Bently Nevada 330910-00-13-10-02-00
Bently Nevada 330910-00-13-10-02-00
Bently Nevada 330910-00-13-10-02-00
Bently Nevada 330910-00-13-10-02-00
Bently Nevada 330910-00-13-10-02-00
Bently Nevada 330910-00-13-10-02-00
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com
  • Lifecycle Status

    Active / Available from OEM
    Strengthening your diagnostic capabilities, Apter Power supplies genuine Bently Nevada instrumentation to ensure accurate, long-term health monitoring of your critical rotating equipment.

330910-00-13-10-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
The 330910-00-13-10-02-00 features an M10 × 1 threaded body and is supplied with armor, providing enhanced mechanical protection for use in demanding industrial environments.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330910-00-13-10-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330910-00-13-10-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330910-00-13-10-02-00
  • Product Family:
    NSV Probe
  • Product Type:
    3300 NSv Proximity Probe
  • Stock:
    1
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    130 mm
  • Total Length:
    1.0 meter (39 in)
  • Connector -Type:
    Miniature coaxial ClickLoc connector
  • Cable-Type:
    standard cable
  • Probe Cable Insulation:
    Fluoroethylene propylene (FEP)
  • Available Probe Cable Lengths:
    0.5 m, 1 m, 5 m, 7 m
  • Operating Temperature:
    -52°C to +177°C (-62°F to +351°F)
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    1.8x1.6x108cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Compatibility Installation Application Scenarios

Features:

  • Compact probe construction enables installation in machines with restricted counter bore, side-view, or rear-view clearance while maintaining accurate shaft monitoring.
  • Supports multiple machine protection functions including radial vibration, radial position, axial position, tachometer, zero speed, and Keyphasor signal measurement.
  • Wide operating temperature range from -52°C to +177°C with FEP cable insulation provides reliable operation in demanding industrial environments.
Bently Nevada 330910-00-13-10-02-00 is designed for rotating machinery that offers very limited installation space while still requiring accurate shaft monitoring. The probe works as part of the 3300 XL NSv Proximity Transducer System together with an NSv extension cable and an NSv Proximitor Sensor. Compact dimensions make the assembly suitable for machinery where conventional 5 mm or 8 mm systems cannot be installed. Stable measurement performance helps maintenance teams improve equipment reliability and operational efficiency.

Many centrifugal air compressors, refrigeration compressors, and process gas compressors require vibration and position monitoring without occupying additional installation space. Bently Nevada 330910-00-13-10-02-00 supports radial vibration, radial position, axial position, tachometer, zero speed, and phase reference measurements. The compact probe design also performs well on shafts smaller than 51 mm and flat targets smaller than 15 mm. Standard FEP cable insulation provides durability for industrial environments across a wide operating temperature range.

Bently Nevada 330910-00-13-10-02-00 features a miniature coaxial ClickLoc connector with a 1.0 meter standard cable configuration and supports optional cable lengths of 0.5 m, 1 m, 5 m, and 7 m. The probe offers an average scale factor of 7.87 V/mm and a linear range of 1.5 mm for precise eddy current measurement. Existing 3300 RAM systems can often be upgraded by replacing only the Proximitor Sensor, while older 3000-series or 7000-series 190 systems require complete NSv components. The flexible upgrade path helps reduce maintenance complexity and extends the service life of monitoring systems.

The 330910-00-13-10-02-00 Bently Nevada 3300 NSv Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330910-00-13-10-02-00 3300 NSv Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330910-00-13-10-02-00 3300 NSv Proximity Probe Specs

General

  • Manufacturer Bently Nevada
  • Model 330910-00-13-10-02-00
  • Condition New Original ready stock
  • Product Family 330910-00-13-10-02-05,330910-00-13-10-02-CN,330910-00-13-10-12-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • System Compatibility: Perfectly matches the Bently Nevada 3300 NSv eddy current sensor system.
  • Preamplifier Connection: A dedicated 3300 NSv preamplifier must be used to ensure signal conversion accuracy.
  • Extension Cable: Compatible with the 3300 NSv series dedicated coaxial extension cable; mixing with other series is not recommended.
  • Small Target Material: Specifically optimized for small target shafts, non-ferromagnetic metals, or special alloy materials.
  • Probe Diameter: Uses a 5mm probe diameter, suitable for precision measurements in confined installation spaces.
  • Thread Specification: Features a 3/8-24 UN standard fine thread; pay attention to pitch matching during installation.
  • Housing Length: The housing is 1.3 inches long and has no unthreaded portion; precise calculation of the screw-in depth is required during installation.
  • Cable Length: Comes with a 1.0-meter (approximately 3.3-foot) miniature coaxial cable; avoid excessive pulling during connection.
  • Miniature Rotating Machinery: Widely used for monitoring radial vibration and axial displacement of small-diameter shafts.
  • Small Clearance Bearings: Suitable for measuring bearing clearance in small-power steam turbines and centrifugal compressors.
  • Industrial Pumps: Commonly used for monitoring the rotor dynamics of high-speed water pumps and oil pumps.
  • Confined Spaces: Designed for compact mechanical interiors where traditional 8mm probes cannot fit.
Description
The 330910-00-13-10-02-00 is a 3300 NSv Proximity Probe designed for accurate and reliable non-contact displacement measurement in industrial machinery monitoring applications. As part of the 3300 NSv series, this probe delivers consistent performance for rotating equipment condition monitoring.

The 330910-00-13-10-02-00 features an M10 × 1 threaded body and is supplied with armor, providing enhanced mechanical protection for use in demanding industrial environments. The unthreaded length is 0 mm, and the overall case length is 130 mm, allowing precise mounting while accommodating applications that require a longer probe body.

In terms of connectivity, the probe uses a miniature coaxial ClickLoc connector with a standard cable, ensuring a secure and reliable electrical interface. The total length is 1.0 meter (39 in), offering sufficient reach for most machinery monitoring setups.

Agency approval is not required, making the 330910-00-13-10-02-00 suitable for general industrial applications where formal certification is not mandated.
Alternative Names
33O91O-OO-13-1O-O2-OO 3309I0-00-I3-I0-02-00 3309100013100200 330910-00-13-10-02-05 330910-00-13-10-02-BR 330910-00-13-10-02-RU 330910-00-13-10-02-CN 330910-00-13-10-12-00
Technical notes
The Bently Nevada 330910-00-13-10-02-00 is a premium 5mm 3300 NSv proximity probe featuring a 1.3-inch threaded body and 1.0-meter cable, engineered specifically for high-accuracy vibration and position monitoring on small-diameter shafts or constrained machinery footprints.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What applications benefit most from Bently Nevada 330910-00-13-10-02-00?
Bently Nevada 330910-00-13-10-02-00 is ideal for centrifugal air compressors, refrigeration compressors, process gas compressors, and other rotating machinery with limited installation space. It also performs well on small shafts and compact measurement targets.
Why choose 330910-00-13-10-02-00 instead of a standard proximity probe?
The compact NSv design fits locations where standard 3300 XL 5 mm or 8 mm transducer systems cannot be installed because of counter bore, side-view, or rear-view restrictions.
How does 330910-00-13-10-02-00 support machine condition monitoring?
The probe measures radial vibration, radial position, axial position, tachometer signals, zero speed, and phase reference signals, providing essential data for machinery protection.
Can Bently Nevada 330910-00-13-10-02-00 operate in high-temperature environments?
Yes. The operating temperature ranges from -52°C to +177°C, and the FEP cable insulation is designed for demanding industrial applications.
