330904-00-05-70-01-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330904-00-05-70-01-05 is a 3300 NSv Proximity Probe featuring an M8 x 1 metric thread with armor protection. This model includes a 7.0 meter (23.0 feet) total length with an overall case length of 50 mm and unthreaded length of 0 mm.
Get a quick price for 330904-00-05-70-01-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330904-00-05-70-01-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330904-00-05-70-01-05
  • Product Family:
    NSV Probe
  • Product Type:
    3300 NSv Proximity Probe, Metric
  • Thread Type:
    M8 x 1 (with armor)
  • Total Length:
    7.0 meters (23.0 feet)
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    50 mm
  • Connector Type:
    Miniature coaxial ClickLoc™ with connector protector
  • Connector Material:
    Gold-plated brass
  • Agency Approvals:
    Multiple Approvals
  • Key Benefit:
    Solves the pain point of extended reach in process compressor environments with 7.0-meter cable length, armor protection, and increased chemical resistance—compact 50 mm case fits tight mounting spaces while multiple agency approvals enable global deployment.
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    1.5x1.3x116cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Monitoring

Features:

  • 7.0-meter extended cable length with compact 50 mm case provides remote monitoring capability while fitting in space-constrained mounting ports.
  • M8 x 1 metric thread with armor protection delivers compact mounting and mechanical durability for demanding industrial environments.
  • Increased chemical resistance and superior side-view characteristics enable reliable operation in process compressor applications with accurate measurements in confined spaces.
The 330904-00-05-70-01-05 is designed for installations where the Proximitor sensor must be located at a distance from the measurement point. Its 7.0-meter integral cable eliminates the need for a separate extension cable, reducing the number of connections and potential failure points in the monitoring path. This extended length is particularly valuable in large machinery configurations such as compressors, turbines, and generators, where the sensor is often mounted in a control cabinet away from the machine.

The 330904-00-05-70-01-05 features an M8 x 1 metric thread, one of the most compact mounting options in the NSv series, making it ideal for installations where space is at a premium. The armor protection adds critical mechanical durability, shielding the probe against crushing, abrasion, and impact damage during installation and operation—particularly important for long cable runs through conduit where the cable may be subject to rough handling.

The 330904-00-05-70-01-05 offers significantly increased chemical resistance compared to previous 3300 RAM probe designs, making it ideally suited for process compressor applications where exposure to aggressive media is routine. The superior side-view characteristics of the NSv series compensate for installation limitations in confined spaces, enabling accurate measurements even when perfect perpendicular alignment is not possible.

The 330904-00-05-70-01-05 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330904-00-05-70-01-05 3300 NSv Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330904-00-05-70-01-05 3300 NSv Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330904-00-05-70-01-05
  • Condition New Original ready stock
  • Product Family 330904-00-05-70-02-05,330904-00-05-70-12-05,330904-00-05-70-01-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Confined Space Installation: Used for observing equipment with very small counterbores (e.g., diameter less than 9.5 mm), avoiding induced interference between the probe's magnetic field and the bore wall.
  • Precision Shaft Vibration Monitoring: When the shaft diameter is very small and the magnetic field coverage of a standard probe exceeds the radius of curvature of the shaft, the NSV probe provides more accurate radial vibration data.
  • Keyphasor Applications: Used in space-constrained bearing chambers to measure speed and phase reference.
  • Dielectric Resistance: The probe tip is encapsulated in PPS (polyphenylene sulfide), providing excellent corrosion resistance against most industrial lubricants, acidic solvents, and chemicals.
  • Protection Rating: The probe tip meets IP68 standards, maintaining a seal even within oil-filled bearing housings.
  • Cable Sheath: FEP (fluoropolymer) insulated cable (specified by option 05), offering high abrasion resistance and chemical resistance.
  • Supporting System: Requires connection to a 3300 XL NSV preamplifier (Proximitor) (model 330980).
  • Linear Range: Standard linear range is approximately 1.5 mm (60 mils). This is slightly shorter than the standard 8mm probe, but optimized for small targets.
  • Gap Voltage Control: During installation, the gap voltage must be adjusted to the midpoint of the linear range (typically approximately -9V to -10V DC).
Description
The 330904-00-05-70-01-05 features an M8 x 1 metric thread with armor protection, providing enhanced durability for demanding industrial installations requiring compact metric mounting standards. This model includes a 7.0 meter (23.0 feet) total length with an overall case length of 50 mm and unthreaded length of 0 mm.

The 330904-00-05-70-01-05 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe designs. This NSv probe features increased chemical resistance compared to the 3300 RAM probe, allowing its use in many process compressor applications where exposure to aggressive media is common.

The side-view characteristics of the 330904-00-05-70-01-05 are superior to those of the 3000-series 190 probe when gapping at the same distance from the probe target. This improved performance enables more accurate measurements in confined spaces and applications where probe orientation presents challenges.

The 330904-00-05-70-01-05 represents a complete solution for applications requiring M8 x 1 metric mounting threads with armor protection and a 7.0-meter extended length. This NSv probe delivers reliable vibration and position monitoring while the increased chemical resistance and superior side-view characteristics ensure long-term performance in demanding process environments.
Alternative Names
330904-00-05-70-02-05 330904-00-05-70-12-05 330904-00-05-70-11-05 330904-00-05-70-01-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What installation advantage does the 7.0-meter cable length provide?
The extended 7.0-meter cable allows the Proximitor sensor to be located in a control cabinet remote from the measurement point, eliminating the need for a separate extension cable.
What makes the M8 x 1 thread beneficial?
The compact metric thread is ideal for installations where space is limited, allowing the probe to fit into tight mounting ports without requiring adapters.
How does the armor protection benefit this probe?
The armored construction shields the probe against crushing, abrasion, and impact damage during installation and operation, particularly valuable for long cable runs through conduit.
Can the 330904-00-05-70-01-05 replace existing 3300 RAM probes?
Yes, it is mechanically and electrically interchangeable with 3300 RAM probes, enabling seamless upgrades while gaining improved chemical resistance and side-view performance.
