          Apter Power supports 330190-040-01-00 quotations, ordering-code checks, and access to the available datasheet.

        330190-040-01-00

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330190-040-01-00 is a 4.0 m armored 3300 XL extended-temperature extension cable for matched probe and Proximitor systems.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 330190-040-01-00
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330190-040-01-00

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330190-040-01-00
        • Product Family:
          3300 XL 8 mm Probe
        • Product Type:
          3300 XL ETR Armored Extension Cable
        • Stock:
          4
        • Cable Function:
          Extended-temperature-range extension cable
        • Cable Option:
          Armored cable
        • Agency Approval Option:
          00 - not required
        • Cable Construction:
          75 ohm triaxial
        • Insulation:
          PFA
        • Typical Capacitance:
          69.9 pF/m
        • Core DC Resistance at 4 m:
          0.88 ± 0.13 ohm
        • Jacket DC Resistance at 4 m:
          0.26 ± 0.05 ohm
        • Armor:
          PFA-coated flexible armor
        • Connector Interface:
          Miniature male and female coaxial connectors
        • Cable Length Tolerance:
          +20% / -0%
        • Extended Temperature Cable Range:
          -35 to +260 degrees C
        • Weight:
          0.4 kg
        • Estimated shipping dimensions:
          400 cm cable length
        • Tariff Code:
          8544200000
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Order Code System-Length Matching ClickLoc Connection Product Applications

        Features:

        • 4.0 m extended-temperature-range cable configuration
        • PFA-insulated 75 ohm triaxial signal path
        • Armored construction with miniature coaxial connectors
        The 330190-040-01-00 extends the matched electrical path between a 3300 XL probe and Proximitor sensor without converting the signal to general-purpose field wiring.

        Its PFA-insulated triaxial construction supports the extended-temperature cable configuration, while the armor protects the routed length through the machine or enclosure.

        The complete part number identifies cable length, armor and approval choices, so all four groups must remain together during selection and replacement.

        The Bently Nevada 330190-040-01-00 3300 XL ETR Armored Extension Cable is listed as Active / Available from OEM. For 330190-040-01-00 sourcing, Apter Power can review ordering-code details and available manufacturer documentation.

        Bently Nevada 330190-040-01-00 3300 XL ETR Extension Cable Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Reading 330190-040-01-00 Before Replacement

        • Family code: 330190 identifies the 3300 XL extended-temperature extension-cable family.
        • Length code 040: The cable length is 4.0 metres (11.5 feet).
        • Armor code 01: This position specifies armored cable construction for additional mechanical protection.
        • Approval code 00: The ordering string indicates that an agency approval option is not required.

        Keeping the 3300 XL ETR Signal Path Matched

        • Total electrical length: Probe lead length plus extension-cable length must equal the total length configured for the Proximitor Sensor.
        • ETR continuity: Keep the probe, extension cable, and sensor within the compatible extended-temperature system rather than mixing parts by connector fit alone.
        • Complete-path check: Record all three component identities before replacement because one matching cable code does not validate the whole measurement chain.
        • Return-to-service: Confirm the configured system length and stable signal response after any cable change.

        Protecting the 330190-040-01-00 Connection

        • Positive engagement: Finger-tighten the gold-plated ClickLoc connector until the locking action clicks.
        • Vibration security: The locking mechanism helps prevent the connection from loosening without requiring special tools.
        • Clean mating surfaces: Inspect the connector for contamination, bent parts, or damage before joining the signal path.
        • Mechanical protection: Use the recommended connector protector and route the armored cable so its weight does not load the connection.

        Where 330190-040-01-00 Supports Measurement

        • Machine vibration: The cable completes a compatible 3300 XL ETR proximity path used for vibration monitoring on fluid-film bearing machines.
        • Shaft position: It can form part of the matched transducer system used to observe relative shaft position.
        • Keyphasor and speed: Compatible system arrangements support phase-reference and rotational-speed measurements.
        • Elevated-temperature routing: The ETR construction is intended for sections where probe leads or extension cables exceed standard temperature limits.
        Description
        The Bently Nevada 330190-040-01-00 3300 XL ETR Extension Cable forms the signal connection between a compatible extended-temperature probe lead and the Proximitor sensor in a matched proximity-transducer system.

        Every group in 330190-040-01-00 defines part of the supplied construction: 040 selects the 4.0 m length, 01 identifies flexible armor, and the final 00 distinguishes the configuration without the optional agency-approval package. Keeping the complete code prevents a visually similar cable from being substituted on length alone.

        Measurement behavior with 330190-040-01-00 depends on the probe, extension cable, and Proximitor being treated as one electrical chain. Total system length, connector condition, bend routing, armor damage, and the exact 3300 family should be checked before calibration or alarm settings are changed.
        Alternative Names
        Bently Nevada 330190-040-01-00 3301900400100 330190 040 01 00 330190-040-01-00 ETR 330190-040-01-00 Cable 330190-040-01-00 Extension Cable 330190-040-01-00 Armored Cable 330190-040-01-00 4 m
        Technical notes
        Match 330190-040-01-00 with the probe and Proximitor total length; inspect armor and miniature connectors before returning the measurement loop to service.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How should damage on a 330190-040-01-00 cable be assessed?
        Inspect the full 330190-040-01-00 cable for crushed armor, sharp bends, heat exposure, contaminated connectors, loose coupling, insulation damage, and intermittent response during a controlled cable movement check.
        What must be matched when replacing Bently Nevada 330190-040-01-00?
        The complete 330190-040-01-00 ordering code, cable length, armor option, temperature rating, probe family, extension cable, and Proximitor sensor must be checked as one measurement chain.
        What evidence is useful when ordering 330190-040-01-00?
        Provide the complete 330190-040-01-00 label, probe and Proximitor numbers, required physical length, connector and armor details, installation temperature, and photographs of both cable ends.
        Why can a new 330190-040-01-00 change the vibration reading?
        A 330190-040-01-00 replacement can shift system output when total electrical length, probe type, connector condition, routing, target material, or Proximitor calibration differs from the original installation.
        Can 330190-040-01-00 be shortened or spliced in the field?
        Field shortening or splicing of 330190-040-01-00 is not appropriate because the calibrated proximity system depends on the specified cable construction and total electrical length.
