21505-00-12-05-02

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 21505-00-12-05-02 is a 7200 8 mm standard-mount proximity probe with 3/8-24 threads, a 1.2 in case, stainless-steel lead armor, a 0.5 m integral lead and a miniature male coaxial connector.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for 21505-00-12-05-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 21505-00-12-05-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    21505-00-12-05-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    8 mm Standard Mount Probe
  • Stock:
    1
  • Case thread:
    3/8-24 UNF-2A
  • Overall case length:
    1.2 in (30.5 mm)
  • Unthreaded length:
    0.0 in
  • Integral cable length:
    0.5 m
  • Lead armor:
    Stainless-steel lead armor
  • Weight:
    0.06 kg
  • Estimated shipping dimensions:
    55x1.5x1.5cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals 3/8-24 Mount Armored Lead 7200 Signal Path Product Applications

Features:

  • English-threaded mount: The standard 8 mm probe case uses 3/8-24 threads.
  • Armored lead: Stainless-steel armor protects the 0.5 m integral cable.
  • Compact case: The 12 option specifies 1.2 in overall case length with 0.0 in unthreaded length.
The 21505 probe family is the armored 3/8-24 standard-mount choice in the 7200 ordering table.

Its short integral lead ends in a miniature male coaxial connector for the matched extension-cable path.

The probe senses shaft-target gap as part of a system containing an extension cable and Proximitor.

Apter Power can provide documentation, a quotation and 7200 configuration support for the Bently Nevada 21505-00-12-05-02 8 mm Standard Mount Probe.
Bently Nevada 21505-00-12-05-02 8 mm Standard Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Case thread: The standard 21505 housing uses 3/8-24 threads.
  • Case length: The 12 option is 1.2 in (30.5 mm) overall.
  • Unthreaded section: The 00 option is 0.0 in ahead of the threaded case.
  • Probe tip: The sensing tip belongs to the 8 mm 7200 design.
  • Lead length: The 05 option provides 0.5 m of integral coaxial cable.
  • Stainless armor: The 21505 family protects the integral lead with stainless-steel armor.
  • Connector: The 02 option ends in a miniature male coaxial connector.
  • Tip junction: The improved standard 8 mm design includes the Cable LoC cable-to-tip connection.
  • Probe role: The 8 mm tip senses gap to a conductive shaft target.
  • Extension cable: A separate cable adds to the 0.5 m integral probe lead.
  • Five-metre path: A 4.5 m extension brings the combined length to 5 m.
  • Signal conditioning: The 18745-03 Proximitor conditions the five-metre loop output.
  • Radial vibration: A complete 7200 loop can monitor shaft motion at a bearing.
  • Axial thrust: The assembled system can measure shaft thrust position.
  • Eccentricity: The complete transducer loop can indicate rotor bow.
  • Average shaft position: A 7200 system can measure radial shaft position.
Description
For an English-threaded 7200 installation, 21505-00-12-05-02 is an 8 mm standard-mount proximity probe with a 3/8-24 case and stainless-steel armor around its integral lead. The probe is one component of the measurement loop.

Its 1.2 in case has a 0.0 in unthreaded-length option. A miniature male coaxial connector terminates the 0.5 m integral cable on 21505-00-12-05-02, giving the installer a compact English-threaded probe arrangement.

In a complete 7200 system, 21505-00-12-05-02 senses target gap at the probe tip; an extension cable and Proximitor complete the signal path to the monitor. Cable lengths and the selected Proximitor determine the assembled system length.
Alternative Names
Bently Nevada 21505-00-12-05-02 21505 00 12 05 02 21505/00/12/05/02 2150500120502 21505-00-12-05-02 7200 probe Bently Nevada 21505 00 12 05 02
Technical notes
The 0.5 m integral lead on 21505-00-12-05-02 is shorter than the 1 m lead used with a 4 m extension. For a five-metre 7200 loop, the ordering matrix provides a 4.5 m extension and 18745-03 Proximitor. Selecting a 4 m extension for this probe would change the intended combined electrical length, even though the coaxial connection may fit.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Will 21505-00-12-05-02 fit a 3/8-24 probe mount?
Yes. Its standard 8 mm probe case uses 3/8-24 threads; the installed mount must also accommodate the 1.2 in case length.
Does 21505-00-12-05-02 include protected integral lead cable?
Yes. The 21505 probe family has stainless-steel lead armor, while this order code specifies a 0.5 m integral length.
Will 21505-00-12-05-02 terminate at the miniature coax connection used in a 7200 loop?
Yes. Its 02 connector option is the miniature male coaxial termination specified by the 7200 probe ordering table.
Can 21505-00-12-05-02 be used as a complete proximity measurement channel by itself?
No. The 7200 measurement path also requires the appropriate extension cable and Proximitor to condition the signal for a monitor.
What cable temperature range applies when 21505-00-12-05-02 is mounted near hot machinery?
The 7200 probe and extension cable operating range is -34 to +177 °C; the Proximitor has a separate lower upper-temperature limit.
Does 21505-00-12-05-02 have a long unthreaded tip for a recessed mounting hole?
No. Its 00 unthreaded-length option is 0.0 in; the ordered 1.2 in case and the mounting geometry determine tip placement.
