.0 m total probe-and-cable length.

The 01 connector option specifies a miniature coaxial ClickLoc connector with a connector protector and standard cable, while 00 states that agency approval is not required. The probe is designed as part of the 3300 XL 8 mm proximity transducer system for vibration, position, and Keyphasor measurements.

Before installation, match the one-meter probe to the correct one-meter Proximitor sensor system, confirm the M10×1 mounting geometry, and limit thread engagement to 15 mm. Verify target material and calibration because published performance is based on an AISI 4140 steel target.
Alternative Names
330104-02-09-10-01-00 330104 02 09 10 01 00 3301040209100100 Bently Nevada 330104-02-09-10-01-00 Bently Nevada 330104 02 09 10 01 00 Baker Hughes Bently Nevada 330104-02-09-10-01-00
Technical notes
Bently Nevada 330104-02-09-10-01-00 is a standard-temperature M10×1 armored probe; match the one-meter system and limit thread engagement to 15 mm.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can I confirm that Bently Nevada 330104-02-09-10-01-00 will fit the existing installation?
Compare the complete probe number, mounting thread, case geometry, cable arrangement, connector type, approval option, and available installation clearance with the removed probe.
What should be checked if Bently Nevada 330104-02-09-10-01-00 gives an unstable signal after replacement?
Check probe gap, target condition, connector seating, cable damage, grounding, routing near electrical noise, and compatibility with the installed extension cable and Proximitor sensor.
Can the integral cable on Bently Nevada 330104-02-09-10-01-00 be shortened or repaired onsite?
Field alteration can change system length and electrical performance. Replace damaged assemblies or follow an approved OEM repair procedure instead of cutting or reterminating the cable.
Does target material affect Bently Nevada 330104-02-09-10-01-00 calibration?
Yes. Published system performance is based on an AISI 4140 steel target. Other shaft materials or geometries may require verification or special calibration.
Can the existing extension cable and Proximitor sensor be reused with Bently Nevada 330104-02-09-10-01-00?
Only when their series, electrical length, connector arrangement, approvals, and calibration match the replacement probe. Confirm the complete measurement loop before reuse.
How can Bently Nevada 330104-02-09-10-01-00 be protected from installation damage?
Avoid twisting the integral cable, excessive bending, connector strain, impact to the probe tip, improper locknut tightening, and contact with the rotating target.
What should be tested after installing Bently Nevada 330104-02-09-10-01-00?
Verify gap voltage, signal stability, shaft clearance, polarity, system response, channel scaling, alarms, trips, and machine behavior before returning the monitoring loop to service.
