The Bently Nevada 3500/54M 286566-01 is an overspeed detection module designed for 3500 series machinery protection systems, providing real-time speed monitoring and rapid protective trips to prevent machinery damage.
Get a quick price for 3500/54M 286566-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/54M 286566-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/54M 286566-01
  • Product Family:
    3500 System
  • Product Type:
    Detection Module
  • Module Type:
    Overspeed Detection Module
  • Measurement range:
    0 ~ 99,999 RPM
  • Maximum input frequency:
    20 kHz
  • Power supply:
    3500 Rack backplane 24 VDC
  • Operating temperature:
    -40°C ~ +85°C
  • Certifications:
    API 670, CE, IEC 61000
  • Weight:
    0.88 kg
  • Estimated shipping dimensions:
    2.5x25.8x24cm
  • Tariff Code:
    8517795000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Communication Application Safety & Reliability

Features:

  • Real-Time Speed Monitoring – Continuously tracks machinery speed to prevent overspeed or reverse rotation damage.
  • Wide Measurement Range – Supports 0 to 99,999 RPM with maximum input frequency of 20 kHz.
  • Standards Compliant and Robust – Meets API 670, CE, and IEC 61000 standards with industrial-grade operating temperature tolerance.
The Bently Nevada 3500/54M 286566-01 Overspeed Detection Module provides critical protection for high-speed rotating machinery. By monitoring real-time speed and triggering immediate trips, it prevents catastrophic equipment failures, ensuring operational safety and reliability. The module’s wide measurement range and fast input frequency handling make it suitable for demanding industrial applications.

Powered from the 3500 series rack backplane at 24 VDC, the 3500/54M 286566-01 integrates seamlessly into existing 3500 machinery protection systems. Its operating temperature tolerance of -40°C to +85°C ensures performance in harsh environments, while compliance with API 670, CE, and IEC 61000 guarantees global standards adherence.

Operators using the 3500/54M 286566-01 benefit from accurate monitoring, early warning, and rapid response capabilities. The module’s design enhances predictive maintenance strategies, reduces unplanned downtime, and provides reliable protection for turbines, compressors, motors, and other critical rotating machinery in industrial plants.

The 3500/54M 286566-01 Bently Nevada Overspeed Detection Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 3500/54M 286566-01 Overspeed Detection Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 3500/54M 286566-01 Overspeed Detection Module Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 3500/54M 286566-01
  • Condition New Original ready stock
  • Product Family 3500/54M-04-00 286566-05,3500/54M,3500/53 133388-01
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Backplane Data Transmission: Real-time communication with the 3500/22M (RIM) module via the 3500 rack backplane, uploading speed data, alarm status, and event lists to the host computer.
  • Software Configuration Interface: Parameter settings (such as trip point, hysteresis, tooth count, etc.) are performed using the 3500 Rack Configuration Software, supporting remote access via Ethernet or serial interface.
  • Status Indicators (LEDs): The module panel features OK, TX/RX (communication in progress), and Bypass indicators, providing intuitive feedback on on-site physical communication and operating status.
  • External System Integration: Supports sending data to DCS or PLC systems for secondary monitoring via the 3500/92 communication gateway using Modbus RTU/TCP or Ethernet/IP protocols.
  • Steam/Gas Turbines: Monitor spindle speed to prevent overspeeding due to sudden load drops.
  • Large Compressors: Ensure impellers operate within safe speed ranges during multi-stage compression processes.
  • Expanders: Monitor speed during cryogenic processes to prevent overspeed damage to seals.
  • Generators: Monitor generator frequency-dependent speed stability to ensure grid synchronization safety.
  • Reverse Flow Monitoring: In pump applications, prevent backflow of media that could cause reverse rotation during shutdown, damaging bearings or mechanical seals.
  • Ultra-fast Response: The system has an extremely short response time (typically < 50 milliseconds), ensuring forced shutdown of the oil circuit before high-speed equipment such as steam turbines experience overspeed.
  • Voting Logic: Supports 2-out-of-2 (2oo2) or 2-out-of-3 (2oo3) logic configurations. In 2oo3 mode, a single sensor failure will not cause false tripping, greatly improving system availability.
  • Self-Diagnostic Function: The module continuously monitors the sensor circuit (open circuit, short circuit) and the status of internal electronic components. Once a hardware anomaly is detected, a failure warning will be immediately issued via the OK relay.
  • API Standard Compliance: Fully compliant with the mandatory requirements of API 670 (Mechanical Protection Systems Standard) and API 612 (Special Purpose Steam Turbine Standard) regarding electronic overspeed protection.
Description
The Bently Nevada 3500/54M 286566-01 is a precision overspeed detection module engineered for integration with 3500 series machinery protection systems. It continuously monitors rotating machinery, including turbines, compressors, and motors, and provides immediate trip signals when overspeed, underspeed, or reverse rotation conditions occur. This ensures critical equipment is safeguarded against catastrophic failures.

Designed to operate within a measurement range of 0 to 99,999 RPM, the 3500/54M 286566-01 can handle input frequencies up to 20 kHz. It is powered directly from the 3500 rack backplane at 24 VDC, ensuring seamless system integration. Its operating temperature range of -40°C to +85°C allows reliable performance in harsh industrial environments.

The module complies with international standards, including API 670, CE, and IEC 61000, reinforcing its suitability for global industrial applications. Its robust design and rapid response capabilities make the Bently Nevada 3500/54M 286566-01 a dependable choice for real-time machinery protection, especially in high-speed or safety-critical operations.

By employing the 3500/54M 286566-01, operators gain precise monitoring and early-warning functionality, which supports predictive maintenance strategies and minimizes unplanned downtime. Its compatibility with the 3500 series ensures straightforward installation and integration into existing systems.
Alternative Names
3500/54M 286566-02 3500/54 288062-01 3500/54M-02-00 286566-03 3500/50M 134938-01 3500/53 133388-01
Technical notes
The Bently Nevada 3500/54M (286566-01) is a 4‑channel seismic monitor module for the 3500 series rack. It interfaces with accelerometers and velocity sensors to provide continuous machinery protection. Each channel accepts IEPE inputs and performs real-time integration from acceleration to velocity, eliminating external signal conditioners.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can I verify that the 3500/54M 286566-01 is properly installed in the rack?
Ensure it is seated correctly in the 3500 rack backplane, with the 24 VDC power connected and proper communication with other 3500 modules. Indicators on the module can confirm operational status.
What types of alarms does the 3500/54M 286566-01 trigger?
The module triggers overspeed, underspeed, and reverse rotation trips, allowing immediate protective action to prevent machinery damage.
How does environmental temperature affect the module?
The 3500/54M 286566-01 is rated to operate from -40°C to +85°C, maintaining accurate speed detection under extreme industrial conditions.
How does the 3500/54M 286566-01 support predictive maintenance?
By providing accurate real-time speed data and early trip signals, the module allows operators to identify abnormal conditions before they cause downtime, enabling proactive maintenance planning.
