330909-00-60-10-02-05

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330909-00-60-10-02-05 3300 NSv Probe with 3/8-24 UNF thread and armored cable, designed for precise radial and axial measurements in compact or restricted spaces.
Get a quick price for 330909-00-60-10-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330909-00-60-10-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330909-00-60-10-02-05
  • Product Family:
    NSV Probe
  • Unthreaded Length Option:
    Minimum unthreaded length: 0.0 in
  • Overall Case Length Option:
    60=6.0 in
  • Total Length Option:
    10=1.0 meter (39 in)
  • Connector and Cable-Type Option:
    02=Miniature coaxial ClickLoc connector, standard cable
  • Agency Approval Option:
    05=Multiple Approvals
  • Operating Temperature:
    -52°C to +177°C (-62°F to +351°F)
  • Probe Case Material:
    AISI 304 stainless steel (SST)
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    118x1.5x1.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Diagnostics & Protection Operating Environment

Features:

  • Probe Configuration with 3/8-24 UNF Thread and Armor Protection
  • Integrates Miniature Coaxial ClickLoc Connector for Secure Signal Transmission
  • Delivers NSv Performance Optimized for Small Target Measurement Applications
330909-00-60-10-02-05 serves as the 3300 NSv proximity probe in vibration monitoring systems, providing precise displacement measurement for shaft diameters smaller than 51 mm (2 inches). It continuously detects gap variations between the probe tip and target surface, converting mechanical vibration into electrical signals transmitted through the 1.0 meter (39-inch) integral cable to monitoring equipment. 330909-00-60-10-02-05 features a 6.0-inch case length and unthreaded design, specifically configured for applications requiring 3/8-24 UNF threaded mounting. Standard signal transmission is achieved through the ClickLoc™ connector, with armor protection ensuring durability in harsh industrial environments.

330909-00-60-10-02-05 provides critical sensing functions for radial vibration monitoring and is an essential component of the measurement path, directly affecting the accuracy of overall monitoring system vibration data acquisition. Each measurement point utilizes one 330909-00-60-10-02-05 probe depending on monitoring configuration requirements. The probe employs a compact design with minimal installation footprint, always requiring proper gap setting with the target surface during installation.

For small target applications, the 3300 NSv system with 330909-00-60-10-02-05 delivers optimized measurement capability for shaft diameters below 51 mm, where standard 8 mm probes cannot be applied. In addition to standard radial vibration measurement, this probe configuration also supports thrust position and speed measurement applications. The 3300 NSv transducer system performs signal conditioning through matched 3300 XL NSv Proximitor sensors. Using this method, the probe maintains stable output continuously throughout the 1.5 mm (60 mils) linear range. If the system detects gap setting outside recommended parameters (beyond 1.0 mm/40 mils target), signal quality and measurement accuracy will be affected.

The 330909-00-60-10-02-05 Bently Nevada 3300 NSv Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330909-00-60-10-02-05 3300 NSv Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330909-00-60-10-02-05 3300 NSv Proximity Probe Specs

General

  • Manufacturer Bently Nevada
  • Model 330909-00-60-10-02-05
  • Condition New Original ready stock
  • Product Family 330909-00-60-10-02-00,330909-00-60-10-02-CN,330909-00-60-05-02-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Centrifugal Air Compressors: Ideal for monitoring internal clearances where mounting space is minimal.
  • Refrigeration & Process Gas Compressors: Frequently applied in these systems due to its superior chemical resistance.
  • Small Shaft Monitoring: Specifically designed for measuring radial vibration on shafts smaller than 51 mm (2 in) or axial position on targets smaller than 15 mm (0.6 in).
  • Restricted Clearances: Used when side-view or counterbore restrictions limit the electrical "viewing" area of the probe.
  • Radial Vibration & Position: Monitors the lateral movement of the shaft within its bearings to detect imbalances or misalignments.
  • Axial (Thrust) Position: Measures the longitudinal movement of the shaft to protect against thrust bearing failure.
  • Phase Reference (Keyphasor): Provides timing signals for vibration phase analysis, essential for balancing and advanced diagnostics.
  • Tachometer & Zero Speed: Can be used to monitor shaft rotation speed and detect startup/shutdown conditions.
  • Temperature Range: Typically operates from –34°C to +177°C (–30°F to +351°F).
  • Chemical Resistance: Features a Polyphenylene Sulfide (PPS) tip and internal seals that offer improved resistance to process chemicals compared to standard RAM probes.
  • Pressure Sealing: Includes a Viton® O-ring and internal pressure seals to prevent process media from leaking through the probe body.
  • Mechanical Strength: Utilizes CableLoc™ and TipLoc™ designs to provide up to 220 N (50 lb) of pull strength, protecting the connection from physical stress.
Description
The Bently Nevada 330909-00-60-10-02-05 3300 NSv Probe is a high-precision proximity transducer engineered for fluid-filmed bearing machines with space constraints. It is particularly suited for applications where counter bore, sideview, or rearview restrictions prevent the use of standard 3300 or 3300 XL 5 and 8 mm Transducer Systems.

This probe is ideal for small-target measurements, such as radial vibration on shafts smaller than 51 mm (2 in) or axial position on flat targets smaller than 15 mm (0.6 in). It supports radial vibration, radial position, axial (thrust) position, tachometer, zero speed, and phase reference (Keyphasor) measurements, making it versatile for critical machinery monitoring.

The probe features a 3/8-24 UNF threaded connection with an armored cable for enhanced mechanical protection. The case is made of AISI 304 stainless steel (SST) for durability in harsh industrial environments. Operating temperature ranges from -52°C to +177°C (-62°F to +351°F), ensuring reliable performance under extreme conditions.

The 3300 XL NSv Proximity Transducer System includes the probe, extension cable, and the 3300 XL NSv Proximitor Sensor. The miniature coaxial ClickLoc connector ensures secure connectivity, and the probe carries multiple agency approvals (Option 05), making it suitable for global installations. Unthreaded length options start at 0.0 inches, and the overall case length is 6.0 inches, with total system length up to 1.0 meter (39 inches).
Alternative Names
33O9O9-OO-6O-1O-O2-O5 330g0g-00-60-10-02-05 330909-00-60-I0-02-05 330909-00-60-10-0Z-05 3309090060100205 330909 00 60 10 02 05 33O9O9OO6O1OO2O5
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the overall case length of the 330909-00-60-10-02-05 probe?
The overall case length is 6.0 inches.
How quickly can the 330909-00-60-10-02-05 probe be shipped?
Orders are typically shipped within 12–3 business days, depending on stock availability.
What is the total system length?
The total length of the probe system is 1.0 meter (39 inches).
What is the 330909-00-60-10-02-05 probe case material?
The probe case is made of AISI 304 stainless steel (SST).
