330130-075-00-CN

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330130-075-00-CN is a 7.5 m 3300 XL extension cable that carries an 8 mm probe signal to its matched Proximitor sensor. The full option string must match the installed measurement chain.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330130-075-00-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-075-00-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-075-00-CN
  • Product Family:
    3300 XL Extension Cable
  • Product Type:
    3300 XL Proximity Transducer Extension Cable
  • Stock:
    1
  • Extension Cable Capacitance:
    69.9 pF/m (21.3 pF/ft) typical
  • Extension Cable Material:
    75 Ω triaxial, FEP-insulated extension cable
  • Operating and Storage Temperature:
    -52°C to +177°C (-62°F to +350°F)
  • Cable Length Option:
    7.5 m (24.6 ft)
  • Cable Option:
    Standard cable (ordering option 00)
  • Nominal Extension Cable DC Resistance:
    1.65 ± 0.25 Ω
  • Outer-Conductor DC Resistance:
    0.49 ± 0.10 Ω
  • Cable Length Tolerance:
    +20%, -0%
  • Minimum Cable Bend Radius:
    25.4 mm (1.0 in)
  • Maximum Cable Outside Diameter:
    3.7 mm (0.15 in) maximum
  • Cable Connector Material:
    Gold-plated brass or gold-plated beryllium copper
  • Weight:
    0.5732 lbs (0.26 kg)
  • Estimated shipping dimensions:
    19.5 x 18.8 x 2.8 cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Compatibility Installation

Features:

  • Provides a 7.5 m extension-cable option for a 3300 XL proximity transducer loop.
  • Uses the standard-cable construction specified for the 330130 extension-cable family.
  • Requires total probe-plus-extension length to match the Proximitor sensor system.

The ordering configuration specifies a 7.5 m 3300 XL extension cable with standard cable option 00; the extra CN suffix is not defined in the cited OEM code table.

In the transducer loop, the cable carries the proximity probe signal to the Proximitor sensor as part of a compatible 3300 XL arrangement.

Before installation, verify the complete label and approval record, match the combined probe and extension length to the sensor, and follow connector handling limits.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Bently Nevada 330130-075-00-CN:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Applied in rotating-machinery monitoring loops where a 3300 XL proximity probe feeds a Proximitor sensor.
  • Supports shaft vibration and position measurement installations using the specified 3300 XL transducer system.
  • Routes the probe signal between the machine-side probe connection and the sensor-side monitoring hardware.
  • The 75 Ω triaxial cable construction carries the proximity transducer signal through the extension segment.
  • FEP insulation provides the documented cable construction for the specified 3300 XL extension-cable family.
  • Miniature coaxial connectors form the electrical interface at the cable ends.
  • Use within a compatible 3300 XL proximity transducer loop with its corresponding probe and Proximitor sensor.
  • The probe and extension cable lengths must total the system length required by the Proximitor sensor.
  • Verify the CN suffix against the installed label and approval documentation; it is not defined in the cited OEM ordering table.
  • Route the cable without bending below the manufacturer’s minimum bend radius.
  • Inspect both connector ends and retain the installed connector-protector arrangement when matching a replacement.
  • Confirm the complete part label, cable option, and approval record before reconnecting the transducer loop.
Description
Bently Nevada 330130-075-00-CN provides a 7.5 m interconnect within a 3300 XL 8 mm proximity measurement chain. The cable carries the probe signal to the Proximitor sensor selected for the installed machinery-monitoring channel.

Its triaxial construction and FEP jacket are engineered for the electrical behavior and industrial routing conditions specified for the 3300 XL transducer family. The ordered length supports installations where the probe lead alone cannot reach the sensor location.

Maintenance personnel should identify this cable by the complete ordering string, not only the 330130 family prefix. Probe lead length, sensor type, connector condition, routing, and documented approval requirements must be reconciled before the old cable is exchanged.
Alternative Names
330130-075-00-CN 330130 075 00 CN 330130-075-00CN 33013007500CN Bently Nevada 330130-075-00-CN 3300 XL 330130-075-00-CN 330130-075-00-CN Extension Cable GE Bently Nevada 330130-075-00-CN
Technical notes
Do not select 330130-075-00-CN from the 330130 prefix alone; verify the 7.5 m length, complete option string, mating probe lead, and sensor calibration.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What measurement path is completed by Bently Nevada 330130-075-00-CN?
It transfers the signal between the 3300 XL 8 mm probe lead and the Proximitor sensor assigned to the machinery-monitoring channel.
When does the 7.5 m ordering length matter for Bently Nevada 330130-075-00-CN?
The probe lead and extension cable together must satisfy the system length expected by the sensor; the 7.5 m option cannot be changed independently.
How should Bently Nevada 330130-075-00-CN connectors be protected during maintenance?
Keep the mating surfaces capped until connection, prevent oil or debris contamination, and never pull or rotate the cable by the connector body.
What evidence prevents suffix confusion when replacing Bently Nevada 330130-075-00-CN?
Record the complete printed code, cable length, connector photographs, probe number, sensor number, and installation drawing before removal.
Which functional check follows installation of Bently Nevada 330130-075-00-CN?
After routing, verify connector engagement and confirm the channel response and probe gap through the configured monitoring system before returning the machine to service.
Where should the approved ordering logic for Bently Nevada 330130-075-00-CN be verified?
Use the current official 3300 XL 8 mm transducer-system datasheet and the installed project documentation; a reseller cross-reference is not an interchangeability approval.
