    Apter Power offers this genuine Bently Nevada 330106-05-30-05-02-CN probe. This rugged and durable sensor is essential for maintaining the proper functioning of rotating equipment.

330106-05-30-05-02-CN

/ 4.9
1001 reviews | Need a Specific Revision?
The 3300 XL 8 mm Reverse Mount Probe, model 330106-05-30-05-02-CN, is designed for reverse-mount installation requirements in industrial monitoring applications.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330106-05-30-05-02-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330106-05-30-05-02-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330106-05-30-05-02-CN
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    Probe
  • Stock:
    1
  • Total Length:
    0.5 meter (1.6 feet)
  • Connector and Cable-Type:
    Miniature ClickLoc coaxial connector
  • Agency Approval:
    CSA, ATEX, IECEx Approvals
  • Fluid Leakage Prevention Option:
    FluidLoc prevents oil and other liquids from leaking through the cable interior
  • CableLoc Design Purpose:
    Ensures 330 N (75 lbf) pull strength for secure cable attachment
  • TipLoc Design Purpose:
    Provides a stronger bond between the probe tip and probe body
  • Cable Type:
    Standard 75Ω triaxial FEP-insulated cable
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    20.5x22.4x3.3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Safety & Compliance

Features:

  • Unmatched System Interchangeability
  • Advanced Environmental Robustness
  • ClickLoc™ Connector Reliability
The Bently Nevada 330106-05-30-05-02-CN allows complete interchangeability of probes, extension cables, and Proximitor sensors without matching or bench calibration. This feature simplifies inventory management and minimizes the time required for system repairs in critical turbomachinery environments.

Featuring a specialized TipLoc™ molding and CableLoc™ attachment, the Bently Nevada 330106-05-30-05-02-CN withstands significant physical stress, including 330 N pull strength. Its improved RFI/EMI immunity meets CE standards, allowing for reliable operation in high-noise electrical environments without costly shielded conduits.

The Bently Nevada 330106-05-30-05-02-CN utilizes gold-plated ClickLoc™ connectors that provide a secure, corrosion-resistant link. The locking mechanism ensures the connection remains tight under vibration, and the "click" sound provides immediate physical feedback during installation, eliminating the need for specialized torque tools.

The 330106-05-30-05-02-CN Bently Nevada 3300 XL 8 mm Reverse Mount Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330106-05-30-05-02-CN 3300 XL 8 mm Reverse Mount Probes Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330106-05-30-05-02-CN 3300 XL 8 mm Reverse Mount Probes

General

  • Manufacturer GE / Bently Nevada
  • Model 330106-05-30-05-02-CN
  • Condition New Original ready stock
  • Product Family 330106-05-30-05-02-00,330106-05-30-15-02-00,330106-05-30-50-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Fluid-Film Bearing Monitoring: Ideal for measuring oil film thickness and journal dynamic movement in large turbo-machinery, high-pressure pumps, and industrial compressors.
  • Radial Vibration Analysis: Captures continuous, high-speed radial shaft movement to detect unbalance, misalignment, or rotor instabilities before equipment failure occurs.
  • Axial Shaft Position Control: Monitors crucial thrust position variations in steam and gas turbines to protect against devastating rotor-to-stator mechanical contact.
  • Speed Sensing & Keyphasor Input: Serves as a precise tachometer and phase reference pickup on small to medium shafts to enable accurate diagnostic timing.
  • Wide Thermal Range: Functions consistently across extreme temperature environments ranging from -52°C up to +177°C, fitting most industrial machinery enclosures.
  • Integrated Viton Pressure Sealing: Built with internal Viton O-rings to provide robust pressure sealing between the probe tip and case assembly, keeping internal fluids contained.
  • High Humidity Immunity: Engineered to maintain maximum calibration integrity with less than a 3% change in scale factor under continuous 93% relative humidity exposure.
  • Vibration Resistant Connectors: Gold-plated ClickLoc connectors utilize an internal mechanical lock mechanism to maintain physical contact under harsh machine vibrations.
  • API 670 Standard Adherence: Meets all standard guidelines for linear range, accuracy, and temperature drift parameters required by global petrochemical monitoring sectors.
  • Intrinsically Safe Certifications: Features ATEX, IECEx, and cNRTLus approvals for Zone 0, Zone 2, Div 1, and Div 2 hazardous environments when paired with approved barriers.
  • Functional Safety Ready: Certified for high-reliability applications, supporting up to SIL 2 architectures with single-channel configurations (HFT=0) or SIL 3 with hardware redundancy.
  • CE Mark and EMC Compliance: Satisfies European Directive 2014/30/EU standards for industrial immunity and emissions without requiring special shielded metal housings.
Description
The 3300 XL 8 mm Reverse Mount Probe, model 330106-05-30-05-02-CN, is designed for reverse-mount installation requirements in industrial monitoring applications. This probe features M10 × 1 threads, allowing secure and accurate mounting in metric-thread configurations.

The 330106-05-30-05-02-CN probe assembly has a total length of 0.5 meter (1.6 feet), making it suitable for compact installations where shorter cable lengths are preferred.

For signal connection, the 330106-05-30-05-02-CN is equipped with a Miniature ClickLoc coaxial connector and cable, ensuring stable signal transmission and reliable compatibility with related monitoring systems.

This model carries CSA, ATEX, and IECEx approvals, making the 330106-05-30-05-02-CN suitable for use in hazardous and regulated environments that require certified proximity sensing components.
Alternative Names
330106 05 30 05 02 CN 330106-05-30-05-02-00 330106-05-30-05-02-05 330106-05-30-05-02-CN 33O1O6-O5-3O-O5-O2-CN 330106-05-30-05-02-00 330106-05-30-05-02-05 330106-05-30-05-12-CN
Technical notes
The Bently Nevada 330106-05-30-05-02-CN is factory-calibrated for AISI 4140 steel targets, ensuring optimal linearity and accuracy for standard industrial applications. Users of the Bently Nevada 330106-05-30-05-02-CN must ensure that the total system length, including the extension cable, matches the factory-calibrated configuration to maintain specified frequency response.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does this 330106-05-30-05-02-CN include armor protection?
No, this probe is designed without armor.
Does the Bently Nevada 330106-05-30-05-02-CN support non-standard target materials?
By default, the Bently Nevada 330106-05-30-05-02-CN is calibrated for AISI 4140 steel; however, calibration for other conductive materials is available upon custom factory request.
What are the installation requirements for the Bently Nevada 330106-05-30-05-02-CN in hazardous areas?
The Bently Nevada 330106-05-30-05-02-CN must be installed according to specific hazardous area drawings (e.g., 141092 for intrinsic safety) to maintain ATEX/IECEx compliance.
Does the Bently Nevada 330106-05-30-05-02-CN support integration with non-XL legacy systems?
Yes, the Bently Nevada 330106-05-30-05-02-CN features full physical and electrical backward compatibility with standard, non-XL 3300 series 5 mm and 8 mm system components. However, engineers should note that mixing XL and non-XL components will restrict the overall performance limits to the lower specifications of the legacy non-XL 3300 Transducer System.
How does the total system length loop calculation work for the Bently Nevada 330106-05-30-05-02-CN proximity probe?
The Bently Nevada 330106-05-30-05-02-CN is configured as a 0.5-meter probe. To function within a standard 5-meter Proximitor Sensor loop configuration, it must be matched with a 4.5-meter 3300 XL extension cable. Maintaining exactly 5.0 meters of combined cable length is mandatory to preserve the 200 mV/mil calibrated scale factor and linear range accuracy.
