Features:
- 3300 NSv extension cable for transducer systems
- Compatible with previous 3300 RAM probe systems
- Non-armored design for flexible installation
The 330930-040-00-00 provides essential signal connection functions critical to the entire monitoring path, serving as the vital link between NSv probes and signal conditioning electronics, directly affecting the proper, normal operation of the overall protection system. One 330930-040-00-00 extension cable is required per measurement point, connecting the NSv probe mounted on machinery to the remotely located Proximitor sensor. The 330930-040-00-00 features non-armored flexible construction that facilitates routing through control cabinets and cable trays without complex installation procedures.
For applications requiring upgrades from legacy systems, the 330930-040-00-00 supports two distinct migration paths. When upgrading from 3300 RAM systems, the 330930-040-00-00 can be used with existing RAM probes and monitoring equipment, requiring only Proximitor Sensor replacement. In addition, for upgrades from 3000-series or 7000-series 190 systems, the 330930-040-00-00 requires complete replacement of probe, extension cable, and Proximitor Sensor with NSv components due to different specifications.
The 330930-040-00-00's performance is verified under standard test conditions of 0°C to +45°C with -24 Vdc power supply and 10 kΩ load, using an AISI 4140 steel target of 31 mm diameter minimum gapped at 1.0 mm. The 330930-040-00-00 is designed as part of the complete 3300 XL NSv transducer system, with system accuracy and interchangeability specifications applying only when using transducer systems calibrated to Bently Nevada supplied AISI 4140 steel targets. This ensures consistent, reliable performance across all monitored points while enabling flexible upgrade paths from legacy installations.
The 330930-040-00-00 Bently Nevada Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330930-040-00-00 Extension Cable Manuals,Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330930-040-00-00 Extension Cable Specs
General
- Manufacturer GE / Bently Nevada
- Model 330930-040-00-00
- Condition New Original ready stock
- Product Family
330930-060-00-00,330930-065-00-00,330930-040-05-00,330930-040-06-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not
included with this equipment unless listed in the above stock item description. All prices are
shown in USD.
- Radial vibration and radial position measurements on shafts smaller than 51 mm (2 in)
- Axial (thrust) position measurements on flat targets smaller than 15 mm (0.6 in)
- Tachometer and zero speed measurements in fluid-film bearing machines
- Phase reference (Keyphasor™ signals) in compressors with limited installation space
- Connects NSv probes to a 3300 XL NSv Proximitor Sensor for complete system integration
- Equipped with gold-plated brass ClickLoc connectors for secure and vibration-resistant connections
- Fully compatible with existing 3300 RAM probe and extension cable infrastructure for system upgrades
- Supports the use of connector protectors to prevent moisture or liquid ingress and ensure signal stability
- Ensures stable and accurate signal transmission within the 3300 XL NSv Proximity Transducer System
- Maintains signal integrity over a 4.0-meter length in non-armored configurations
- Supports high-performance NSv probe operation, including enhanced side-view measurement capability
- System accuracy is verified with AISI 4140 steel targets and applies only when calibrated to Bently Nevada supplied targets
