JNJ5300-08-06-005-030-05-00-00-03

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada JNJ5300-08-06-005-030-05-00-00-03 is an 8 mm 3300 XL proximity probe offering precise shaft vibration and displacement monitoring with robust IP68 protection and a wide operating range from -51 °C to +177 °C.
Get a quick price for JNJ5300-08-06-005-030-05-00-00-03
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for JNJ5300-08-06-005-030-05-00-00-03

  • Manufacturer:
    Bently Nevada
  • Part Number:
    JNJ5300-08-06-005-030-05-00-00-03
  • Product Family:
    Proximity Probe
  • Product Series:
    3300 XL 8mm Proximity Probe System.
  • Probe Diameter:
    8 mm (standard industrial size).
  • Linear Range:
    2.0 mm (approx. 80 mils). Standard Sensitivity: 7.87 V/mm (200 mV/mil).
  • Thread Specification (-06):
    M10 x 1 metric thread.
  • Unthreaded Length (-005):
    5 mm (probe tip shank).
  • Overall Housing Length (-030):
    30 mm (integral threaded tube length).
  • Included Cable Length (-05):
    0.5 m (50 cm).
  • Connector Type (-03):
    Small coaxial male connector with locking mechanism (with anti-corrosion coating).
  • Operating Temperature:
    -51°C to +177°C.
  • Protection Rating:
    Probe head has IP68 waterproof and oil-resistant seal.
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    20.5x22.5x3.5cm
  • Tariff Code:
    8431499900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Protection System Upgrades Application

Features:

  • Reverse-Mount 8 Mm Proximity Probe Designed For Precise Shaft Monitoring.
  • IP68 Waterproof And Oil-Resistant Probe Head Suitable For Harsh Industrial Environments.
  • Operates Reliably From -51 °C To +177 °C With High Sensitivity Of 7.87 V/Mm.
The JNJ5300-08-06-005-030-05-00-00-03 proximity probe features a compact 30 mm housing with a 5 mm unthreaded probe tip and M10 x 1 metric thread, making installation straightforward in tight mechanical spaces. Its 0.5 m coaxial cable with locking connector and anti-corrosion coating ensures stable and long-lasting electrical connectivity, even in environments exposed to moisture or lubricants.

With a linear range of 2.0 mm (80 mils) and standard sensitivity of 7.87 V/mm (200 mV/mil), the probe captures subtle vibrations, shaft displacements, and keyphasor signals accurately, providing essential data for predictive maintenance programs.

The probe’s wide operating temperature range of -51 °C to +177 °C, combined with its robust sealing, makes it suitable for extreme conditions such as high-speed turbines, pumps, and compressors. Its design emphasizes durability and measurement stability over long-term industrial use.

The JNJ5300-08-06-005-030-05-00-00-03 Bently Nevada Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada JNJ5300-08-06-005-030-05-00-00-03 Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada JNJ5300-08-06-005-030-05-00-00-03 Proximity Probe Specs

General

  • Manufacturer GE / Bently Nevada
  • Model JNJ5300-08-06-005-030-05-00-00-03
  • Condition New Original ready stock
  • Product Family JNJ5300-08-06-005-030-05-01-00-03,JNJ5300-08-06-005-030-10-00-00-03,JNJ5300-08-06-005-040-05-00-00-03
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Physical Armor Protection: Configurations at the end of this model typically include stainless steel armor to protect cables from compression, abrasion, or oil corrosion during unit operation.
  • Connector Insulation Protection: The connection between the probe and the extension cable must be wrapped with transparent heat-shrink tubing. The connector (common end) must never contact the metal housing or cable tray to prevent grounding loop interference.
  • Sealing and Corrosion Protection: The probe tip is encapsulated in high-performance engineering plastic with an IP68 protection rating, providing long-term resistance to turbine oil (L-TSA) erosion and penetration.
  • Electrical Limiting Protection: When used with a Bently Nevada preamplifier, it features reverse polarity protection and short-circuit protection to prevent circuit burnout due to incorrect wiring in the field.
  • Backward Compatibility: As part of the 3300 XL series, it is fully compatible with older 3300 systems, allowing direct replacement of older non-XL probes without changing the mounting bracket.
  • Digital Integration: Supports digital signal processing via Orbit 60 or 3500 systems, improving signal-to-noise ratio and anti-interference capabilities.
  • Standardized Extension Cables: This 0.5-meter probe can be flexibly upgraded to match 5-meter or 9-meter overall systems; simply changing the preamplifier and extension cable of the corresponding length alters the installation layout.
  • Upgraded Monitoring Accuracy: Compared to earlier models, the XL series offers a wider linear range, significantly reducing zero-point drift caused by ambient temperature fluctuations.
  • Radial Vibration: Mounted at 90° (X/Y axis) on the bearing housing, used to monitor the shaft's orbital trajectory (orbit), identifying misalignment, rotor imbalance, or oil film eddy.
  • Thrust Position: Mounted on the thrust bearing side, monitoring the shaft's longitudinal movement; it serves as the last line of defense against catastrophic collisions between the rotor and stator.
  • Keyphasor: Aligns with keyways or protrusions on the shaft, providing a trigger pulse per revolution for calculating precise rotational speed and performing vibration phase analysis.
  • Eccentricity Monitoring: Monitors the degree of thermal bending of the shaft during the idle (turning gear) phase before starting a large steam turbine, ensuring safe startup.
Description
The JNJ5300-08-06-005-030-05-00-00-03 is part of Bently Nevada's 3300 XL 8 mm Proximity Probe System, featuring an 8 mm probe diameter, 5 mm unthreaded tip, and M10 x 1 metric thread for stable mounting. Its 30 mm housing and included 0.5 m coaxial cable with anti-corrosion, locking connector ensure reliable mechanical and electrical integration in industrial machinery.

With a linear range of 2.0 mm (80 mils) and sensitivity of 7.87 V/mm (200 mV/mil), this probe delivers high-resolution measurements of shaft displacement, vibration, and keyphasor signals. The IP68-rated probe head is waterproof and oil-resistant, allowing operation in harsh industrial conditions, while the wide temperature range of -51 °C to +177 °C ensures stability across extreme environments.

Compared to the JNJ5300-08-06-005-030-05-00-00-02, which lacks the anti-corrosion coating on the connector and has slightly lower sealing, this model offers superior durability and signal reliability under high-temperature, wet, or oily conditions.
Alternative Names
JNJ5300-08-03-005-030-05-00-00-03 JNJ5300-08-09-005-030-05-00-00-03 JNJ5300-08-06-000-030-05-00-00-03 JNJ5300-08-06-010-030-05-00-00-03 JNJ5300-08-06-005-020-05-00-00-03 JNJ5300-08-06-005-040-05-00-00-03
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the linear range of the JNJ5300-08-06-005-030-05-00-00-03, and why does it matter?
The probe offers a linear range of 2.0 mm (80 mils), allowing precise measurement of shaft displacement and vibration. A wide linear range ensures that the probe can accurately capture both small and large shaft excursions without signal saturation.
What advantages does the anti-corrosion coated connector provide?
The small coaxial male connector with a locking mechanism and anti-corrosion coating ensures durable electrical connections and reduces maintenance issues caused by connector oxidation.
How does the probe handle extreme temperatures?
It operates reliably from -51 °C to +177 °C, making it suitable for both cryogenic and high-temperature machinery applications.
