330901-00-19-10-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
The 330901-00-19-10-02-00 is a 3300 NSv Proximity Probe featuring a 1/4-28 UNF thread without armor. This model includes a 1.0 meter (39 inch) total length with an overall case length of 1.9 inches and unthreaded length of 0.0 inches.
Get a quick price for 330901-00-19-10-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330901-00-19-10-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330901-00-19-10-02-00
  • Product Family:
    NSV Probe
  • Product Type:
    3300 NSv Proximity Probe
  • Thread Type:
    1/4-28 UNF (without armor)
  • Total Length:
    1.0 meter (39 inches)
  • Unthreaded Length:
    0.0 inches
  • Overall Case Length:
    1.9 inches
  • Connector Type:
    Miniature coaxial ClickLoc™
  • Connector Material:
    Gold-plated brass
  • Cable Type:
    Standard cable
  • Agency Approval:
    Not required
  • Key Benefit:
    Model 330901-00-19-10-02-00 addresses measurement accuracy challenges in confined spaces with superior side-view characteristics versus 3000-series 190 probes.
  • Weight:
    0.05 kg
  • Estimated shipping dimensions:
    1.2x1x117cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Installation and Upgrades Diagnosis and Protection

Features:

  • The 330901-00-19-10-02-00 features a 1/4-28 UNF thread configuration without armor.
  • This model includes a compact 1.9-inch overall case length for space-constrained installations.
  • The 330901-00-19-10-02-00 offers increased chemical resistance for process compressor applications.
The 330901-00-19-10-02-00 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe designs. This NSv probe features increased chemical resistance compared to the 3300 RAM probe, allowing its use in many process compressor applications where exposure to aggressive media is common. The 330901-00-19-10-02-00 enables seamless upgrades from legacy 3300 RAM installations while providing enhanced durability in chemically challenging environments.

The side-view characteristics of the 330901-00-19-10-02-00 are superior to those of the 3000-series 190 probe when gapping at the same distance from the probe target. This improved performance enables more accurate measurements in confined spaces and applications where probe orientation presents challenges. With no agency approvals required, the 330901-00-19-10-02-00 simplifies procurement and deployment for industrial monitoring applications.

The 330901-00-19-10-02-00 represents a complete solution for applications requiring 1/4-28 UNF mounting threads and enhanced chemical resistance in a compact package. This NSv probe delivers reliable vibration and position monitoring while the increased chemical resistance and superior side-view characteristics ensure long-term performance in demanding process environments. The 330901-00-19-10-02-00 maintains compatibility with legacy systems while providing significant performance improvements.

The 330901-00-19-10-02-00 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330901-00-19-10-02-00 3300 NSv Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330901-00-19-10-02-00 3300 NSv Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330901-00-19-10-02-00
  • Condition New Original ready stock
  • Product Family 330901-00-19-10-01-00,330901-00-19-10-11-00,330901-00-19-10-02-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Narrow space monitoring: Suitable for areas where standard 5mm or 8mm probes cannot be installed due to lateral clearance limitations, reverse drilling, or rearward restrictions.
  • Typical machine types: Widely used in centrifugal air compressors, refrigeration compressors, process gas compressors, and other machines with stringent installation requirements.
  • Measurement parameters: Used to measure radial vibration, radial position, axial (thrust) position, speed (counter), and keyphasor signal.
  • Ease of Installation: The included 3300 XL NSv preamplifier (Proximitor Sensor) supports high-density DIN rail mounting or traditional panel mounting, and features SpringLoc terminal blocks for quick wiring without special tools.
  • 3300 RAM System Upgrade: When upgrading to the 3300 XL NSv, the existing probes, extension cables, and monitoring system can usually be retained; only the preamplifier needs to be replaced.
  • 3000/7000 Series Upgrade: The probes, extension cables, and preamplifier must all be replaced with NSv components.
  • Dynamic and Static Measurement: The system output voltage is proportional to the distance between the probe tip and the measured surface, allowing simultaneous measurement of static (position) and dynamic (vibration) values.
  • Interference Immunity: Enhanced immunity to radio frequency interference (RFI/EMI) prevents adverse effects from nearby high-frequency radio signals on the sensor system.
  • Environmental Protection: The probe tip is made of polyphenylene sulfide (PPS). Users should be aware of the chemical corrosion risk, as solutions with extremely high or low pH values ​​may corrode the probe tip and cause media leakage.
Description
The 330901-00-19-10-02-00 features a 1/4-28 UNF thread configuration without armor, providing installation flexibility for applications requiring standard UNF mounting threads. This model includes a 1.0 meter (39 inch) total length with an overall case length of 1.9 inches and unthreaded length of 0.0 inches.

The 330901-00-19-10-02-00 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe designs. This NSv probe features increased chemical resistance compared to the 3300 RAM probe, allowing its use in many process compressor applications where exposure to aggressive media is common.

The side-view characteristics of the 330901-00-19-10-02-00 are superior to those of the 3000-series 190 probe when gapping at the same distance from the probe target. This improved performance enables more accurate measurements in confined spaces and applications where probe orientation presents challenges.

With no agency approvals required, the 330901-00-19-10-02-00 simplifies procurement and deployment for industrial monitoring applications. This probe delivers reliable vibration and position monitoring while the increased chemical resistance and superior side-view characteristics ensure long-term performance in demanding process environments.
Alternative Names
330901-00-19-10-01-00 330901-00-19-10-11-00 330901-00-19-10-12-00 330901-00-19-10-02-05
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What installation advantage does the 1.9-inch overall case length provide for the 330901-00-19-10-02-00?
The compact 1.9-inch case length allows installation in space-constrained applications where longer probes cannot be accommodated, such as tightly packed machinery or limited clearance installations.
How does the 330901-00-19-10-02-00 improve upon previous 3300 RAM probe designs?
This NSv probe offers increased chemical resistance for process compressor applications and superior side-view characteristics, while maintaining complete mechanical and electrical interchangeability with RAM probes.
What makes the side-view characteristics of the 330901-00-19-10-02-00 superior to 3000-series probes?
Improved side-view response allows accurate gapping at the same distance as 190-series probes, enabling reliable measurements in confined spaces where optimal probe orientation cannot be achieved.
Can the 330901-00-19-10-02-00 be used in applications without hazardous area certifications?
Yes, with no agency approvals required, this probe simplifies deployment in general-purpose industrial applications where hazardous area certifications are not necessary.
