The Model 330902-00-15-10-02-05 is a 3300 NSv proximity probe featuring 1/4-28 UNF mounting threads with armor protection, designed for process compressor applications requiring enhanced chemical resistance and mechanical durability.
Get a quick price for 330902-00-15-10-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330902-00-15-10-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330902-00-15-10-02-05
  • Product Family:
    NSV Probe
  • Mounting Thread:
    1/4-28 UNF
  • Unthreaded Length:
    0.0 in
  • Overall Case Length:
    1.5 in
  • Total Length:
    1.0 meter (39 in)
  • Connector Type:
    Miniature coaxial ClickLoc
  • Cable Type:
    Standard cable with armor
  • Agency Approvals:
    Multiple Approvals
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    2.1x1.9x119cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications

Features:

  • 3300 NSv proximity probe with 1/4-28 UNF threads and armored cable for mechanical protection
  • Flush-mount zero unthreaded design with compact 1.5-inch case length for tight installations
  • Increased chemical resistance with multiple hazardous area approvals and RAM system compatibility
he 330902-00-15-10-02-05 provides essential sensing functions critical to the entire monitoring path, serving as the primary interface between process compressors and the monitoring system, directly affecting the proper, normal operation of the overall protection system. One 330902-00-15-10-02-05 probe is required per measurement point, installed flush in the compressor casing with the 1/4-28 UNF mounting threads.

For applications requiring chemical resistance in aggressive process environments, the 330902-00-15-10-02-05 offers increased resistance compared to previous 3300 RAM probes, allowing reliable operation with corrosive media exposure. In addition to standard signal transmission, the armored construction of the 330902-00-15-10-02-05 protects the integral cable from crushing, abrasion, and mechanical damage during installation and operation.

The 330902-00-15-10-02-05's rugged construction ensures reliable operation in demanding process compressor environments. Using enhanced materials for chemical resistance and precision manufacturing with armored cable protection, the probe delivers consistent performance over extended periods. The multiple hazardous area approvals carried by the 330902-00-15-10-02-05 certify its suitability for installation in potentially explosive atmospheres.

The 330902-00-15-10-02-05 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330902-00-15-10-02-05 3300 NSv Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330902-00-15-10-02-05 3300 NSv Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330902-00-15-10-02-05
  • Condition New Original ready stock
  • Product Family 330902-00-15-10-01-05,330902-00-15-10-11-05,330902-00-15-10-12-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
The Model 330902-00-15-10-02-05 is a specialized 3300 NSv proximity probe featuring 1/4-28 UNF mounting threads with armor protection for demanding process compressor applications. This armored configuration includes a zero unthreaded length for flush mounting and a compact 1.5 in overall case length, with total length of 1.0 meter.

Chemical resistance is a significant advantage of the 330902-00-15-10-02-05 compared to previous probe generations. This NSv probe offers increased chemical resistance relative to the earlier 3300 RAM probe, enabling reliable operation in process compressor applications with aggressive media exposure. The 330902-00-15-10-02-05 maintains side-view characteristics superior to 3000-series 190 probes when gapped at the same distance from the target.

The armored construction of the 330902-00-15-10-02-05 provides critical mechanical protection for the integral cable in demanding installations where physical abuse or harsh routing conditions are present. The armor shielding safeguards the internal conductors from crushing, abrasion, and other mechanical damage during installation and throughout service life.

System compatibility is a key feature of the 330902-00-15-10-02-05, which is mechanically and electrically interchangeable with Bently Nevada's previous 3300 RAM probe systems. This backward compatibility allows seamless integration into existing monitoring installations without system redesign. The combination of armored construction, enhanced chemical resistance, superior side-view characteristics, and multiple agency approvals makes the 330902-00-15-10-02-05 ideal for process compressor applications requiring both mechanical protection and chemical resistance in hazardous areas.
Alternative Names
330902-00-15-10-01-05 330902-00-15-10-11-05 330902-00-15-10-12-05 330902-00-15-10-02-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What are the key dimensional specifications for the 330902-00-15-10-02-05 probe?
The 330902-00-15-10-02-05 features 1/4-28 UNF mounting threads, a zero unthreaded length (0.0 in) for flush mounting applications, and a compact overall case length of 1.5 in. The total length of the probe assembly, including the integral armored cable, is 1.0 meter (39 in), terminated with a miniature coaxial ClickLoc connector featuring gold-plated brass contacts.
What are the advantages of the armored construction on the 330902-00-15-10-02-05?
The armored construction of the 330902-00-15-10-02-05 provides critical mechanical protection for the integral cable in demanding installations where physical abuse or harsh routing conditions are present. The armor shielding safeguards the internal conductors from crushing, abrasion, and other mechanical damage during installation and throughout service life, making this probe exceptionally suited for rugged industrial environments where standard non-armored probes would be vulnerable to damage.
What chemical resistance and side-view benefits does the 330902-00-15-10-02-05 offer?
The 330902-00-15-10-02-05 offers increased chemical resistance compared to previous 3300 RAM probes, allowing reliable operation in process compressor applications with aggressive media exposure.
Is the 330902-00-15-10-02-05 compatible with existing Bently Nevada monitoring systems?
Yes. The 330902-00-15-10-02-05 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe and extension cable systems. This allows for seamless integration into existing monitoring installations while benefiting from the enhanced chemical resistance, superior side-view characteristics, armored construction, and multiple hazardous area approvals.
